ResUNet: Application of Deep Learning in Quantitative Characterization of 3D Structures in Iron Ore Pellets
Abstract
:1. Introduction
2. Summary of Previous Research
3. Materials and Methods
3.1. Data Preparation
3.2. ResUNet Network Structure
3.2.1. Encoder
3.2.2. Bridge
3.2.3. Decoder
3.3. Image Augmentation
3.4. Image Normalization
3.5. Experimental Details
3.6. Evaluation Metrics
4. Results
4.1. Model Evaluation
4.2. Comparative Experiments and Analysis of Segmentation Methods
4.2.1. Multi-Otsu Thresholding Method
4.2.2. Basic U-Net Architecture
4.2.3. Experimental Results and Analysis
4.3. Model Robustness Analysis
4.4. Reliability Analysis of Phase Identification
4.5. Model Application
4.5.1. Three-Dimensional Reconstruction
4.5.2. Quantitative Analysis
Volume Fraction
Fractal Dimension
4.6. Effect of Spatial Resolution on Segmentation Results
5. Conclusions
Supplementary Materials
Author Contributions
Funding
Data Availability Statement
Acknowledgments
Conflicts of Interest
References
