Placenta Accreta Spectrum (PAS) Disorder: Ultrasound versus Magnetic Resonance Imaging
Abstract
1. Introduction
2. Materials and Methods
2.1. Patient Population
2.2. Imaging Acquisition
2.3. Imaging Analysis
2.4. Definitive Diagnosis
2.5. Statistical Analysis
3. Results
3.1. Absence/Presence of PAS
3.2. Diagnosing Grade of PAS
4. Discussion
5. Conclusions
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Conflicts of Interest
References
- Palacios-Jaraquemada, J.M.; Basanta, N.; Fiorillo, A.; Labrousse, C.; Martínez, M. Neonatal outcome after conservative-reconstructive surgery for placenta accreta spectrum disorders. J. Matern. Fetal Neonatal Med. 2021, 1–3. [Google Scholar] [CrossRef] [PubMed]
- Silver, R.M.; Branch, D.W. Placenta Accreta Spectrum. N. Engl. J. Med. 2018, 378, 1529–1536. [Google Scholar] [CrossRef] [PubMed]
- Collins, S.L.; Ashcroft, A.; Braun, T.; Calda, P.; Langhoff-Roos, J.; Morel, O.; Stefanovic, V.; Tutschek, B.; Chantraine, F. Proposal for standardized ultrasound descriptors of abnormally invasive placenta (AIP). Ultrasound Obstet. Gynecol. 2015, 47, 271–275. [Google Scholar] [CrossRef]
- Irving, F.C.; Hertig, A.T. A study of placenta accreta. Surg. Gynec. Obstet. 1937, 64, 178–200. [Google Scholar]
- Morgan, E.A.; Sidebottom, A.; Vacquier, M.; Wunderlich, W.; Loichinger, M. The effect of placental location in cases of placenta accreta spectrum. Am. J. Obstet. Gynecol. 2019, 221, 357.e1–357.e5. [Google Scholar] [CrossRef] [PubMed]
- Jauniaux, E.; Chantraine, F.; Silver, R.M.; Langhoff-Roos, J.; FIGO Placenta Accreta Diagnosis and Management Expert Consensus Panel. FIGO consensus guidelines on placenta accreta spectrum disorders: Epidemiology. Int. J. Gynecol. Obstet. 2018, 140, 265–273. [Google Scholar] [CrossRef]
- Fitzpatrick, K.E.; Sellers, S.; Spark, P.; Kurinczuk, J.J.; Brocklehurst, P.; Knight, M. The management and outcomes of placenta accreta, increta, and percreta in the UK: A population-based descriptive study. BJOG 2014, 121, 62–71. [Google Scholar] [CrossRef] [PubMed]
- Bailit, J.L.; Grobman, W.A.; Rice, M.M.; Reddy, U.M.; Wapner, R.; Varner, M.; Leveno, K.J.; Iams, J.D.; Tita, A.; Saade, G.; et al. Morbidly Adherent Placenta Treatments and Outcomes. Obstet. Gynecol. 2015, 125, 683–689. [Google Scholar] [CrossRef] [PubMed]
- Thurn, L.; Lindqvist, P.; Jakobsson, M.; Colmorn, L.; Klungsoyr, K.; Bjarnadóttir, R.; Tapper, A.; Børdahl, P.; Gottvall, K.; Petersen, K.; et al. Abnormally invasive placenta-prevalence, risk factors and antenatal suspicion: Results from a large population-based pregnancy cohort study in the Nordic countries. BJOG: Int. J. Obstet. Gynaecol. 2015, 123, 1348–1355. [Google Scholar] [CrossRef]
- Calì, G.; Timor-Trisch, I.E.; Palacios-Jaraquemada, J.; Monteaugudo, A.; Forlani, F.; Minneci, G.; Foti, F.; Buca, D.; Familiari, A.; Scambia, G.; et al. Changes in ultrasonography indicators of abnormally invasive placenta during pregnancy. Int. J. Gynecol. Obstet. 2018, 140, 319–325. [Google Scholar] [CrossRef]
- Barzilay, E.; Brandt, B.; Gilboa, Y.; Kassif, E.; Achiron, R.; Raviv-Zilka, L.; Katorza, E. Comparative analysis of ultrasound and MRI in the diagnosis of placenta accreta spectrum. J. Matern. Fetal Neonatal Med. 2020, 1–4. [Google Scholar] [CrossRef]
- Jauniaux, E.; Ayres-de-Campos, D.; Langhoff-Roos, J.; Fox, K.A.; Collins, S. FIGO Placenta Accreta Diagnosis and Management Expert Consensus Panel. FIGO classification for the clinical diagnosis of placenta accreta spectrum disorders. Int. J. Gynaecol. Obstet. 2019, 146, 20–24. [Google Scholar] [CrossRef]
- Hecht, J.L.; Baergen, R.; Ernst, L.M.; Katzman, P.J.; Jacques, S.M.; Jauniaux, E.; Khong, T.Y.; Metlay, L.A.; Poder, L.; Qureshi, F.; et al. Classification and reporting guidelines for the pathology diagnosis of placenta accreta spectrum (PAS) disorders: Recommendations from an expert panel. Mod. Pathol. 2020, 33, 2382–2396. [Google Scholar] [CrossRef]
- D’Antonio, F.; Palacios-Jaraquemada, J.; Timor-Trisch, I.; Cali, G. Placenta accreta spectrum disorders: Prenatal diagnosis still lacks clinical correlation. Acta Obstet. Gynecol. Scand. 2018, 97, 773–775. [Google Scholar] [CrossRef]
- Jauniaux, E.; Bhide, A.; Kennedy, A.; Woodward, P.; Hubinont, C.; Collins, S. FIGO consensus guidelines on placenta accreta spectrum disorders: Prenatal diagnosis and screening. Int. J. Gynecol. Obstet. 2018, 140, 274–280. [Google Scholar] [CrossRef] [PubMed]
- Collins, S.L.; Alemdar, B.; van Beekhuizen, H.J.; Bertholdt, C.; Braun, T.; Calda, P.; Delorme, P.; Duvekot, J.J.; Gronbeck, L.; Kayem, G.; et al. Evidence-based guidelines for the management of abnormally invasive placenta: Recommendations from the International Society for Abnormally Invasive Placenta. Am. J. Obstet. Gynecol. 2019, 220, 511–526. [Google Scholar] [CrossRef] [PubMed]
- Kapoor, H.; Hanaoka, M.; Dawkins, A.; Khurana, A. Review of MRI imaging for placenta accreta spectrum: Pathophysiologic insights, imaging signs, and recent developments. Placenta 2021, 104, 31–39. [Google Scholar] [CrossRef]
- D’Antonio, F.; Iacovella, C.; Bhide, A. Prenatal identification of invasive placentation using ultrasound: Systematic review and meta-analysis. Ultrasound Obstet. Gynecol. 2013, 42, 509–517. [Google Scholar] [CrossRef] [PubMed]
- Jauniaux, E.; Bhide, A. Prenatal ultrasound diagnosis and outcome of placenta previa accreta after cesarean delivery: A systematic review and meta-analysis. Am. J. Obstet. Gynecol. 2017, 217, 27–36. [Google Scholar] [CrossRef]
- Jauniaux, E.; Alfirevic, Z.; Bhide, A.G.; Belfort, M.A.; Burton, G.J.; Collins, S.; Dornan, S.; Jurkovic, D.; Kayem, G.; Kingdom, J.; et al. Placenta Praevia and Placenta Accreta: Diagnosis and Management. BJOG: Int. J. Obstet. Gynaecol. 2018, 126, e1–e48. [Google Scholar] [CrossRef]
- Del Negro, V.; Aleksa, N.; Galli, C.; Ciminello, E.; Derme, M.; Vena, F.; Muzii, L.; Piccioni, M.G. Ultrasonographic Diagnosis of Placenta Accreta Spectrum (PAS) Disorder: Ideation of an Ultrasonographic Score and Correlation with Surgical and Neonatal Outcomes. Diagnostics 2020, 11, 23. [Google Scholar] [CrossRef] [PubMed]
- Jha, P.; Pōder, L.; Bourgioti, C.; Bharwani, N.; Lewis, S.; Kamath, A.; Nougaret, S.; Soyer, P.; Weston, M.; Castillo, R.P.; et al. Society of Abdominal Radiology (SAR) and European Society of Urogenital Radiology (ESUR) joint consensus statement for MR imaging of placenta accreta spectrum disorders. Eur. Radiol. 2020, 30, 2604–2615. [Google Scholar] [CrossRef] [PubMed]
- Levine, D.; Hulka, C.A.; Ludmir, J.; Li, W.; Edelman, R.R. Placenta accreta: Evaluation with color Doppler US, power Doppler US, and MR imaging. Radiology 1997, 205, 773–776. [Google Scholar] [CrossRef]
- Lim, P.S.; Greenberg, M.; Edelson, M.I.; Bell, K.A.; Edmonds, P.R.; Mackey, A.M. Utility of Ultrasound and MRI in Prenatal Diagnosis of Placenta Accreta: A Pilot Study. AJR Am. J. Roentgenol. 2011, 197, 1506–1513. [Google Scholar] [CrossRef] [PubMed]
- Lopes, E.S.; Feitosa, F.E.D.L.; Brazil, A.V.; de Castro, J.D.V.; da Costa, J.I.F.; Júnior, E.A.; Peixoto, A.B.; Carvalho, F.H.C. Assessment of Sensitivity and Specificity of Ultrasound and Magnetic Resonance Imaging in the Diagnosis of Placenta Accreta. Avaliação da sensibilidade e especificidade da ultrassonografia e ressonância magnética no diagnóstico da placenta acreta. Rev. Bras Ginecol. Obstet. 2019, 41, 17–23. [Google Scholar] [CrossRef]
- Xia, H.; Ke, S.-C.; Qian, R.-R.; Lin, J.-G.; Li, Y.; Zhang, X. Comparison between abdominal ultrasound and nuclear magnetic resonance imaging detection of placenta accreta in the second and third trimester of pregnancy. Medicine 2020, 99, e17908. [Google Scholar] [CrossRef]
- Berkley, E.M.; Abuhamad, A.Z. Prenatal Diagnosis of Placenta Accreta: Is sonography all we need? J. Ultrasound Med. 2013, 32, 1345–1350. [Google Scholar] [CrossRef]
- Balcacer, P.; Pahade, J.; Spektor, M.; Staib, L.; Copel, J.A.; McCarthy, S. Magnetic Resonance Imaging and Sonography in the Diagnosis of Placental Invasion. J. Ultrasound Med. 2016, 35, 1445–1456. [Google Scholar] [CrossRef]
- Allen, B.C.; Leyendecker, J.R. Placental Evaluation with Magnetic Resonance. Radiol. Clin. N. Am. 2013, 51, 955–966. [Google Scholar] [CrossRef]
- Chou, M.M.; Tseng, J.J.; Ho, E.S.C. The application of three-dimensional color power Doppler ultrasound in the depiction of abnormal uteroplacental angioarchitecture in placenta previa percreta. Ultrasound Obstet. Gynecol. 2002, 19, 625–627. [Google Scholar] [CrossRef]
- Rezk, M.; Shawky, M. Grey-scale and colour Doppler ultrasound versus magnetic resonance imaging for the prenatal diagnosis of placenta accreta. J. Matern. Fetal Neonatal Med. 2014, 29, 218–223. [Google Scholar] [CrossRef] [PubMed]
- Ayati, S.; Pourali, L.; Pezeshkirad, M.; Toosi, F.S.; Nekooei, S.; Shakeri, M.T.; Golmohammadi, M.S. Accuracy of color Doppler ultrasonography and magnetic resonance imaging in diagnosis of placenta accreta: A survey of 82 cases. Int. J. Reprod. Biomed. 2017, 15, 225–230. [Google Scholar] [CrossRef] [PubMed]
- Kumar, I.; Verma, A.; Ojha, R.; Shukla, R.C.; Jain, M.; Srivastava, A. Invasive placental disorders: A prospective US and MRI comparative analysis. Acta Radiol. 2016, 58, 121–128. [Google Scholar] [CrossRef]
- Riteau, A.-S.; Tassin, M.; Chambon, G.; Le Vaillant, C.; De Laveaucoupet, J.; Quere, M.-P.; Joubert, M.; Prevot, S.; Philippe, H.-J.; Benachi, A. Accuracy of Ultrasonography and Magnetic Resonance Imaging in the Diagnosis of Placenta Accreta. PLoS ONE 2014, 9, e94866. [Google Scholar] [CrossRef]
- Meng, X.; Xie, L.; Song, W. Comparing the Diagnostic Value of Ultrasound and Magnetic Resonance Imaging for Placenta Accreta: A Systematic Review and Meta-analysis. Ultrasound Med. Biol. 2013, 39, 1958–1965. [Google Scholar] [CrossRef]
- Jaraquemada, J.M.P.; Bruno, C.H. Magnetic resonance imaging in 300 cases of placenta accreta: Surgical correlation of new findings. Acta Obstet. Gynecol. Scand. 2005, 84, 716–724. [Google Scholar] [CrossRef] [PubMed]
- Baughman, W.C.; Corteville, J.E.; Shah, R.R. Placenta Accreta: Spectrum of US and MR Imaging Findings. RadioGraphics 2008, 28, 1905–1916. [Google Scholar] [CrossRef]
- D’Antonio, F.; Iacovella, C.; Palacios-Jaraquemada, J.; Bruno, C.H.; Manzoli, L.; Bhide, A. Prenatal identification of invasive placentation using magnetic resonance imaging: Systematic review and meta-analysis. Ultrasound Obstet. Gynecol. 2014, 44, 8–16. [Google Scholar] [CrossRef]
Characteristics and Risk Factors | No PAS | Accreta | Increta | Percreta | p-Value |
---|---|---|---|---|---|
Number of patients (%) | 79 (75) | 14 (13) | 7 (6.7%) | 4 (3.8%) | |
Mean age (SD) 1 | 37 (5.5) | 38 (5.6) | 40 (7.5) | 38 (8) | 0.73 |
No previous cesarean (%) | 48 (60.8) | 2 (14.3) | 1 (14.3) | 0 | <0.001 |
1 previous cesarean (%) | 24 (30.4) | 7 (50) | 2 (28.6) | 0 | <0.001 |
2 previous cesareans (%) | 5 (6.3) | 3 (21.4) | 1 (14.3) | 3 (75) | <0.001 |
>2 previous cesareans (%) | 2 (2.5) | 2 (14.3) | 3 (42.8) | 1 (25) | <0.001 |
Major placenta previa (%) | 45 (60) | 11 (78.6) | 7 (100) | 4 (100) | 0.02 |
Minor placenta previa (%) | 34 (43) | 3 (21.4) | 0 | 0 | 0.02 |
Previous courettage (%) | 25 (31.6) | 4 (28.6) | 1 (14.3) | 2 (50) | 0.64 |
No previous courettage (%) | 54 (68.4) | 10 (71.4) | 6 (85.7) | 2 (50) | 0.64 |
Variable | Coefficient | SD 1 | p Value |
---|---|---|---|
Intercept | −3.95 | 0.87 | <0.001 |
Previous CS 2 | 1.20 | 0.33 | <0.001 |
Previous courettage | −0.08 | 0.041 | 0.83 |
Previous myomectomy | 2.87 | 1.38 | 0.03 |
Major placenta previa | 1.9 | 0.82 | 0.02 |
US Diagnosis | MRI Diagnosis | ||||
---|---|---|---|---|---|
Histological/ Surgical diagnosis | No PAS | PAS | No PAS | PAS | |
NO PAS (%) | 70 (88.6) | 9 (11.4) | 70 (88.6) | 9 (11.4) | |
PAS (%) | 2 (8) | 23 (92) | 3 (12) | 22 (88) |
US | MRI | |
---|---|---|
Accuracy | 0.89 | 0.88 |
Sensitivity | 0.92 | 0.88 |
Specificity | 0.89 | 0.89 |
PPV 1 | 0.72 | 0.71 |
NPV 2 | 0.97 | 0.95 |
US Diagnosis | MRI Diagnosis | ||||||||
---|---|---|---|---|---|---|---|---|---|
Histological/ Surgical diagnosis | No PAS | Accreta | Increta | Percreta | No PAS | Accreta | Increta | Percreta | |
No PAS (%) | 70 (88.6) | 9 (11.4) | 0 | 0 | 70 (88.6) | 9 (11.4) | 0 | 0 | |
Accreta (%) | 2 (14.3) | 12 (85.7) | 0 | 0 | 2 (14.3) | 10 (71.4) | 2 (14.3) | 0 | |
Increta (%) | 0 | 3 (42.8) | 2 (28.6) | 2 (28.6) | 1 (14.3) | 4 (57.1) | 0 | 2 (28.6) | |
Percreta (%) | 0 | 0 | 0 | 4 (100) | 0 | 1 (25) | 0 | 3 (75) |
Anterior | Posterior | Total | ||
---|---|---|---|---|
US: PAS/no-PAS distinction | Error (%) | 5 (5.8) | 6 (33.3) | 11 (10.6) |
Correct (%) | 81 (92.2) | 12 (66.7) | 93 (89.4) | |
Total | 86 | 18 | 104 | |
Accuracy for anterior placenta | Accuracy for posterior placenta | Difference significance (chi-squared test) | ||
0.94 | 0.67 | p = 0.0024 | ||
MRI: PAS/no-PAS distinction | Error (%) | 6 (7) | 6 (33.3) | 12 (11.5) |
Correct (%) | 80 (93) | 12 (66.7) | 92 (88.5) | |
Total | 86 | 18 | 104 | |
Accuracy for anterior placenta | Accuracy for posterior placenta | Difference significance (chi-squared test) | ||
0.93 | 0.67 | p = 0.0055 |
Anterior | Posterior | Total | ||
---|---|---|---|---|
US | Error (%) | 9 (10.5) | 7 (38.9) | 16 (15.4) |
Correct (%) | 77 (89.5) | 11 (61.1) | 88 (84.6) | |
Total | 86 | 18 | 104 | |
Accuracy for anterior placenta | Accuracy for posterior placenta | Difference significance (chi-squared test) | ||
0.89 | 0.61 | p = 0.0074 | ||
MRI | Error (%) | 13 (15.1) | 8 (44.4) | 21 (20.2) |
Correct (%) | 73 (84.9) | 10 (55.6) | 83 (79.8) | |
Total | 86 | 18 | 104 | |
Accuracy for anterior placenta | Accuracy for posterior placenta | Difference significance (chi-squared test) | ||
0.85 | 0.55 | p = 0.0126 |
