Open AccessArticle
Genes 2017, 8(11), 296;

The Pattern of microRNA Binding Site Distribution

Department of Mathematics and Statistics, Texas Tech University, Lubbock, TX 79409, USA
Department of Environmental Toxicology, The Institute of Environmental and Human Health (TIEHH), Texas Tech University, 1207 Gilbert Dr., Lubbock, TX 79416, USA
Authors to whom correspondence should be addressed.
Received: 17 August 2017 / Revised: 18 October 2017 / Accepted: 23 October 2017 / Published: 27 October 2017
(This article belongs to the Special Issue Integrative Genomics and Systems Medicine in Cancer)
Full-Text   |   PDF [2699 KB, uploaded 30 October 2017]   |


Micro-RNA (miRNA or miR) regulates at least 60% of the genes in the human genome through their target sites at mRNA 3’-untranslated regions (UTR), and defects in miRNA expression regulation and target sites are frequently observed in cancers. We report here a systematic analysis of the distribution of miRNA target sites. Using the evolutionarily conserved miRNA binding sites in the TargetScan database (release 7.1), we constructed a miRNA co-regulation network by connecting genes sharing common miRNA target sites. The network possesses characteristics of the ubiquitous small-world network. Non-hub genes in the network—those sharing miRNA target sites with small numbers of genes—tend to form small cliques with their neighboring genes, while hub genes exhibit high levels of promiscuousness in their neighboring genes. Additionally, miRNA target site distribution is extremely uneven. Among the miRNAs, the distribution concentrates on a small number of miRNAs, in that their target sites occur in an extraordinarily large number of genes, that is, they have large numbers of target genes. The distribution across the genes follows a similar pattern; the mRNAs of a small proportion of the genes contain extraordinarily large numbers of miRNA binding sites. Quantitatively, the patterns fit into the P(K) ∝ Kα relationship (P(K): the number of miRNAs with K target genes or genes with K miRNA sites; α: a positive constant), the mathematical description of connection distribution among the nodes and a defining characteristic of the so-called scale-free networks—a subset of small-world networks. Notably, well-known tumor-suppressive miRNAs (Let-7, miR-15/16, 26, 29, 31, 34, 145, 200, 203–205, 223, and 375) collectively have more than expected target genes, and well-known cancer genes contain more than expected miRNA binding sites. In summary, miRNA target site distribution exhibits characteristics of the small-world network. The potential to use this pattern to better understand miRNA function and their oncological roles is discussed. View Full-Text
Keywords: microRNA; small-world network; scale-free network; clustering coefficient; distribution microRNA; small-world network; scale-free network; clustering coefficient; distribution

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).

Supplementary material


Share & Cite This Article

MDPI and ACS Style

Zhang, F.; Wang, D. The Pattern of microRNA Binding Site Distribution. Genes 2017, 8, 296.
