Fast Planar Detection System Using a GPU-Based 3D Hough Transform for LiDAR Point Clouds
Abstract
:1. Introduction
2. Related Works
2.1. Clustering Methods
2.2. Stochastic Methods
2.3. Parameter Spaces Methods
3. Planar Detection System Using GPU-Based 3D Hough Transform
3.1. System Overview
3.2. 3D Hough Space Generation
3.3. Flag Map Generation
3.4. CPU–GPU Hybrid System
4. Experiments and Analysis
4.1. Three-Dimensional Hough Space and Flag Map Performance
4.2. Multiple Fraction Integration
4.3. Parallel 3DHT Performance
4.4. Multiple Fraction Integration
5. Conclusions
Author Contributions
Funding
Acknowledgments
Conflicts of Interest
References
