Land Consumption Classification Using Sentinel 1 Data: A Systematic Review
Abstract
:1. Introduction
Goal of This Study
2. Background Analysis
2.1. Fundamentals on Land Consumption
“a phenomenon associated with the loss of an important environmental resource: agricultural, natural, or semi-natural land. The phenomenon refers to an increase of the artificial covering of the ground, due to settlement dynamics. It is defined as a change from a non-artificial covering (unconsumed land) to an artificial covering of the soil (consumed land)”
2.2. Fundamentals on SAR Images and Sentinel-1 Mission
3. Materials and Methods
- Type of analysis conducted (e.g., mapping, classification or change detection);
- Software used (e.g., SNAP, ENVI, etc.);
- Methodologies implemented (e.g., combining Radar and Geospatial Big Data, integrating SAR and Optical data, considering Sentinel-1 features, etc.);
- Algorithms applied (e.g., supervised/unsupervised Machine Learning (ML) algorithms, Bayesian Algorithms, Object/Pixel-Based learning algorithms, etc.);
- Study areas considered (e.g., local/city scale, national scale, global scale, etc.);
- Dataset considered (e.g., orbits, spatial and temporal resolution, number of images, etc.);
- Results obtained (e.g., overall accuracy, k-index, producer accuracy, visual analysis accuracy, etc.);
- Potential issues and gained benefits.
4. Analysis of Existing Approaches to Map Land Consumption with Sentinel-1 Images
4.1. Study Area, Dataset, and Software
4.2. Methodologies
- Type A—Land consumption mapping combining SAR and Geospatial Big Data;
- Type B—Land consumption change detection;
- Type C—Land consumption mapping using data fusion or data integration;
- Type D—Land consumption mapping using approaches considering only Sentinel-1 image features.
4.2.1. Type A—Land Consumption Mapping Combining SAR and Geospatial Big Data
4.2.2. Type B—Land Consumption Change Detection
4.2.3. Type C—Land Consumption Mapping Using Data Fusion or Data Integration
4.2.4. Type D—Land Consumption Mapping Using Approaches Considering Only Sentinel-1 Image Features
Paper | Type | Method | Mode | Algorithms/ Techniques | Accuracy Assessment | Advantages | Disadvantages |
---|---|---|---|---|---|---|---|
[63] | A | Object-based | Supervised | Segmentation algorithm Decision tree RF | OA: 91.55% K: 0.89 | Reduced confusion between greenhouses and vegetation thanks to the population density (in urban areas higher than in vegetation areas). | Availability of Social Media data. |
[17] | A–C | Pixel-based | Supervised | RF; K-means | OA: various | Possible use for global scale. | Several accuracies (different cities considered). Availability of global population data (GHS-POP). Low accuracy if considering cities different from trained ones. |
[1] | B | Pixel-based | Unsupervised | Bayesian algorithm | Visual analysis | This approach is simple, unsupervised, automatic, and feasible for users who are not experts in the field. | Changes are not detected whenever the new objects are characterized by low amplitude, such as a street, a square, or a set of solar panels. |
[56] | B | Pixel-based | Unsupervised | NDVI applicated to optical images; Median backscattering; Photointerpretation | OA: 97.7–99.66% | High accuracy. Global scale. | Arbitrariness of thresholds. |
[70] | B | Pixel-based | Unsupervised | MDADT | Visual analysis | Use only SAR data, consider large area, and long time period. | Only detected medium-term land cover changes. Small changes were not recorded due to the spatial resolution of Sentinel-1 images. |
[61] | B–C | Pixel-based | Supervised | SVM with radial bases | S1: OA = 96% K = 0.942 S1-S2: OA = 96% K = 0.942 | Data are integrated and harmonized, thus obtaining a very accurate result for a city with a complex and heterogeneous urban pattern. These new products offer support for conducting spatial and statistical analysis for changes that occurred in the urban landscape. | Limited number of classes that can be extracted due to the similar spectral signature of some classes. |
[55] | B | Pixel-based | Unsupervised | NDVI applicated to optical images; Median backscattering; Photointerpretation | OA: various | Global scale. No training areas. Time and cost-effective. | Omissions are mainly related to the smallest changes, which are less than one pixel in size. Could be detected false or not permanent changes. |
[64] | C | Pixel-based | Supervised | RF | OA: 85–98% K: 0.8–1 | The technique would mainly benefit urban areas with open spaces within the settlement due to higher spatial resolution of Sentinel data despite the urban density. | To replicate the process in tropical regions would be challenging, being S-2 data constantly contaminated with cloud covers. For a larger study area, the method can be computationally time consuming. |
[71] | C | Pixel-based | Supervised | SVM-CK | OA = 92.12% K = 0.89 | The fusion of Sentinel-2B MSI and Sentinel-1A SAR data efficiently improve land cover classification in cloud-prone regions. | Possible misclassification. |
[65] | C | Pixel-based | Supervised | MKSVR | RMSE: 0.2031 R2: 0.8321 | Improved accuracy compared with the same method using optical image alone. | Setting parameters. Computational efficiency. |
[66] | C | Pixel-based | Supervised | RF | S2:OA: 95% S1-S2:OA: 91% | - | Salt and pepper effect improved the mixed image classification, and overall accuracy and k coefficient have been reduced to respect multispectral S2 classification. |
[72] | C | Object-based | Supervised | S1: MLC, RF S2: SLIC | OA: 90% | Free and open access data. The ability to follow high-resolution details in a mixed environment. A low number of calibration parameters is required, reducing tuning sensitivity. | Urban pixels surrounded by many not-urban pixels will be misclassified. Inconsistencies of Sentinel 2. Quite complex approach. |
[78] | C | Pixel-based | Supervised | SML | Visual analysis | The capacity to handle different sets of input features, such as radiometric, textural, and morphological descriptors. The distinction between built-up areas and fluvial gravel, similar in terms of radiometric characteristics but having different surface roughness becomes possible. | Highways are not detected. Underestimate the built-up surfaces in high density areas where shadows hamper the automated classification. |
[57] | C | Object-based | Unsupervised | S2: Super-pixel segmentation; S1: Fuzzy C-Mean | OA: 88–95% K: 0.58–0.61 | The SAR features are tuned to detect high concentrations of permanent scatterers and stable targets. Unsupervised classification: no training dataset used, making the proposed solution applicable worldwide. Frequently updated. | Object-based approach limits the size of the smallest detail. Roads are narrow surfaces without any double-bounce scattering mechanisms (usually) and are surrounded by decorrelating targets, causing difficulties in their classification. |
[83] | C | Pixel-based | Supervised | RF | F1 score: 0.81–0.98; K-fold Cross Validation (CV): 0.90–0.95 | RF class probabilities were post-processed using a simple mean filter with a 3 × 3 window size. This allowed a partial removal of noise, illumination artifacts, and roads. | Availability of data since the long period considered. Lots of training samples. |
[68] | C | Pixel-based | Supervised | RF | OA: 99% K: 0.98 | High accuracy. | Impact of seasonality in urban land cover mapping. |
[60] | C | Pixel-based | Supervised | RF | OA: 92–95% K: 0.88–0.92 | High accuracys. | Slight underestimation of impervious surface for the city. |
[59] | C | Pixel-based | Supervised | UEXT | OA: 75-82% K: 0.5–0.65 | Overcome limits in mountainous regions, often erroneously identified as urban structures. Reduces number of false positives. Low computational demand. Higher repeatability over a long time. | Low accuracy. |
[69] | C | Pixel-based | Supervised | Multi-Attention Module Hybrid CNN (MAMHybridNet) | OA: 98.87 K: 0.98 | Good performance in high surface humidity, cloud cover, and foggy weather. High accuracy. | Quite complex model. |
[49] | D | Pixel-based\ | Unsupervised | MLC; ISODATA + Texture analyses | MLC: K < 0.80 ISO-TEX: K > 0.80 | Higher accuracy level compared to the supervised classification. | MLC: The confusions between the urban and non-urban were detected in the high backscatter areas. The disparities occur especially on more extended, excessively humid, or bare soil areas. ISO-TEX: the spectral response was explored on all 20 bands by land use classes that are narrow enough to capture a particular classification problem. |
[74] | D | Pixel-based | Unsupervised | Hierarchical Split Based Approach | Visual analysis | Reduces shadow and layover areas. Removes the permanent water bodies. Reduce false alarms. | Limited geometric resolution of the Sentinel satellites with respect to other commercial satellites. |
[85] | D | Pixel-based | Unsupervised | Hierarchical Spilt Based thresholding approach (HSBA) | OA: 91–97% | Reduces the speckle without losing spatial resolution. | Limited geometric resolution of the Sentinel satellites with respect to other commercial satellites. |
[58] | D | Pixel-based | Supervised | MLC; SVM | SVM: K = 0.72 ML: K = 0.61 | Good performance in separating water bodies. | Better accuracy only in semi-arid areas (due to low atmospheric turbulences). Backscattering coefficient may differ based on the geometric orientation of the objects. |
[62] | D | Pixel-based | Supervised; Unsupervised | MLC; RD; K-means | OA: 85–90% Visual analysis | Completely based on Open data. | Limited geometric resolution of the Sentinel satellites with respect to other commercial satellites. |
[48] | D | Pixel-based | Unsupervised | Hierarchical Spilt Based tresholding approach (HSBA) | OA: 91.55–97.93% K: 0.29–0.47 | Reduces shadow and layover areas. Reduces the speckle without losing spatial resolution. Reduces false alarms. | Variability of accuracies. Limited geometric resolution of the Sentinel satellites with respect to other commercial satellites. |
5. Conclusions
Author Contributions
Funding
Data Availability Statement
Conflicts of Interest
References
- Mastrorosa, S.; Crosetto, M.; Congedo, L.; Munafò, M. Land consumption monitoring: An innovative method integrating SAR and optical data. Environ. Monit. Assess. 2018, 190, 588. [Google Scholar] [CrossRef] [PubMed]
- European Commission. Soil Deal for Europe; Publications Office of the European Union: Luxemburg, 2022. [Google Scholar] [CrossRef]
- European Commission. Future Brief: No Net Land Take by 2050? European Union: Luxemburg, 2016. [Google Scholar] [CrossRef]
- EU Missions in Horizon Europe. Available online: https://research-and-innovation.ec.europa.eu/funding/funding-opportunities/funding-programmes-and-open-calls/horizon-europe/eu-missions-horizon-europe_en (accessed on 31 October 2022).
- EEA. Land and Soil in Europe; Luxembourg Publications Office of the European Union: Luxemburg, 2020. [Google Scholar] [CrossRef]
- FAO. Urbanisation and Soil Sealing; FAO: Rome, Italy, 2022. [Google Scholar]
- Munafò, M. “Consumo Di Suolo, Dinamiche Territoriali e Servizi Ecosistemici”. 2022. Report ISPRA-SNPA 32/22. Available online: https://www.snpambiente.it/2022/07/26/consumo-di-suolo-dinamiche-territoriali-e-servizi-ecosistemici-edizione-2022/ (accessed on 9 January 2023).
- Shang, R.; Yuan, Y.; Jiao, L.; Meng, Y.; Ghalamzan, A.M. A self-paced learning algorithm for change detection in synthetic aperture radar images. Signal Process. 2018, 142, 375–387. [Google Scholar] [CrossRef]
- Sumaiya, M.; Kumari, R.S.S. Gabor filter based change detection in SAR images by KI thresholding. Optik 2017, 130, 114–122. [Google Scholar] [CrossRef]
- Marinelli, D.; Bovolo, F.; Bruzzone, L. A Novel Change Detection Method for Multitemporal Hyperspectral Images Based on Binary Hyperspectral Change Vectors. IEEE Trans. Geosci. Remote. Sens. 2019, 57, 4913–4928. [Google Scholar] [CrossRef]
- Khorram, S.; Koch, F.H.; Wiele, C.; Nelson, S.A.C. Remote Sensing; Springer Science & Business Media: Berlin/Heidelberg, Germany, 2012; ISBN 978-1-4614-3102-2. [Google Scholar]
- Congedo, L.; Marinosci, I.; Ritano, N.; Strollo, A.; De Fioravante, P.; Munafò, M. Monitoring of Land Consumption: An Analysis of Loss of Natural and Agricultural Areas in Italy. Annali. Botanica. 2017, 7, 1–9. [Google Scholar] [CrossRef]
- Lam, N.S.-N. Methodologies for Mapping Land Cover/Land Use and its Change. Adv. Land Remote Sens. Syst. Model. Invers. Appl. 2008, 341–367. [Google Scholar] [CrossRef]
- As-Syakur, A.R.; Adnyana, I.W.S.; Arthana, I.W.; Nuarsa, I.W. Enhanced Built-Up and Bareness Index (EBBI) for Mapping Built-Up and Bare Land in an Urban Area. Remote. Sens. 2012, 4, 2957–2970. [Google Scholar] [CrossRef]
- Sun, Z.; Wang, C.; Guo, H.; Shang, R. A Modified Normalized Difference Impervious Surface Index (MNDISI) for Automatic Urban Mapping from Landsat Imagery. Remote. Sens. 2017, 9, 942. [Google Scholar] [CrossRef]
- Hagenauer, J.; Omrani, H.; Helbich, M. Assessing the performance of 38 machine learning models: The case of land consumption rates in Bavaria, Germany. Int. J. Geogr. Inf. Sci. 2019, 33, 1399–1419. [Google Scholar] [CrossRef]
- Hu, J.; Wang, Y.; Taubenböck, H.; Zhu, X.X. Land consumption in cities: A comparative study across the globe. Cities 2021, 113, 103163. [Google Scholar] [CrossRef]
- Gómez, C.; White, J.C.; Wulder, M.A. Optical remotely sensed time series data for land cover classification: A review. ISPRS J. Photogramm. Remote. Sens. 2016, 116, 55–72. [Google Scholar] [CrossRef]
- Khatami, R.; Mountrakis, G.; Stehman, S.V. A meta-analysis of remote sensing research on supervised pixel-based land-cover image classification processes: General guidelines for practitioners and future research. Remote. Sens. Environ. 2016, 177, 89–100. [Google Scholar] [CrossRef]
- Ma, L.; Li, M.; Ma, X.; Cheng, L.; Du, P.; Liu, Y. A review of supervised object-based land-cover image classification. ISPRS J. Photogramm. Remote. Sens. 2017, 130, 277–293. [Google Scholar] [CrossRef]
- MohanRajan, S.N.; Loganathan, A.; Manoharan, P. Survey on Land Use/Land Cover (LU/LC) change analysis in remote sensing and GIS environment: Techniques and Challenges. Environ. Sci. Pollut. Res. 2020, 27, 29900–29926. [Google Scholar] [CrossRef]
- Phiri, D.; Simwanda, M.; Salekin, S.; Nyirenda, V.R.; Murayama, Y.; Ranagalage, M. Sentinel-2 Data for Land Cover/Use Mapping: A Review. Remote. Sens. 2020, 12, 2291. [Google Scholar] [CrossRef]
- Phiri, D.; Morgenroth, J. Developments in Landsat Land Cover Classification Methods: A Review. Remote. Sens. 2017, 9, 967. [Google Scholar] [CrossRef]
- Shafique, A.; Cao, G.; Khan, Z.; Asad, M.; Aslam, M. Deep Learning-Based Change Detection in Remote Sensing Images: A Review. Remote. Sens. 2022, 14, 871. [Google Scholar] [CrossRef]
- Yan, W.Y.; Shaker, A.; El-Ashmawy, N. Urban land cover classification using airborne LiDAR data: A review. Remote Sens. Environ. 2015, 158, 295–310. [Google Scholar] [CrossRef]
- Yin, J.; Dong, J.; Hamm, N.A.; Li, Z.; Wang, J.; Xing, H.; Fu, P. Integrating remote sensing and geospatial big data for urban land use mapping: A review. Int. J. Appl. Earth Obs. Geoinf. 2021, 103, 102514. [Google Scholar] [CrossRef]
- Chatterjee, U.; Majumdar, S. Impact of land use change and rapid urbanization on urban heat island in Kolkata city: A remote sensing based perspective. J. Urban Manag. 2021, 11, 59–71. [Google Scholar] [CrossRef]
- Dong, J.; Zhang, Z.; Da, X.; Zhang, W.; Feng, X. Eco-environmental effects of land use transformation and its driving forces from the perspective of “production-living-ecological” spaces: A case study of Gansu Province. Acta Ecol. Sin. 2021, 41, 5919–5928. [Google Scholar] [CrossRef]
- EEA. Urban Soil Sealing in Europe. 2011. Available online: https://www.eea.europa.eu/articles/urban-soilsealing-in-europe (accessed on 20 December 2022).
- Adhikari, K.; Hartemink, A.E. Linking soils to ecosystem services—A global review. Geoderma 2016, 262, 101–111. [Google Scholar] [CrossRef]
- Scalenghe, R.; Marsan, F.A. The anthropogenic sealing of soils in urban areas. Landsc. Urban Plan. 2009, 90, 1–10. [Google Scholar] [CrossRef]
- Giuffré, G.; Ricci, A.; Bisoffi, S.; Dönitz, E.; Voglhuber-Slavinsky, A.; Helming, K.; Evgrafova, A.; Ratinger, T.; Robinson, D.A. Mission Area: Soil Health and Food: Foresight on Demand Brief in Support of the Horizon Europe Mission Board; Publications Office of the European Union: Luxembourg, 2021. [Google Scholar] [CrossRef]
- Intergovernmental Panel on Climate Change (IPCC). Climate change 2022: The physical science basis. In Contribution of Working Group I to the Fourth Assessment Report of the Intergovernmental Panel on Climate Change 2022; Cambridge University Press: Cambridge, UK, 2022. [Google Scholar]
- Murata, T.; Kawai, N. Degradation of the urban ecosystem function due to soil sealing: Involvement in the heat island phenomenon and hydrologic cycle in the Tokyo metropolitan area. Soil Sci. Plant Nutr. 2018, 64, 145–155. [Google Scholar] [CrossRef]
- Scheyer, J.M.; Hipple, K. Urban Soil Primer; Natural Resources Conservation Service: Washington, DC, USA, 2005. [Google Scholar]
- Hameed, H.M. Estimating the Effect of Urban Growth on Annual Runoff Volume Using GIS in the Erbil Sub-Basin of the Kurdistan Region of Iraq. Hydrology 2017, 4, 12. [Google Scholar] [CrossRef]
- European Commission. Guidlines on Best Pratice to Limit, Mitigate or Compensate Soil Sealing; Publications Office of the European Union: Luxembourg, 2012. [Google Scholar]
- Sultan, H.; Rashid, W.; Shi, J.; Rahim, I.U.; Nafees, M.; Bohnett, E.; Rashid, S.; Khan, M.T.; Shah, I.A.; Han, H.; et al. Horizon Scan of Transboundary Concerns Impacting Snow Leopard Landscapes in Asia. Land 2022, 11, 248. [Google Scholar] [CrossRef]
- United Nations, Department of Economic and Social Affairs. Population Division (2019). In World Urbanization Prospects: The 2018 Revision; United Nations: New York, NY, USA, 2019; ISBN 978-92-1-148319-2. [Google Scholar]
- Ghildiyal, S.; Goel, N.; Saini, M. Cloud Removal in Satellite Imagery Using Adversarial Network and RGB-Optical Data Fusion. In Proceedings of the 2022 IEEE 5th International Conference on Multimedia Information Processing and Retrieval (MIPR), Virtual, 2–4 August 2022; pp. 407–412. [Google Scholar] [CrossRef]
- Richards, J.A.; Jia, X. Remote Sensing Digital Image Analysis: An introduction, 4th ed.; Springer: Berlin/Heidelberg, Germany, 2006; ISBN 3-540-25128-6. [Google Scholar]
- Pandey, P.C.; Koutsias, N.; Petropoulos, G.P.; Srivastava, P.K.; Ben Dor, E. Land use/land cover in view of earth observation: Data sources, input dimensions, and classifiers—A review of the state of the art. Geocarto Int. 2021, 36, 957–988. [Google Scholar] [CrossRef]
- Gomez-Chova, L.; Fernández-Prieto, D.; Calpe, J.; Soria, E.; Vila, J.; Camps-Valls, G. Urban monitoring using multi-temporal SAR and multi-spectral data. Pattern Recognit. Lett. 2005, 27, 234–243. [Google Scholar] [CrossRef]
- Zhu, Z.; Woodcock, C.E.; Rogan, J.; Kellndorfer, J. Assessment of spectral, polarimetric, temporal, and spatial dimensions for urban and peri-urban land cover classification using Landsat and SAR data. Remote. Sens. Environ. 2012, 117, 72–82. [Google Scholar] [CrossRef]
- Angelis, C.F.; Freitas, C.C.; Valeriano, D.M.; Dutra, L.V. Multitemporal analysis of land use/land cover JERS-1 backscatter in the Brazilian tropical rainforest. Int. J. Remote. Sens. 2002, 23, 1231–1240. [Google Scholar] [CrossRef]
- Satalino, G.; Impedovo, D.; Balenzano, A.; Mattia, F. Land cover classification by using multi-temporal COSMO-SkyMed data. In Proceedings of the 2011 6th International Workshop on the Analysis of Multi-Temporal Remote Sensing Images, Multi-Temp 2011, Trento, Italy, 12–14 July 2011; pp. 17–20. [Google Scholar] [CrossRef]
- Yousif, O.; Ban, Y. Object-Based Change Detection in Urban Areas Using Multitemporal High Resolution SAR Images with Unsupervised Thresholding Algorithms. Remote Sens. Digit. Image Process. 2016, 20, 89–105. [Google Scholar] [CrossRef]
- Chini, M.; Pelich, R.; Hostache, R.; Matgen, P.; Lopez-Martinez, C. Towards a 20 m Global Building Map from Sentinel-1 SAR Data. Remote. Sens. 2018, 10, 1833. [Google Scholar] [CrossRef]
- Holobâcă, I.-H.; Ivan, K.; Alexe, M. Extracting built-up areas from Sentinel-1 imagery using land-cover classification and texture analysis. Int. J. Remote. Sens. 2019, 40, 8054–8069. [Google Scholar] [CrossRef]
- Che, M.; Vizziello, A.; Gamba, P. Spatio-Temporal Urban Change Mapping With Time-Series SAR Data. IEEE J. Sel. Top. Appl. Earth Obs. Remote. Sens. 2022, 15, 7222–7234. [Google Scholar] [CrossRef]
- Che, M.; Gamba, P. Urban Change Pattern Exploration Using Fine-resolution SAR of Ascending and Descending Orbits. In Proceedings of the 2020 IEEE Radar Conference (RadarConf20), Florence, Italy, 21–25 September 2020. [Google Scholar] [CrossRef]
- ESA. Sentinel-1. 2021. Available online: https://sentinels.copernicus.eu/web/sentinel/missions/sentinel-1 (accessed on 24 November 2022).
- Fletcher, K.; European Space Agency. Sentinel-1: ESA’s Radar Observatory Mission for GMES Operational Services (ESA SP-1322/1, March 2012); ESA Communications: Noordwijk, The Netherlands, 2012; ISBN 978-92-9221-418-0. [Google Scholar]
- NASA ARSET. Basics of Synthetic Aperture Radar (SAR), Session ¼. 2018. Available online: https://www.youtube.com/watch?v=Xemo2ZpduHA (accessed on 24 November 2022).
- Luti, T.; De Fioravante, P.; Marinosci, I.; Strollo, A.; Riitano, N.; Falanga, V.; Mariani, L.; Congedo, L.; Munafò, M. Land Consumption Monitoring with SAR Data and Multispectral Indices. Remote. Sens. 2021, 13, 1586. [Google Scholar] [CrossRef]
- Strollo, A.; Smiraglia, D.; Bruno, R.; Assennato, F.; Congedo, L.; De Fioravante, P.; Giuliani, C.; Marinosci, I.; Riitano, N.; Munafò, M. Land consumption in Italy. J. Maps 2020, 16, 113–123. [Google Scholar] [CrossRef]
- Petrushevsky, N.; Manzoni, M.; Monti-Guarnieri, A. Fast Urban Land Cover Mapping Exploiting Sentinel-1 and Sentinel-2 Data. Remote. Sens. 2021, 14, 36. [Google Scholar] [CrossRef]
- Ghasemi, M.; Karimzadeh, S.; Feizizadeh, B. Urban classification using preserved information of high dimensional textural features of Sentinel-1 images in Tabriz, Iran. Earth Sci. Informatics 2021, 14, 1745–1762. [Google Scholar] [CrossRef]
- Iannelli, G.C.; Gamba, P. Jointly exploiting sentinel-1 and sentinel-2 for urban mapping. In Proceedings of the International Geoscience and Remote Sensing Symposium (IGARSS), Valencia, Spain, 22–27 July 2018; pp. 8209–8212. [Google Scholar] [CrossRef]
- Shrestha, B.; Ahmad, S.; Stephen, H. Fusion of Sentinel-1 and Sentinel-2 data in mapping the impervious surfaces at city scale. Environ. Monit. Assess. 2021, 193, 556. [Google Scholar] [CrossRef]
- Nistor, C.; Vîrghileanu, M.; Cârlan, I.; Mihai, B.-A.; Toma, L.; Olariu, B. Remote Sensing-Based Analysis of Urban Landscape Change in the City of Bucharest, Romania. Remote. Sens. 2021, 13, 2323. [Google Scholar] [CrossRef]
- Semenzato, A.; Pappalardo, S.E.; Codato, D.; Trivelloni, U.; De Zorzi, S.; Ferrari, S.; De Marchi, M.; Massironi, M. Mapping and Monitoring Urban Environment through Sentinel-1 SAR Data: A Case Study in the Veneto Region (Italy). ISPRS Int. J. Geo-Inf. 2020, 9, 375. [Google Scholar] [CrossRef]
- Shi, Y.; Qi, Z.; Liu, X.; Niu, N.; Zhang, H. Urban Land Use and Land Cover Classification Using Multisource Remote Sensing Images and Social Media Data. Remote. Sens. 2019, 11, 2719. [Google Scholar] [CrossRef]
- Shrestha, B.; Stephen, H.; Ahmad, S. Impervious Surfaces Mapping at City Scale by Fusion of Radar and Optical Data through a Random Forest Classifier. Remote. Sens. 2021, 13, 3040. [Google Scholar] [CrossRef]
- Sun, G.; Kong, Y.; Jia, X.; Zhang, A.; Rong, J.; Ma, H. Synergistic Use of Optical and Dual-Polarized SAR Data With Multiple Kernel Learning for Urban Impervious Surface Mapping. IEEE J. Sel. Top. Appl. Earth Obs. Remote. Sens. 2019, 12, 223–236. [Google Scholar] [CrossRef]
- Tsolakidis, I.; Vafiadis, M. Urban land cover mapping, using open satellite data. Case study of the municipality of Thessaloniki. IOP Conf. Series Earth Environ. Sci. 2020, 410, 012062. [Google Scholar] [CrossRef]
- Kamusoko, C. Improving Urban Land Cover Mapping; Springer Geography: Berlin/Heidelberg, Germany, 2022; pp. 89–103. [Google Scholar] [CrossRef]
- Zhou, T.; Li, Z.; Pan, J. Multi-Feature Classification of Multi-Sensor Satellite Imagery Based on Dual-Polarimetric Sentinel-1A, Landsat-8 OLI, and Hyperion Images for Urban Land-Cover Classification. Sensors 2018, 18, 373. [Google Scholar] [CrossRef]
- Yang, Z.; Zhang, H.; Lyu, X.; Du, W. Improving Typical Urban Land-Use Classification with Active-Passive Remote Sensing and Multi-Attention Modules Hybrid Network: A Case Study of Qibin District, Henan, China. Sustainability 2022, 14, 14723. [Google Scholar] [CrossRef]
- Gruenhagen, L.; Juergens, C. Multitemporal Change Detection Analysis in an Urbanized Environment Based upon Sentinel-1 Data. Remote. Sens. 2022, 14, 1043. [Google Scholar] [CrossRef]
- Hu, B.; Xu, Y.; Huang, X.; Cheng, Q.; Ding, Q.; Bai, L.; Li, Y. Improving Urban Land Cover Classification with Combined Use of Sentinel-2 and Sentinel-1 Imagery. ISPRS Int. J. Geo-Inf. 2021, 10, 533. [Google Scholar] [CrossRef]
- Petrushevsky, N.; Manzoni, M.; Guarnieri, A.M. High-Resolution Urban Mapping By Fusion Of Sar And Optical Data. ISPRS Int. Arch. Photogramm. Remote. Sens. Spat. Inf. Sci. 2021, 43, 273–278. [Google Scholar] [CrossRef]
- Ma, L.; Liu, Y.; Zhang, X.; Ye, Y.; Yin, G.; Johnson, B.A. Deep learning in remote sensing applications: A meta-analysis and review. ISPRS J. Photogramm. Remote Sens. 2019, 152, 166–177. [Google Scholar] [CrossRef]
- Chini, M.; Pelich, R.; Hostache, R.; Matgen, P. Built-up areas mapping at global scale based on adaptive parametric thresholding of Sentinel-1 intensity & coherence time series. In Proceedings of the 2017 9th International Workshop on the Analysis of Multitemporal Remote Sensing Images, Brugge, Belgium, 27–29 June 2017. [Google Scholar] [CrossRef]
- Ravishanker, N.; O’Ruanaidh, J.J.K.; Fitzgerald, W.J. Numerical Bayesian Methods Applied to Signal Processing. J. Am. Stat. Assoc. 1997, 92, 1646. [Google Scholar] [CrossRef]
- Koeniguer, E.C.; Nicolas, J.-M. Change Detection Based on the Coefficient of Variation in SAR Time-Series of Urban Areas. Remote. Sens. 2020, 12, 2089. [Google Scholar] [CrossRef]
- Weng, Q. Remote sensing of impervious surfaces in the urban areas: Requirements, methods, and trends. Remote. Sens. Environ. 2012, 117, 34–49. [Google Scholar] [CrossRef]
- Pesaresi, M.; Corbane, C.; Julea, A.; Florczyk, A.J.; Syrris, V.; Soille, P. Assessment of the Added-Value of Sentinel-2 for Detecting Built-up Areas. Remote. Sens. 2016, 8, 299. [Google Scholar] [CrossRef]
- Lisini, G.; Salentinig, A.; Du, P.; Gamba, P. SAR-Based Urban Extents Extraction: From ENVISAT to Sentinel-1. IEEE J. Sel. Top. Appl. Earth Obs. Remote Sens. 2017, 11, 2683–2691. [Google Scholar] [CrossRef]
- Sun, G.; Cheng, J.; Zhang, A.; Jia, X.; Yao, Y.; Jiao, Z. Hierarchical fusion of optical and dual-polarized SAR on impervious surface mapping at city scale. ISPRS J. Photogramm. Remote. Sens. 2022, 184, 264–278. [Google Scholar] [CrossRef]
- Zhang, J.; Yang, J.; Zhao, Z.; Li, H.; Zhang, Y. Block-regression based fusion of optical and SAR imagery for feature enhancement. Int. J. Remote. Sens. 2010, 31, 2325–2345. [Google Scholar] [CrossRef]
- Gu, Y.; Wang, Q.; Jia, X.; Benediktsson, J.A. A Novel MKL Model of Integrating LiDAR Data and MSI for Urban Area Classification. IEEE Trans. Geosci. Remote. Sens. 2015, 53, 5312–5326. [Google Scholar] [CrossRef]
- Forget, Y.; Shimoni, M.; Gilbert, M.; Linard, C. Mapping 20 Years of Urban Expansion in 45 Urban Areas of Sub-Saharan Africa. Remote. Sens. 2021, 13, 525. [Google Scholar] [CrossRef]
- Boudinaud, L. Mapping Urban Area with Sentinel-1 Data: A Tutorial Using SNAP and SCP for QGIS. Available online: https://fromgistors.blogspot.com/2017/04/mapping-urban-area-with-sentinel-1-data.html (accessed on 16 December 2022).
- Chini, M.; Pelich, R.; Hostache, R.; Matgen, P.; Lopez-Martinez, C. Polarimetric and multitemporal information extracted from sentinel-1 SAR data to map buildings. In Proceedings of the International Geoscience and Remote Sensing Symposium (IGARSS), Valencia, Spain, 22–27 July 2018; pp. 8132–8134. [Google Scholar] [CrossRef]
- Org, S.U. Transforming Our World: The 2030 Agenda for Sustainable Development; United Nations: New York, NY, USA, 2015. [Google Scholar]
Interferometric Wide-Swath Mode (IW) | Wave Mode | Strip Map Mode | Extra Wide-Swath Mode (EW) | ||
---|---|---|---|---|---|
Parameters | Polarization | Dual (HH + HV, VV + VH) | Single (HH, VV) | Dual (HH + HV, VV + VH) | Dual (HH+HV, VV + VH) |
Azimuth resolution | 20 m | 5 m | 5 m | 40 m | |
Ground range resolution | 5 m | 5 m | 5 m | 20 m | |
Azimuth and range looks | Single | Single | Single | Single | |
Products | Level 2 | Ocean | Ocean | Ocean | Ocean |
Level 1 | Single Look Complex | - | Single Look Complex | Single Look Complex | |
Level 0 | Raw data | - | Raw data | Raw data | |
Characteristic | Lifetime | 7 years (consumables for 12 years) | |||
Launch date | 1A—3 April 2014 | 1B—25 April 2016 timeframe | ||||
Launcher/Location | Soyuz, Kourou (both launches) | ||||
Orbit | Near-polar, Sun-synchronous, about 690 km, 12 days repeat cycle | ||||
Orbital period | 98.6 min |
Software | Developer | Application | Description | Related Paper |
---|---|---|---|---|
Copernicus Open Access | European Space Agency (ESA) | Downloading | It provides complete, free, and open access to Sentinel-1, Sentinel-2, Sentinel-3, and Sentinel-5P user products. The self-registration process is automatic and immediate. Registration grants access rights for searching and downloading Sentinels products. Search queries on the products stored on the archive and filtering of results are possible via a full-text search bar, using filters for the different acquisition modes, product types, product levels, and geographical areas. | [57,58,59,60] |
SNAP—Sentinel 1 Toolbox | European Space Agency (ESA) | Preprocessing; Classification | A graphical user interface (GUI) used for both polarimetric and interferometric processing of SAR data. Start to finish processing includes algorithms for calibration, speckle filtering, co-registration, orthorectification, mosaicking, and data conversion. | [17,49,59,60,61,62,63,64,65,66] |
ENVI | Inventory Optimization Solutions (IOS) | Preprocessing; Classification | Software built in IDL, a powerful programming language, allows for easy features and functionality customization to meet unique needs. It makes it easier than ever to read, explore, prepare, analyze, and share information from imagery. | [1,61,67,68,69] |
ERDAS Image | ERDAS, Inc. | Preprocessing; Classification | Used widely for processing remote sensing data since it provides a framework for integrating sensor data and imagery from many sources. It is based on a Hierarchical File Format (HFA) structure. It allows to apply algorithms and validate results (accuracy assessment). | [49] |
Google Earth Imagery | Validating | Google Earth includes many images collected from satellites orbiting the planet. These images come from various satellite companies and are grouped into a mosaic of photographs taken over many days, months and years. It allows to validate results in visual mode | [70,71] | |
Google Earth Engine | Downloading; Preprocessing; Classification | Google Earth Engine combines a multi-petabyte catalogue of satellite imagery and geospatial datasets with planetary-scale analysis capabilities. It is used to detect changes, map trends, and quantify differences on the Earth’s surface. The client libraries provide Python and JavaScript wrappers around our web API. It is free. | [1,17,55,59,61,68,69,70,72] |
