An Overview of Challenges Associated with Automatic Detection of Concrete Cracks in the Presence of Shadows
Abstract
:1. Introduction
Paper | Feature Enhancement/ Pre-Processing | Classification of Fracture Dimensions | Type of Neural Network | Open-Source | Image Resolution | Filter Size | Filter Type | Images in the Dataset | Accuracy, % |
---|---|---|---|---|---|---|---|---|---|
[24] | N | N | CNN | VGG16 | 256 × 256 | 5 × 5 | 3500 | 92.3 | |
[8] | Y | Y | CNN | N/A | 227 × 227 | 40,000 | 99.9 | ||
[14] | Y | Y | ANN vs. Fuzzy | N/A | 256 × 256 | Object Detection | 205 | 96.1 | |
[16] | CNN vs. SVM vs. Boost | ConvNet | 227 × 227 | 40,000 | 99.7 | ||||
[9] | Y | CNN | N/A | 256 × 256 | 40,000 | 98 | |||
[15] | Y | Image Segmentation Approach | No | N/A | Automatic Peak Detection | N/A | N/A | ||
[19] | N | N | KNN vs. Decsion Tree vs. SVM vs. Ranorest | 227 × 227 | 20,000 | ||||
[4] | Y | Y | No (Review Paper) | N/A | N/A | N/A | N/A | N/A | |
[20] | Y | N | CNN | AlexNet, LeNet-5, CIFAR10 | 1024 × 1024 | 32 × 32 | 94 | ||
[21] | Y | N | CNN | N/A | N/A | N/A | ASPP | N/A | 96.7 |
[23] | N/A | N/A | CNN-LSTM | N/A | N/A | N/A | N/A | N/A | |
[22] | N/A | N/A | New CNN vs. R-CNN vs. U-Net | N/A | 576 × 576 | N/A | N/A | N/A | 82.5 |
[17] | N | N | FCN | VGG16 | 227 × 227 | 40,000 | 90 | ||
[18] | N/A | N/A | CNN | AlexNet | 3120 × 4160 | N/A | 60,000 | 99.06 | |
[13] | Y | N | Backpropagation NN | N/A | N/A | N/A | N/A | 225 | 92 |
[25] | N | Y | R-CNN | 376 | |||||
[11] | N/A | N | U-Net | N/A | N/A | N/A | N/A | N/A | 78.12 |
[26] | AlexNet, VGGNet13, and ResNet18 | 227 × 227 | 10,000 | ||||||
[27] | N | N | CNN | N/A | 16 × 16 | N/A | N/A | 64,000 | 93 |
[28] | Y | N | SVM | N/A | N/A | N/A | N/A | N/A | 94 |
[29] | N | N | ANN | N/A | N/A | N/A | N/A | N/A | N/A |
2. The Difficulties of Automatic Concrete-Crack Detection in the Presence of Shadow Effects
- Training dataset—the dataset published in [40], consisting of 40,000 concrete images (227 × 227 pixels with RGB channels) with and without cracks. As mentioned above, this database has already been used by several researchers for the development of deep-learning methods for concrete-crack detection (see Table 1). Sample images of each type are displayed in the Figure 1. Note that no shadow effects are present in the images included in this dataset.
- Testing dataset—the dataset comprising 500 concrete images (227 × 227 pixels with RGB channels) with and without cracks with the shadow effects present in all images. Samples images of each type are depicted in the Figure 2.
3. The Challenges Associated with the Application of Shadow Removal Techniques
4. Discussion
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Acknowledgments
Conflicts of Interest
Abbreviations
NN | Neural network |
ANN | Artificial neural network |
CNN | Convolutional neural network |
R-CNN | Region-based convolutional neural network |
DSN | Deeply-supervised net |
LSTM | Long short-term memory |
SVM | Support vector machine |
KNN | K-nearest neighbors |
FCN | Fully convolutional network |
UAV | Unmanned aerial vehicle |
DSN | Deeply-supervised net |
