Ultrasound-Guided Pleural Effusion Drainage: Effect on Oxygenation, Respiratory Mechanics, and Liberation from Mechanical Ventilation in Surgical Intensive Care Unit Patients
Abstract
:1. Introduction
2. Materials and Methods
2.1. Study Patients
2.2. Mechanical Ventilation, Pleural Drainage, and Physiological Measurement
2.3. Data Collection and Statistical Analysis
3. Results
3.1. Patient Characteristics
3.2. Procedural Outcomes
3.3. Changes in Arterial Blood Gas Parameters and Respiratory Mechanics before and after the Procedure
3.4. Frequency and Predictors of Freedom from Mechanical Ventilation within the First 72 Post-Procedural Hours
3.5. Subgroup Analyses According to the Time Interval from Surgery to Pleural Effusion Drainage
4. Discussion
5. Conclusions
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Conflicts of Interest
References
- Yu, H. Management of Pleural Effusion, Empyema, and Lung Abscess. Semin. Interv. Radiol. 2011, 28, 075–086. [Google Scholar] [CrossRef] [Green Version]
- Feller-Kopman, D.; Light, R. Pleural Disease. New Engl. J. Med. 2018, 378, 740–751. [Google Scholar] [CrossRef]
- Light, R.W.; George, R.B. Incidence and Significance of Pleural Effusion after Abdominal Surgery. Chest 1976, 69, 621–625. [Google Scholar] [CrossRef]
- Nielsen, P.H.; Jepsen, S.B.; Olsen, A.D. Postoperative Pleural Effusion Following Upper Abdominal Surgery. Chest 1989, 96, 1133–1135. [Google Scholar] [CrossRef] [Green Version]
- Vargas, F.S.; Cukier, A.; Hueb, W.; Teixeira, L.R.; Light, R.W. Relationship Between Pleural Effusion and Pericardial Involvement After Myocardial Revascularization. Chest 1994, 105, 1748–1752. [Google Scholar] [CrossRef] [PubMed]
- Alsaddique, A.; Royse, A.; Royse, C.F.; Mobeirek, A.; El Shaer, F.; AlBackr, H.; Fouda, M.; Canty, D.J. Repeated Monitoring With Transthoracic Echocardiography and Lung Ultrasound After Cardiac Surgery: Feasibility and Impact on Diagnosis. J. Cardiothorac. Vasc. Anesthesia 2016, 30, 406–412. [Google Scholar] [CrossRef] [PubMed]
- Chen, Y.-T.; Wang, C.-T.; Chiu, C.-H.; Chao, Y.-K. Salvage surgery, chylothorax and pneumonia are the main drivers of unplanned readmissions after oesophagectomy for cancer. Eur. J. Cardio-Thoracic Surg. 2021, 59, 1021–1029. [Google Scholar] [CrossRef]
- Vincent, J.L.; Moreno, R.; Takala, J.; Willatts, S.; De Mendonca, A.; Bruining, H.; Reinhart, C.K.; Suter, P.M.; Thijs, L.G. The SOFA (Sepsis-related Organ Failure Assessment) score to describe organ dysfunction/failure. Intensive Care Med. 1996, 22, 707–710. [Google Scholar] [CrossRef] [PubMed]
- Talmor, M.; Hydo, L.; Gershenwald, J.G.; Barie, P.S. Beneficial effects of chest tube drainage of pleural effusion in acute respiratory failure refractory to positive end-expiratory pressure ventilation. Surgery 1998, 123, 137–143. [Google Scholar] [CrossRef]
- Roch, A.; Bojan, M.; Michelet, P.; Romain, F.; Bregeon, F.; Papazian, L.; Auffray, J.-P. Usefulness of Ultrasonography in Predicting Pleural Effusions > 500 mL in Patients Receiving Mechanical Ventilation. Chest 2005, 127, 224–232. [Google Scholar] [CrossRef] [PubMed] [Green Version]
- Walden, A.P.; Garrard, C.S.; Salmon, J. Sustained effects of thoracocentesis on oxygenation in mechanically ventilated patients. Respirology 2010, 15, 986–992. [Google Scholar] [CrossRef]
- Razazi, K.; Thille, A.W.; Carteaux, G.; Beji, O.; Brun-Buisson, C.; Brochard, L.; Dessap, A.M. Effects of Pleural Effusion Drainage on Oxygenation, Respiratory Mechanics, and Hemodynamics in Mechanically Ventilated Patients. Ann. Am. Thorac. Soc. 2014, 11, 1018–1024. [Google Scholar] [CrossRef]
- Brims, F.J.H.; Davies, M.G.; Elia, A.; Griffiths, M.J.D. The effects of pleural fluid drainage on respiratory function in mechanically ventilated patients after cardiac surgery. BMJ Open Respir. Res. 2015, 2, e000080. [Google Scholar] [CrossRef] [Green Version]
- Ahmed, S.H.; Ouzounian, S.P.; DiRusso, S.; Sullivan, T.; Savino, J.; Del Guercio, L. Hemodynamic and Pulmonary Changes after Drainage of Significant Pleural Effusions in Critically Ill, Mechanically Ventilated Surgical Patients. J. Trauma: Inj. Infect. Crit. Care 2004, 57, 1184–1188. [Google Scholar] [CrossRef] [Green Version]
- Doelken, P.; Abreu, R.; Sahn, S.A.; Mayo, P.H. Effect of Thoracentesis on Respiratory Mechanics and Gas Exchange in the Patient Receiving Mechanical Ventilation. Chest 2006, 130, 1354–1361. [Google Scholar] [CrossRef] [PubMed]
- Ali-Hassan-Sayegh, S.; Mirhosseini, S.J.; Vahabzadeh, V.; Ghaffari, N. Should the integrity of the pleura during internal mammary artery harvesting be preserved? Interact. Cardiovasc. Thorac. Surg. 2014, 19, 838–847. [Google Scholar] [CrossRef] [PubMed] [Green Version]
- Vargas, F.S.; Uezumi, K.K.; Janete, F.B.; Terra-Filho, M.; Hueb, W.; Cukier, A.; Light, R.W. Acute pleuropulmonary complications detected by computed tomography following myocardial revascularization. Rev. Hosp. Clín. 2002, 57, 135–142. [Google Scholar] [CrossRef] [PubMed] [Green Version]
- Kalomenidis, I.; Stathopoulos, G.; Barnette, R.; Papiris, S.; Blackwell, T.S.; Roussos, C.; Light, R.W. Vascular endothelial growth factor levels in post-CABG pleural effusions are associated with pleural inflammation and permeability. Respir. Med. 2007, 101, 223–229. [Google Scholar] [CrossRef] [PubMed] [Green Version]
- Khan, A.H. The postcardiac injury syndromes. Clin. Cardiol. 1992, 15, 67–72. [Google Scholar] [CrossRef] [PubMed]
- He, S.; Chen, B.; Li, W.; Yan, J.; Chen, L.; Wang, X.; Xiao, Y. Ventilator-associated pneumonia after cardiac surgery: A meta-analysis and systematic review. J. Thorac. Cardiovasc. Surg. 2014, 148, 3148–3155. [Google Scholar] [CrossRef] [Green Version]
- Razazi, K.; Boissier, F.; Neuville, M.; Jochmans, S.; Tchir, M.; May, F.; De Prost, N.; Brun-Buisson, C.; Carteaux, G.; Dessap, A.M. Pleural effusion during weaning from mechanical ventilation: A prospective observational multicenter study. Ann. Intensiv. Care 2018, 8, 1–10. [Google Scholar] [CrossRef] [PubMed]
- Purro, A.; Appendini, L.; De Gaetano, A.; Guðjónsdóttir, M.; Donner, C.F.; Rossi, A. Physiologic Determinants of Ventilator Dependence in Long-term Mechanically Ventilated Patients. Am. J. Respir. Crit. Care Med. 2000, 161, 1115–1123. [Google Scholar] [CrossRef] [PubMed]
- Li, S.; An, Y.-Z.; Ren, J.-Y.; Zhu, F.-X.; Chen, H. Myocardial Injury after Surgery Is a Risk Factor for Weaning Failure from Mechanical Ventilation in Critical Patients Undergoing Major Abdominal Surgery. PLoS ONE 2014, 9, e113410. [Google Scholar] [CrossRef] [PubMed]
- Laghi, F.; Tobin, M.J. Disorders of the Respiratory Muscles. Am. J. Respir. Crit. Care Med. 2003, 168, 10–48. [Google Scholar] [CrossRef] [PubMed]
Total Patients | |
---|---|
(n = 62) | |
Age (years) | 61.4 ± 13.4 |
Sex (Men/women) | 44/18 |
Body mass index (kg/m2) | 24.1 ± 4.2 |
Opeartion type | |
Cardiovascular or thoracic | 22 (35.5%) |
Abdomen | 32 (51.6%) |
Burn | 2 (3.2%) |
Brain | 1 (1.6%) |
Limbs | 3 (4.8%) |
Neck | 2 (3.2%) |
Side | |
Left | 22 (35.5%) |
Right | 37 (59.7%) |
Bilateral | 3 (4.8%) |
SOFA score | 8.4 ± 3.8 |
Laboratory parameters | |
White blood cells (1000/μL) | 12.9 ± 6.5 |
Platelets (1000/μL) | 160 ± 119 |
Prothrombin time/international normalized ratio | 1.2 ± 0.4 |
Total bilirubin (mg/dL) | 4.1 ± 6.5 |
Creatinine (mg/dL) | 2.2 ± 2.3 |
Arterial blood gas analysis before pleural effusion drainage | |
PaO2/FiO2 ratio (mmHg) | 280 ± 102 |
PaCO2 (mmHg) | 38 ± 7 |
pH | 7.4 ± 0.1 |
Ventilator settings before pleural effusion drainage | |
Peak airway pressure (cmH2O) | 23 ± 5 |
Positive end expiratory pressure (cmH2O) | 8 ± 1 |
Tidal volume/predicted body weight (mL/Kg) | 9 ± 2 |
Respiratory rate (/minute) | 19 ± 4 |
Dynamic driving pressure (cmH2O) | 14 ± 5 |
Dynamic lung compliance (mL/cmH2O) | 40 ± 18 |
Time interval from operation to the onset of pleural effusion (days) | 9 ± 11 |
Time interval from the onset of pleural effusion to pleural effusion drainage (days) | 1.7 ± 1.8 |
Chest ultrasound findings | |
Fluid height (number of intercostal spaces) | 3.5 ± 1.3 |
Fluid depth (cm) | 4.3 ± 1.6 |
Inadequate diaphragm movements | 10 (16.1%) |
Drainage volume (mL) | |
During the first day | 864 ± 493 |
Average per day | 233 ± 168 |
T −1 | T 0 | T +1 | p Value (T −1 vs. T 0) | p Value (T 0 vs. T +1) | |
---|---|---|---|---|---|
PaO2/FiO2 ratio (mmHg) | 300 ± 146 | 280 ± 102 | 319 ± 101 | 0.92 | 0.002 * |
PaCO2 (mmHg) | 38 ± 6 | 38 ± 7 | 37 ± 7 | 0.79 | 0.14 |
pH | 7 ± 0.1 | 7 ± 0.1 | 7 ± 0.1 | 0.42 | 0.13 |
Peak airway pressure (cmH2O) | 23 ± 5 | 23 ± 5 | 22 ± 6 | 0.13 | 0.01 * |
Positive end expiratory pressure (cmH2O) | 9 ± 1 | 8 ± 1 | 8 ± 1 | 0.78 | 0.74 |
Tidal volume/predict body weight (mL/Kg) | 9 ± 2 | 9 ± 2 | 9 ± 2 | 0.20 | 0.35 |
Respiratory rate (per min) | 18 ± 4 | 18 ± 4 | 18 ± 4 | 0.59 | 0.26 |
Dynamic driving pressure (cmH2O) | 15 ± 4 | 14 ± 5 | 13 ± 5 | 0.10 | 0.008 * |
Dynamic lung compliance (mL/cmH2O) | 37 ± 12 | 40 ± 18 | 46 ± 21 | 0.22 | 0.003 * |
Univariate Analysis | Multivariable Analysis | |||
---|---|---|---|---|
Odds Ratio (95% CI) | p | Odds Ratio (95% CI) | p | |
Sex | ||||
Woman | 1 (reference) | |||
Man | 0.8 (0.3–2.6) | 0.75 | ||
Age, per 1 year increment | 1.01 (0.97–1.05) | 0.51 | ||
Body mass index, per 1 kg/m2 increament | 1.08 (0.95–1.23) | 0.22 | ||
Operation type | ||||
Cardiovascular or thoracic | 1 (reference) | 1 (reference) | ||
Others | 3.00 (1.02–8.80) | 0.046 * | 4.97 (1.03–24.04) | 0.046 * |
SOFA score, per 1 increment | 1.09 (0.95–1.25) | 0.24 | ||
Time interval from operation to the onset of pleural effusion, per 1 day increment | 1.10 (1.02–1.19) | 0.013 * | 1.16 (1.05–1.30) | 0.005 * |
Time interval from the onset of pleural effusion to pleural effusion drainage, per 1 day increment | 1.5 (0.90–1.74) | 0.19 | ||
Average pleural effusion drainage volume per day, per 1 mL increament | 0.999 (0.996–1.002) | 0.63 | ||
Laboratory parameters | ||||
PT/INR, per 1 increament | 1.08 (0.28–4.19) | 0.91 | ||
Blood gas analyses and respiratory mechanics before pleural effusion drainage | ||||
Positive end expiratory pressure, per 1 cm H2O increment | 1.47 (0.97–2.23) | 0.07 | 1.36 (0.65–2.86) | 0.42 |
Peak airway pressure, per 1 cm H2O increment | 1.17 (1.05–1.31) | 0.004 * | 1.30 (1.07–1.59) | 0.009 * |
Inadequate diaphragm movements | ||||
No | 1 (reference) | 1 (reference) | ||
Yes | 8.33 (0.98–70.57) | 0.05 | 13.44 (0.59–304.68) | 0.10 |
≤6 Days (n = 36) | >6 Days (n = 26) | |||||
---|---|---|---|---|---|---|
T 0 | T +1 | p Value | T 0 | T +1 | p Value | |
PaO2/FiO2 ratio (mmHg) | 278 ± 122 | 338 ± 118 | 0.006 * | 281 ± 79 | 296 ± 71 | 0.22 |
PaCO2 (mmHg) | 39 ± 8 | 36 ± 7 | 0.07 | 38 ± 5 | 38 ± 7 | 0.46 |
pH | 7 ± 0.1 | 7 ± 0.1 | 0.04 * | 7 ± 0.1 | 7 ± 0.1 | 0.32 |
Peak airway pressure (cmH2O) | 23 ± 5 | 21 ± 5 | 0.002 * | 23 ± 6 | 22 ± 7 | 0.81 |
Positive end expiratory pressure (cmH2O) | 8 ± 1 | 8 ± 1 | 0.66 | 9 ± 2 | 9 ± 2 | >0.99 |
Tidal volume/predict body weight (mL/Kg) | 9 ± 2 | 9 ± 2 | 0.80 | 9 ± 1 | 9 ± 1 | 0.26 |
Respiratory rate (per min) | 19 ± 5 | 17 ± 3 | 0.04 * | 18 ± 3 | 19 ± 5 | 0.51 |
Dynamic driving pressure (cmH2O) | 15 ± 5 | 13 ± 4 | 0.002 * | 14 ± 5 | 14 ± 6 | 0.81 |
Dynamic lung compliance (mL/ cmH2O) | 39 ± 18 | 46 ± 21 | 0.007 * | 41 ± 18 | 47 ± 22 | 0.17 |
