Design of a Modular Plantar Orthosis System through the Application of TRIZ Methodology Tools

1
Faculty of Engineering, Architecture and Design, Autonomous University of Baja California, Ensenada 22860, Mexico
2
Faculty of Chemical Sciences and Engineering, Autonomous University of Baja California, Tijuana 22390, Mexico
3
Department Industrial Engineering and Manufacturing, Autonomous University of Ciudad Juarez, Ciudad Juárez 32310, Mexico
*
Author to whom correspondence should be addressed.
Academic Editor: Lapo Governi
Appl. Sci. 2021, 11(5), 2051; https://doi.org/10.3390/app11052051
Received: 11 December 2020 / Revised: 1 February 2021 / Accepted: 17 February 2021 / Published: 25 February 2021
(This article belongs to the Special Issue Personalized Medical Devices)
Innovations within the medical device sector are constantly and rapidly emerging due to increasing demand, especially for orthosis systems, which usually constitute built rigids with low comfort, due mainly to the standardized production process. This article reports the design process of a plantar orthosis system from the application of Theory of Inventive Problem Solving (TRIZ) tools, known as generic parameters, matrix of contradictions, and inventive principles. The final orthosis is integrated by four modules or components (1 central and 3 movables) and customers can buy only the required ones, reducing cost in unnecessary parts. The plantar orthosis was defined based on three engineering parameters that delimited the design work by developing a customizable system that is capable of performing simultaneous functions and whose manufacture could be standardized. We identified the existence of a technical contradiction between the engineering parameters, customization, and standardization, which was solved by the inventive principles of segmentation, inversion, transition to a new dimension, and porous materials. A modular design with four components was accomplished, molds are built for each component in a machining center and injected using granulated ethylene vinyl acetate copolymer. The positions of the movable components are configured through a bolt-hole assembly mechanism to the central component, which is a flat perforated plantar base. The novelty in the design here presented is elated to supports that constitute the orthosis, which are interchangeable and adjustable to the pathological and morphological needs of each patient. View Full-Text
