Robust Space Time Adaptive Processing Methods for Synthetic Aperture Radar
Abstract
:1. Introduction
2. SAR Simulation Models
2.1. SAR Signal Model
2.2. Jammer and Noise Models
2.3. Basic STAP Method
2.4. Influence of Platform Motion
3. The Piecewise Constrained STAP Based on Sub-Apertures Framework
4. The Piecewise Constrained Generalized Sidelobe Canceller
5. Simulation Result
6. Measured Data Results
7. Conclusions
Author Contributions
Funding
Conflicts of Interest
References
