Characterization of Driver Mutations in Anaplastic Thyroid Carcinoma Identifies RAS and PIK3CA Mutations as Negative Survival Predictors

by
Wei-An Lai
1,
Chih-Yi Liu
2,
Shih-Yao Lin
1,3,
Chien-Chin Chen
4,5 and
Jen-Fan Hang
1,6,*
1
Department of Pathology and Laboratory Medicine, Taipei Veterans General Hospital, Taipei 112, Taiwan
2
Division of Pathology, Sijhih Cathay General Hospital, New Taipei City 221, Taiwan
3
Department of Pathology, Far Eastern Memorial Hospital, New Taipei City 220, Taiwan
4
Department of Pathology, Ditmanson Medical Foundation Chia-Yi Christian Hospital, Chiayi 600, Taiwan
5
Department of Cosmetic Science, Chia Nan University of Pharmacy and Science, Tainan 717, Taiwan
6
National Yang-Ming University School of Medicine, Taipei 112, Taiwan
*
Author to whom correspondence should be addressed.
Cancers 2020, 12(7), 1973; https://doi.org/10.3390/cancers12071973
Submission received: 25 June 2020 / Revised: 13 July 2020 / Accepted: 17 July 2020 / Published: 20 July 2020
(This article belongs to the Special Issue Biomarkers of Thyroid Cancer)
Browse Figures
Versions Notes

Abstract

:
Anaplastic thyroid carcinoma (ATC) is rare but highly aggressive. We investigated the association of selected driver mutations, including BRAF, RAS, PIK3CA, TERT promoter, TP53, POLE, and mismatch repair deficiency (MMR-D) with the clinicopathological features of ATC to identify prognostic and predictive biomarkers. Thirty-nine retrospective cases from pathology archives were enrolled for clinicopathology analysis and immunohistochemistry, and 27 cases had sufficient specimens for further molecular testing using targeted next-generation sequencing and mass spectrometry. BRAFV600E and RAS mutations were identified in 25.9% and 40.7% of ATC, respectively. BRAFV600E mutation was significantly associated with coexisting papillary thyroid carcinoma (p = 0.009) and RAS mutations with female gender (p = 0.012). In univariant analysis, the non-BRAF/RAS tumors were significantly associated with the presence of a sarcomatoid pattern (p = 0.045). PIK3CA, TERT promoter, and TP53 mutations were identified in 14.8%, 81.5%, and 70.4% of cases, respectively. No MMR-D or POLE mutations were detected. In survival analyses, RAS and PIK3CA mutations were significantly associated with inferior outcomes (p = 0.03 and p = 0.006, respectively). In conclusion, driver mutations in ATC are associated with distinct clinicopathological features. RAS and PIK3CA mutations were negative predictors for patient survival. Emerging therapeutic agents targeting BRAF, RAS, and PI3 kinase may benefit a substantial proportion of ATC patients.

1. Introduction

Thyroid carcinoma is the most common malignancy of the endocrine system [1]. Anaplastic thyroid carcinoma (ATC) is an aggressive tumor comprising 1%~2% of thyroid carcinoma [2]. Most patients present with advanced disease at the initial clinical encounter, and up to 90% of them die within a year after diagnosis [3,4]. ATC is managed by a multi-modality treatment approach combining surgical resection and chemoradiation. However, the effectiveness of the current treatment approach is limited [2]. As such, identification of actionable treatment targets, as well as biological predictors for clinical behavior in ATCs, is of value to improve clinical outcomes.
Genomic-scale analyses using next-generation sequencing have unraveled close genetic and phenotypic associations in well-differentiated thyroid carcinoma (WDTC). RAS-activating mutations and BRAFV600E mutation are the most common driver mutations in WDTC [5,6]. RAS mutations are associated with follicular patterned thyroid tumors including follicular adenoma, follicular carcinoma (FTC), and follicular variant of papillary thyroid carcinoma (PTC) [5]. These follicular patterned tumors share a RAS-driven transcriptome [5]. In contrast, BRAFV600E mutation is highly associated with classical PTC and tall cell variant of PTC. The BRAF-driven PTC has lower expression of thyroid differentiation genes, a higher risk of tumor recurrence, and strong MAP kinase signaling activation as opposed to activation of both MAP kinase and PI3 kinase pathways in RAS-driven PTC [7]. RAS and BRAFV600E mutations were also commonly mutated genes in ATC [8,9,10,11,12,13,14,15,16,17]. Studies indicated that RAS-driven and BRAF-driven ATC share homogenous transcriptome with an undifferentiated thyroid gene expression profile [9,18].
TERT promoter and TP53 were genomic hallmarks of ATC and less frequently detected in WDTC [19]. Additionally, mutations of PI3 kinase-Akt pathway-related genes were also identified in ATC [2,6,20,21]. Moreover, an increase of somatic mutation in ATC as compared to WDTC has been reported [15,18,22]. Defects in DNA mismatch repair mechanism or DNA polymerase epsilon (POLE) mutation could contribute to hypermutation in tumors and have therapeutic implications for the emerging immunotherapies [23]. It has been proposed that these molecular changes are acquired during tumor de-differentiation and contribute to anaplastic transformation in thyroid carcinoma [19]. However, the phenotypic association with the aforementioned genetic alterations has not been well delineated in ATC. In this study, we aimed to characterize these selected driver mutations and their associated clinicopathological features in ATC.

2. Results

2.1. Clinicopathological Features of ATC

We assembled a cohort of 39 ATC cases. The clinicopathological features are summarized in Table 1. The median age was 75 years. Female patients comprised 51.3% of the cases. More than half (55.6%) were stage IVC disease at initial presentation. Most patients underwent total or subtotal thyroidectomy (61.5% and 23.1%), while 15.4% of cases had biopsy only. Up to 51.3% of the patients received additional therapies, including external radiation (25%), chemotherapy (24.1%), radioiodine (21.4%), and targeted therapy (15.1%). Histologically, epithelial, sarcomatoid, and giant cell are well-described morphologic patterns in ATC (Figure 1a–c). Twelve (30.8%) cases showed more than one histologic pattern. In our cohort, the epithelial pattern was the most frequent (71.8%), followed by sarcomatoid (43.6%) and giant cell (12.8%). A coexisting well-differentiated thyroid carcinoma component was identified in 33.3% of cases, including 10 PTC and 3 FTC (Figure 1d,e). Immunohistochemical stains were utilized to detect thyroid-lineage marker expression and BRAFV600E mutation (Figure 1f–h). PAX8 expressed in 56.4% and TTF-1 in 5.1% of the cases (Table 2). BRAF VE1 staining was positive in 25.6% of all cases. Coexisting PTC was identified in 6/10 (60%) of the BRAF VE1-positive ATC and 4/29 (13.8%) of wild-type ATC. Coexisting PTC was significantly associated with BRAFV600E mutation (p = 0.009).

2.2. Molecular Profiles of ATC

Twenty-seven ATC cases with sufficient formalin-fixed paraffin-embedded (FFPE) materials for DNA extraction were subjected to targeted next-generation sequencing (NGS) and mass spectrometry, and the results are summarized (Figure 2, Supplementary Data 1 and Data 2). BRAFV600E (c.T1799A) was identified in 25.9% of the cases. All ATC with BRAFV600E mutation detected by NGS were positive for the BRAF VE1 immunohistochemistry. RAS-activating mutations at codon 12, 13, and 61 were analyzed. We found overall RAS mutations in 40.7% of the cases, and among the 11 cases, 8 were found in N-RAS (Q61R in 6, Q61K in 1, and G12D in 1) and 3 in K-RAS (Q61R in 2 and G12A in 1). H-RAS mutation was not identified. To investigate the potential association between driver mutations and clinicopathological features, the 27 cases were stratified into three molecular groups: BRAF-mutated, RAS-mutated, and non-BRAF/RAS group (Table 3). We found that RAS mutation was associated with female gender (90.9% versus 44.4% and 28.6% in non-BRAF/RAS and BRAF groups respectively, p = 0.012). The non-BRAF/RAS group was associated with the presence of a sarcomatoid component morphologically (77.8% versus 45.5% in RAS and 14.3% in BRAF groups, respectively, p = 0.045). Association between RAS mutations and female gender remains significant (odds ratio 20.31, p = 0.022, supplementary Table S1) in multivariate analysis, while the non-BRAF/RAS group becomes marginally associated with the presence of a sarcomatoid pattern (odds ratio 23.17, p = 0.089, Supplementary Table S2). TERT promoter C288T mutation was present in 81.5% of cases, while C250T was not detected in any of the cases. TP53 missense mutation was found in 70.4% of ATC. PIK3CA mutation was present in 14.8% of ATC, including one E542K, one E545K, and two H1047R mutations. Mismatch repair deficiency and POLE exonuclease domain mutation potentially led to a hypermutation phenotype in tumors. We found that mismatch repair (MMR) protein expression was retained in all of the cases (Table 2). We did not identify mutations in the exonuclease domain of POLE in any of the ATC.

2.3. Survival Analysis of ATC Cohort

Follow-up data of all cases was obtained, and the median survival interval was 54 days (1–1079). We constructed Kaplan–Meier survival curves with stratification on molecular alternations including BRAFV600E, RAS, TERT promoter, TP53, and PIK3CA mutations (Figure 3). RAS and PIK3CA mutations were significantly associated with an inferior survival (median 94 versus 41 days, p = 0.03 and median 94 versus 29 days, p = 0.006 respectively). None of the other mutations correlate with patient survival.

3. Discussion

In the current study, we analyzed a cohort of ATC and identified RAS mutations in 40.7% and BRAFV600E mutation in 25.9% of ATC. The two mutations were mutually exclusive and detected in up to 70% of ATC. ATC stratified by BRAFV600E and RAS mutations showed distinct clinicopathological features. BRAFV600E mutation was significantly associated with coexisting PTC. RAS-mutated ATC was positively associated with female gender and an inferior survival outcome. Non-RAS/BRAF tumors tended to show a sarcomatoid morphological pattern. PIK3CA mutations were found in 14.8% of ATC and were also identified as a negative prognostic indicator. TERT promoter and TP53 mutations were frequent mutations in ATC, identified in 81.5% and 70.4% of the tumors respectively. MMR deficiency and POLE exonuclease domain mutation were not detected in our cohort. Except for RAS and PIK3CA mutations, none of the other molecular changes investigated in this study showed prognostic significance.
Genetic alternation rates of selected genes in ATC reported in the literature are summarized in Table 4. RAS mutation rate in ATC was reported ranging from 18% to 44.4%. In our cohort, N-RAS mutation was the most frequent (eight cases, 29.6%) among the three RAS subtypes, concordant with findings in previous reports [9,13,15,16]. K-RAS mutation was present in three cases (11.1%), while H-RAS mutation was not detected. Mutations at codon 61 were the most common, followed by codon 12. RAS-mutated ATC emerged with distinct clinicopathological features. RAS mutations were strongly associated with female gender in both univariate and multivariate analyses (p = 0.012 and 0.022) and showed significantly poor survival outcomes (p = 0.03). It has been reported that the co-occurrence of RAS and TERT promoter mutations was associated with an inferior survival outcome [8,18]. Our study was the first one to demonstrate that RAS mutations alone predicted a significantly poor outcome. On the other hand, BRAFV600E mutation rate in ATC was reported ranging from 12.8% to 56% (Table 4). In one Korean report where PTC is prevalent, the BRAFV600E mutation in ATC was up to 91% [14]. In our cohort, BRAFV600E mutation was also strongly associated with a coexisting PTC component (p = 0.009). In the 10 ATC with coexisting PTC, up to 60% harbored BRAFV600E mutation. Therapies targeting BRAFV600E are being utilized for the treatment of ATC. In BRAFV600E-mutated ATC, combination treatment with Dabrafenib and Trametinib has been proven robust as an adjuvant therapy to improve clinical outcomes and a neoadjuvant treatment to facilitate complete surgical resection for local control [24,25]. Direct inhibitors of RAS have not yet achieved clinical success. Recently, small molecules targeting KRAS G12C have entered phase 1 and 2 clinical trials for the treatment of colorectal carcinoma [26]. Targeting RAS may become a potential strategy in the management of advanced malignancy. Among the 27 cases subjected to NGS studies, nine cases were absent of either RAS or BRAFV600E mutations. Whether these tumors harbor other rare targetable driver fusion events found in WDTC, such as RET-PTC, PAX8-PPARG, NTRK, and ALK rearrangement, requires further analysis [27].
Mutation rates of PIK3CA, TERT promoter, and TP53 are higher in ATC as compared to WDTC [19]. These gene mutations often co-occur with BRAFV600E and RAS mutations and are thought to be acquired during thyroid cancer de-differentiation [19]. In the 18 cases with the driver BRAFV600E or RAS mutations, only one was absent of all PIK3CA, TERT promoter, and TP53 mutations. PIK3CA mutation rates were reported ranging from 0% to 44% in the literature (Table 4). We identified PIK3CA mutations in 14.8% of our cohort, with two cases co-occurring with BRAFV600E mutation and one with RAS mutation. Moreover, we identified PIK3CA mutation significantly associated with an inferior survival outcome (p = 0.006). Duan et al. also reported PIK3CA as a negative predictor of patient survival in ATC, and co-occurrence of PIK3CA and TERT promoter mutations had a higher risk of mortality than patients with only one of either mutation [10]. PI3 kinase pathway and MAP kinase pathway are divergent pathways downstream of RAS signaling. Pre-clinical studies had identified combined treatment with MEK and PI3 kinase inhibitors synergized to target BRAFV600E and PIK3CA double-mutant ATC cell lines and genetically engineered mice [28]. PI3 kinase inhibitors have also been evaluated in clinical trials for breast, colorectal, and lung cancers [29]. Whether targeting PI3 kinase serves as an effective treatment strategy for ATC remains to be elucidated. Mutations of TERT promoter and TP53 are the genetic hallmark of ATC [2,12,20]. In ATC, the rate of TERT promoter and TP53-inactivating mutations ranged from 32% to 75% and 25% to 65.6%, respectively (Table 4). Moreover, TERT promoter mutation had been recurrently reported to associate with shorter survival [8,10,18]. Xu et al. and Duan et al. both showed that TERT promoter mutation alone served as a negative prognostic indicator [8,10]. Xu et al. further found that patient outcome was particularly grave in tumors with co-occurrence of TERT promoter mutation with RAS or BRAFV600E mutation [8]. Yet no prognostic effect of TERT promoter mutation could be observed in our analysis. This could be attributed to a high mutation rate of TERT promoter in our cohort.
Previous studies reported an increase in somatic mutation numbers in ATC [15,18]. In colorectal and endometrial carcinoma, it was well demonstrated that MMR-D or POLE exonuclease domain mutation could lead to a marked increase of somatic mutations in tumors and predict response to anti-PD-L1 treatment [30,31,32]. Prior studies demonstrated MMR-D in up to 13.6% of ATC [8,15,22,33], and POLE missense mutation in 4% and 9% (Table 4). The mutation sites of POLE were not specified in previous studies. In our cohort, all ATC had preserved MMR protein expression, and we did not detect any non-synonymous mutations specifically in the POLE exonuclease domain. Our findings along with previous reports suggested that MMR-D and POLE exonuclease domain mutations were rare in ATC and had limited implications regarding anti-PD-L1 therapy.
In this study, we identified distinct clinicopathological features in ATC stratified by BRAFV600E and RAS mutations. BRAFV600E mutation was significantly associated with coexisting PTC, while RAS-mutated tumors were strongly associated with female gender. Of note, RAS and PIK3CA mutations were significantly associated with worse prognostic outcomes in ATC. Genetic hallmarks including TERT promoter and TP53 mutations were prevalent, while MMR-D or POLE exonuclease domain mutations were not identified in our ATC cohort. The molecular profile of these selected driver mutations has clinical implications regarding the emerging targeted therapies in this particularly aggressive cancer.
Table
Table 4. Literature review of molecular alternations in anaplastic thyroid carcinoma.
Table 4. Literature review of molecular alternations in anaplastic thyroid carcinoma.
ReferencesCase No.BRAFV600ERASTP53TERTPIK3CAPOLEMMR Alternation b
Current Study2725.9%40.7%70.4%81.5%14.8%0%0%
Xu 2020 [8] a10243.1%22%63%75%18%4%8%
Khan 2019 [16]9032%26%65.6%32%12.2%nana
Duan 2019 [10]2556%24%60%56%44%nana
Yoo 2019 [9]2740.1%44.4%48.1%55.6%11.1%nana
Ravi 2019 [33]1118%18%55%36%18%9%9%
Chen 2018 [17]1225%33%25%na0%nana
Bonhomme 2017 [13]9412.8%42.6%54.4%54%6.4%nana
Kunstman 2015 [15]2227.3%27.3%27.3%na9.1%na13.6%
a Cases from Landa et al. 2016 [18] and Pozdeyev et al. 2018 [34] were included in Xu 2020; b MMR alternations include MMR deficiency detected by immunohistochemistry in this study as well as mutations of the MMR genes detected in Xu 2020, Ravi 2019, and Kunstman 2015; MMR, mismatch repair; na, not analyzed.

4. Materials and Methods

4.1. Case Selection

This study was carried out in accordance to the Declaration of Helsinki and approved by the Institutional Review Board of Taipei Veterans General hospital, which granted exemption of informed consent for tissue procurement through the Biobank of Taipei Veterans General Hospital after an unlinked anonymous process (IRB no.: 2018-06-008BC, June 7th, 2019; Biobank no.: 10707). A total of 39 ATC cases from four participating hospitals in the period between 1997 and 2018 were enrolled. All pathology slides were reviewed, and the diagnosis of ATC in each case was confirmed according to the 2017 WHO Classification of Tumors of Endocrine Organs [35]. Histologic patterns, including epithelial, giant cell, and sarcomatoid, as well as the presence of coexisting differentiated carcinoma component, were recorded. Clinical information including age, gender, stage at presentation, specimen obtaining procedure, treatment modality, and follow-up information was obtained from the biobank database.

4.2. Construction of Tissue Microarray and Immunohistochemistry

For each case, representative formalin-fixed paraffin-embedded (FFPE) ATC tissue was selected, and two 2-mm cores were obtained for tissue microarray construction. Four-μm tissue microarray sections were used for H&E and immunohistochemistry. Immunohistochemical stains for PAX8 (1:400 dilution; clone 10336-1-AP; Proteintech, Rosemont, IL), TTF-1 (1:300 dilution; clone 8G7G3/1, Dako GmbH, Jena, Germany), and BRAF VE1 (1:200 dilution; clone VE1; Spring Bioscience, Pleasanton, CA, USA) were performed on Leica Bond-Max autostainer (Leica Microsystems GmbH, Wetzlar, Germany). To investigate mismatch repair protein (MMR) deficiency, immunohistochemical stains for the four MMR proteins, including MSH2, MSH6, PMS1, and MLH2, were performed. Prediluted antibodies for MLH1 (clone M1), PMS2 (clone A16-4), MSH2 (clone G219-1129), and MSH6 (clone SP93) were applied on BenchMark Ultra slide stainer (Ventana Medical Systems, Tuscan, Italian). The automated program for immunohistochemistry included deparaffinization, antigen retrieval, incubation with primary antibody followed by secondary antibody, and chromogen visualization. For PAX8 and TTF-1, positive staining was defined as the presence of positive nuclear staining in more than 5% of ATC tumor cells. For BRAF VE1, positive staining was defined as diffuse cytoplasmic staining of moderate to strong intensity. Loss of MMR protein expression was defined as complete absence of nuclear staining in the entire tumor area with lymphocytes and vascular endothelial cells serving as positive internal control.

4.3. DNA Extraction

Cases with sufficient FFPE tissue were subjected to molecular testing. Representative FFPE blocks were used for DNA extraction. Four to six 10 μm-sections on glass slides were used for each case based on tissue size. DNA extraction was performed using QIAamp DNA FFPE tissue kit (Qiagen, Germantown, MD, USA) based on the manufacturer’s instruction. In brief, the tumor region on section was applied with lysis buffer, scraped off the glass slide, and collected into a microcentrifuge tube in a total volume of 180 μL. The sample was then incubated with 20 μL proteinase K at 56 °C for 1 h and then mixed with 200 μL buffer AL and 200 μL ethanol. The mixture was then transferred to the MinElute column, centrifuged to remove the buffer, and passed sequentially by buffer AW1 and AW2. Finally, 60 μL of buffer ATE was added to the column and the eluate containing extracted DNA was collected.

4.4. Targeted Next-Generation Sequencing (NGS)

We performed targeted NGS panel to identify mutation at BRAF exon 15 (NM_004333.4), RAS codon 12, 13, and 61 (H-RAS NM_005343.2, N-RAS NM_002524.4, and K-RAS NM_033360.2) [36], POLE exonuclease domain encompassing codons 268 to 471 (NM_006231.2) [37], TERT promoter (NC_000005.9) [12], and TP53 whole coding region (NM_000546.5). The amount of 250 ng tumor genomic DNA of each individual was used for library construction of the targeted gene regions using QIAseq target DNA system (Qiagen). Briefly, DNA was enzymatically fragmented and end-repaired in a 25 μL reaction containing 2.5 μL 10× fragmentation buffer and 5 μL fragmentation enzyme mix. The reaction was carried out at 4 °C for 1 min, 32 °C for 24 min, and 65 °C for 30 min. Immediately after the reaction, 10 μL 5× ligation buffer, 5 μL DNA ligase, 2.8 μL 25 μM barcoded adapters, and water were added to reach a total volume at 50 μL. The reaction was incubated at 20 °C for 15 min. To ensure complete removal of free barcoded adapters, each reaction was purified for two rounds using beads. To amplify the barcoded DNA fragments, the purified DNA was then mixed with 10 nM each of target primer (a total of 72 target specific primers), 400 nM Forward primer, 1× PCR buffer, and 0.8 μL HotStarTaq DNA polymerase in a 20 μL reaction. The PCR was carried with the following conditions: 95 °C for 13 min, 98 °C for 2 min; six cycles of 98 °C for 15 s and 65 °C for 15 min; 72 °C for 5 min. The reaction was then incubated with beads to remove remaining excess primers. The DNA product was subjected to another round of amplification by mixing with 400 nM Universal primer, 400 nM Index primer, 1X PCR buffer, and 1 μL HotStarTaq DNA polymerase in a volume of 20 μL, with the following PCR conditions: 95 °C for 13 min, 98 °C for 2 min, 20 cycles of 98 °C for 15 s and 60 °C for 2 min; 72 °C for 5 min. The DNA library was purified by incubation with beads, and the final pool subjected to targeted sequencing using Illumina MiniSeq sequencer (Illumina, San Diego, CA, USA). The raw outputs of each case were>16 Mb, and the average depth of target regions was more than 500 folds. The sequence of each read was trimmed based on the quality score (Q30), and reads with length less than 45 bp were discarded in subsequent analysis. Reads were aligned to the human hg19 reference genome using BWA-MEM [38]. GATK Unified Genotyper was used for variant calling [39]. Variant Effect Predictor was used to annotating the variants [40]. Variants with an allelic frequency ≤5% were excluded. Only non-synonymous mutations reported in the Sanger Institute Catalogue were taken into account.

4.5. Mass Spectrometry for PI3KCA Mutations

Analysis of hot spot somatic mutations of PI3KCA in exon 9 and exon 20 (NM_006218.4) [41] was performed using Agena MassARRAY platform with iPLEX reagent chemistry (Agena, San Diego, CA, USA). The genotypes of the codons assayed are listed in Supplementary Table S3. The specific PCR primer and extension primer sequences were designed with Assay Designer software package (v.4.0). Multiplex PCR reaction was carried by mixing 10 ng genomic DNA sample, 1 U Taq polymerase, 500 nmol each of PCR primers, and 2.5 mM dNTP in 5 μL reaction volume and amplified in a thermocycler for 45 cycles. Unincorporated dNTPs were deactivated using 0.3 U of shrimp alkaline phosphatase. Single base extension reaction was performed by adding a mix of specific extension primers, dideoxynucleotide terminators, and extension enzyme, followed by thermocycling according to manufacturer’s instruction. The specific extension primers anneal directly to the mutation sites, and were extended and terminated by the dideoxynucleotide terminators complementary to the target somatic mutational site. The reaction was purified by incubation with cation exchange resin, and 7 μL of the purified product was loaded onto a matrix pad of a SpectroCHIP where the analyte crystalizes with a pre-spotted MALDI matrix. SpectroCHIPs were loaded in MassARRAY Analyzer 4 where ionization and signal detection were carried, and base calling reported by clustering analysis with TYPER 4.0 software.

4.6. Statistical Analysis

Categorical data were analyzed using Fisher exact test and logistic regression for univariate and multivariate analyses. Survival curves were built using the Kaplan–Meier method, and log-rank test was applied to test for differences between the variables. The p-values were two-sided, and a value <0.05 was considered significant. All analyses were performed using R software (version 3.5.1, R Foundation for Statistical Computing, Vienna, Austria).

5. Conclusions

This study illustrates clinicopathological features in ATC stratified by BRAFV600E and RAS mutations. Importantly, RAS and PIK3CA mutations were found to be negative prognostic indicators in ATC. In concordance with previous reports, we demonstrated that genetic hallmarks in ATC including TERT promoter and TP53 mutations were prevalent in ATC. MMR-D or POLE exonuclease domain mutations were not identified in our study cohort. Acknowledging molecular profiles of ATC may have clinical implications regarding emerging targeted therapies, including BRAF, RAS, and PI3 kinase inhibitors.

Supplementary Materials

The following are available online at https://www.mdpi.com/2072-6694/12/7/1973/s1, Supplementary data 1: Mutational profile of anaplastic thyroid carcinoma cases detected by next-generation sequencing, Supplemental data 2: PIK3CA mutations in anaplastic thyroid carcinoma cases detected by mass spectrometry, Table S1: Clinicopathological features of RAS-mutated and RAS wild-type ATC cases, Table S2: Clinicopathological features of ATC cases wild type for RAS and BRAFV600E and cases with either one mutation, Table S3: List of PIK3CA mass spectrometry assay panel.

Author Contributions

Conceptualization, J.-F.H.; methodology, W.-A.L. and J.-F.H.; software, W.-A.L.; validation, W.-A.L. and J.-F.H.; formal analysis, W.-A.L.; investigation, W.-A.L. and J.-F.H.; resources, J.-F.H., C.-Y.L., S.-Y.L., and C.-C.C.; data curation, W.-A.L., C.-Y.L., S.-Y.L., and C.-C.C.; writing—original draft preparation, W.-A.L.; writing—review and editing, J.-F.H., C.-Y.L., S.-Y.L., and C.-C.C.; visualization, W.-A.L. and J.-F.H.; supervision, J.-F.H.; project administration, J.-F.H.; funding acquisition, J.-F.H. All authors have read and agreed to the published version of the manuscript.

Funding

This research was funded by the research grant from Taipei Veterans General Hospital (Grant No.: V108B-011 (January 1st to December 31st, 2019) and V109B-029 (January 1st to December 31st, 2020)) and Taipei Veterans General Hospital-National Yang-Ming University Excellent Physician Scientists Cultivation Program (Grant No.: 108-V-B-003 (January 1st to March 31st, 2019)).

Acknowledgments

The authors would like to thank the Biobank, Taipei Veterans General Hospital for assistance with sample preparation in this study.

Conflicts of Interest

The authors declare no conflict of interest.

References

  1. Liu, F.-C.; Lin, H.-T.; Lin, S.-F.; Kuo, C.-F.; Chung, T.-T.; Yu, H.-P. Nationwide cohort study on the epidemiology and survival outcomes of thyroid cancer. Oncotarget 2017, 8, 78429–78451. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  2. Molinaro, E.; Romei, C.; Biagini, A.; Sabini, E.; Agate, L.; Mazzeo, S.; Materazzi, G.; Sellari-Franceschini, S.; Ribechini, A.; Torregrossa, L.; et al. Anaplastic thyroid carcinoma: From clinicopathology to genetics and advanced therapies. Nat. Rev. Endocrinol. 2017, 13, 644–660. [Google Scholar] [CrossRef]
  3. Brignardello, E.; Gallo, M.; Baldi, I.; Palestini, N.; Piovesan, A.; Grossi, E.; Ciccone, G.; Boccuzzi, G. Anaplastic thyroid carcinoma: Clinical outcome of 30 consecutive patients referred to a single institution in the past 5 years. Eur. J. Endocrinol. 2007, 156, 425–430. [Google Scholar] [CrossRef]
  4. Kebebew, E.; Greenspan, F.S.; Clark, O.H.; Woeber, K.A.; McMillan, A. Anaplastic thyroid carcinoma. Treatment outcome and prognostic factors. Cancer 2005, 103, 1330–1335. [Google Scholar] [CrossRef] [PubMed]
  5. Yoo, S.-K.; Lee, S.; Kim, S.-j.; Jee, H.-G.; Kim, B.-A.; Cho, H.; Song, Y.S.; Cho, S.W.; Won, J.-K.; Shin, J.-Y.; et al. Comprehensive analysis of the transcriptional and mutational landscape of follicular and papillary thyroid cancers. PLoS Genet. 2016, 12, e1006239. [Google Scholar] [CrossRef] [PubMed]
  6. Nikiforov, Y.E.; Nikiforova, M.N. Molecular genetics and diagnosis of thyroid cancer. Nat. Rev. Endocrinol. 2011, 7, 569–580. [Google Scholar] [CrossRef] [PubMed]
  7. Agrawal, N.; Akbani, R.; Aksoy, B.A.; Ally, A.; Arachchi, H.; Asa Sylvia, L.; Auman, J.T.; Balasundaram, M.; Balu, S.; Baylin, S.B.; et al. Integrated genomic characterization of papillary thyroid carcinoma. Cell 2014, 159, 676–690. [Google Scholar] [CrossRef]
  8. Xu, B.; Fuchs, T.L.; Dogan, S.; Landa, I.; Katabi, N.; Fagin, J.A.; Tuttle, R.M.T.; Sherman, E.J.; Gill, A.; Ghossein, R. Dissecting anaplastic thyroid carcinoma (ATC): A comprehensive clinical, histologic, immunophenotypic, and molecular study of 360 cases. Thyroid 2020, in press. [Google Scholar] [CrossRef]
  9. Yoo, S.-K.; Song, Y.S.; Lee, E.K.; Hwang, J.; Kim, H.H.; Jung, G.; Kim, Y.A.; Kim, S.-j.; Cho, S.W.; Won, J.-K.; et al. Integrative analysis of genomic and transcriptomic characteristics associated with progression of aggressive thyroid cancer. Nat. Commun. 2019, 10, 2764–2775. [Google Scholar] [CrossRef] [Green Version]
  10. Duan, H.; Li, Y.; Hu, P.; Gao, J.; Ying, J.; Xu, W.; Zhao, D.; Wang, Z.; Ye, J.; Lizaso, A.; et al. Mutational profiling of poorly differentiated and anaplastic thyroid carcinoma by the use of targeted next-generation sequencing. Histopathology 2019, 75, 890–899. [Google Scholar] [CrossRef]
  11. Deeken-Draisey, A.; Yang, G.-Y.; Gao, J.; Alexiev, B.A. Anaplastic thyroid carcinoma: An epidemiologic, histologic, immunohistochemical, and molecular single-institution study. Hum. Pathol. 2018, 82, 140–148. [Google Scholar] [CrossRef] [PubMed]
  12. Oishi, N.; Kondo, T.; Ebina, A.; Sato, Y.; Akaishi, J.; Hino, R.; Yamamoto, N.; Mochizuki, K.; Nakazawa, T.; Yokomichi, H.; et al. Molecular alterations of coexisting thyroid papillary carcinoma and anaplastic carcinoma: Identification of TERT mutation as an independent risk factor for transformation. Mod. Pathol. 2017, 30, 1527–1537. [Google Scholar] [CrossRef] [PubMed]
  13. Bonhomme, B.; Godbert, Y.; Perot, G.; Al Ghuzlan, A.; Bardet, S.; Belleannée, G.; Crinière, L.; Do Cao, C.; Fouilloux, G.; Guyetant, S.; et al. Molecular pathology of anaplastic thyroid carcinomas: A retrospective study of 144 cases. Thyroid 2017, 27, 682–692. [Google Scholar] [CrossRef]
  14. Jeon, M.J.; Chun, S.-M.; Kim, D.; Kwon, H.; Jang, E.K.; Kim, T.Y.; Kim, W.B.; Shong, Y.K.; Jang, S.J.; Song, D.E.; et al. Genomic alterations of anaplastic thyroid carcinoma detected by targeted massive parallel sequencing in a BRAF V600E mutation-prevalent area. Thyroid 2016, 26, 683–690. [Google Scholar] [CrossRef] [PubMed]
  15. Kunstman, J.W.; Juhlin, C.C.; Goh, G.; Brown, T.C.; Stenman, A.; Healy, J.M.; Rubinstein, J.C.; Choi, M.; Kiss, N.; Nelson-Williams, C.; et al. Characterization of the mutational landscape of anaplastic thyroid cancer via whole-exome sequencing. Hum. Mol. Genet. 2015, 24, 2318–2329. [Google Scholar] [CrossRef] [Green Version]
  16. Khan, S.A.; Ci, B.; Xie, Y.; Gerber, D.E.; Beg, M.S.; Sherman, S.I.; Cabanillas, M.E.; Busaidy, N.L.; Burtness, B.A.; Heilmann, A.M.; et al. Unique mutation patterns in anaplastic thyroid cancer identified by comprehensive genomic profiling. Head Neck 2019, 41, 1928–1934. [Google Scholar] [CrossRef]
  17. Chen, H.; Luthra, R.; Routbort, M.J.; Patel, K.P.; Cabanillas, M.E.; Broaddus, R.R.; Williams, M.D. Molecular profile of advanced thyroid carcinomas by next-generation sequencing: Characterizing tumors beyond diagnosis for targeted therapy. Mol. Cancer Ther. 2018, 17, 1575–1584. [Google Scholar] [CrossRef] [Green Version]
  18. Landa, I.; Ibrahimpasic, T.; Boucai, L.; Sinha, R.; Knauf, J.A.; Shah, R.H.; Dogan, S.; Ricarte-Filho, J.C.; Krishnamoorthy, G.P.; Xu, B.; et al. Genomic and transcriptomic hallmarks of poorly differentiated and anaplastic thyroid cancers. J. Clin. Investig. 2016, 126, 1052–1066. [Google Scholar] [CrossRef] [Green Version]
  19. Xu, B.; Ghossein, R. Genomic landscape of poorly differentiated and anaplastic thyroid carcinoma. Endocr. Pathol. 2016, 27, 205–212. [Google Scholar] [CrossRef]
  20. Haroon Al Rasheed, M.R.; Xu, B. Molecular alterations in thyroid carcinoma. Surg. Pathol. Clin. 2019, 12, 921–930. [Google Scholar] [CrossRef]
  21. Acquaviva, G.; Visani, M.; Repaci, A.; Rhoden, K.J.; de Biase, D.; Pession, A.; Giovanni, T. Molecular pathology of thyroid tumours of follicular cells: A review of genetic alterations and their clinicopathological relevance. Histopathology 2018, 72, 6–31. [Google Scholar] [CrossRef]
  22. Wong, K.S.; Lorch, J.H.; Alexander, E.K.; Nehs, M.A.; Nowak, J.A.; Hornick, J.L.; Barletta, J.A. Clinicopathologic features of mismatch repair-deficient anaplastic thyroid carcinomas. Thyroid 2019, 29, 666–673. [Google Scholar] [CrossRef] [PubMed]
  23. Kim, T.M.; Laird, P.W.; Park, P.J. The landscape of microsatellite instability in colorectal and endometrial cancer genomes. Cell 2013, 155, 858–868. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  24. Subbiah, V.; Kreitman, R.J.; Wainberg, Z.A.; Cho, J.Y.; Schellens, J.H.M.; Soria, J.C.; Wen, P.Y.; Zielinski, C.; Cabanillas, M.E.; Urbanowitz, G.; et al. Dabrafenib and trametinib treatment in patients with locally advanced or metastatic BRAF V600–mutant anaplastic thyroid cancer. J. Clin. Oncol. 2018, 36, 7–13. [Google Scholar] [CrossRef] [Green Version]
  25. Wang, J.R.; Zafereo, M.E.; Dadu, R.; Ferrarotto, R.; Busaidy, N.L.; Lu, C.; Ahmed, S.; Gule-Monroe, M.K.; Williams, M.D.; Sturgis, E.M.; et al. Complete surgical resection following neoadjuvant dabrafenib plus trametinib in BRAFV600E-mutated anaplastic thyroid carcinoma. Thyroid 2019, 29, 1036–1043. [Google Scholar] [CrossRef] [Green Version]
  26. Khan, I.; Rhett, J.M.; O’Bryan, J.P. Therapeutic targeting of RAS: New hope for drugging the “undruggable”. Biochim. Biophys. Acta 2020, 1867, 118570. [Google Scholar] [CrossRef] [PubMed]
  27. Yakushina, V.D.; Lerner, L.V.; Lavrov, A.V. Gene fusions in thyroid cancer. Thyroid 2017, 28, 158–167. [Google Scholar] [CrossRef]
  28. ElMokh, O.; Ruffieux-Daidié, D.; Roelli, M.A.; Stooss, A.; Phillips, W.A.; Gertsch, J.; Dettmer, M.S.; Charles, R.-P. Combined MEK and PI3-kinase inhibition reveals synergy in targeting thyroid cancer in vitro and in vivo. Oncotarget 2017, 8, 24604–24620. [Google Scholar] [CrossRef] [Green Version]
  29. Yang, J.; Nie, J.; Ma, X.; Wei, Y.; Peng, Y.; Wei, X. Targeting PI3K in cancer: Mechanisms and advances in clinical trials. Mol. Cancer 2019, 18, 26. [Google Scholar] [CrossRef] [Green Version]
  30. Haraldsdottir, S.; Hampel, H.; Tomsic, J.; Frankel, W.L.; Pearlman, R.; de la Chapelle, A.; Pritchard, C.C. Colon and endometrial cancers with mismatch repair deficiency can arise from somatic, rather than germline, mutations. Gastroenterology 2014, 147, 1308–1316. [Google Scholar] [CrossRef] [Green Version]
  31. Gong, J.; Wang, C.; Lee, P.P.; Chu, P.; Fakih, M. Response to PD-1 blockade in microsatellite stable metastatic colorectal cancer harboring a POLE mutation. J. Natl. Compr. Cancer Netw. 2017, 15, 142–147. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  32. Konstantinopoulos, P.A.; Luo, W.; Liu, J.F.; Gulhan, D.C.; Krasner, C.; Ishizuka, J.J.; Gockley, A.A.; Buss, M.; Growdon, W.B.; Crowe, H.; et al. Phase II study of avelumab in patients with mismatch repair deficient and mismatch repair proficient recurrent/persistent endometrial cancer. J. Clin. Oncol. 2019, 37, 2786–2794. [Google Scholar] [CrossRef] [PubMed]
  33. Ravi, N.; Yang, M.; Gretarsson, S.; Jansson, C.; Mylona, N.; Sydow, S.R.; Woodward, E.L.; Ekblad, L.; Wennerberg, J.; Paulsson, K. Identification of targetable lesions in anaplastic thyroid cancer by genome profiling. Cancers 2019, 11, 402. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  34. Pozdeyev, N.; Gay, L.M.; Sokol, E.S.; Hartmaier, R.; Deaver, K.E.; Davis, S.; French, J.D.; Borre, P.V.; LaBarbera, D.V.; Tan, A.-C.; et al. Genetic analysis of 779 advanced differentiated and anaplastic thyroid cancers. Clin. Cancer Res. 2018, 24, 3059–3068. [Google Scholar] [CrossRef] [Green Version]
  35. Lloyd, R.V.; Osamura, R.Y.; Klöppel, G.; Rosai, J. WHO Classification of Tumours of Endocrine Organs, 4th ed.; International Agency for Research on Cancer: Lyon, France, 2017. [Google Scholar]
  36. Santarpia, L.; El-Naggar, A.K.; Cote, G.J.; Myers, J.N.; Sherman, S.I. Phosphatidylinositol 3-kinase/Akt and Ras/Raf-mitogen-activated protein kinase pathway mutations in anaplastic thyroid cancer. J. Clin. Endocr. Metab. 2008, 93, 278–284. [Google Scholar] [CrossRef] [Green Version]
  37. Church, D.N.; Briggs, S.E.W.; Palles, C.; Domingo, E.; Kearsey, S.J.; Grimes, J.M.; Gorman, M.; Martin, L.; Howarth, K.M.; Hodgson, S.V.; et al. DNA polymerase ε and δ exonuclease domain mutations in endometrial cancer. Hum. Mol. Genet. 2013, 22, 2820–2828. [Google Scholar] [CrossRef] [Green Version]
  38. Li, H.; Durbin, R. Fast and accurate short read alignment with Burrows–Wheeler transform. Bioinformatics 2009, 25, 1754–1760. [Google Scholar] [CrossRef] [Green Version]
  39. DePristo, M.A.; Banks, E.; Poplin, R.; Garimella, K.V.; Maguire, J.R.; Hartl, C.; Philippakis, A.A.; del Angel, G.; Rivas, M.A.; Hanna, M.; et al. A framework for variation discovery and genotyping using next-generation DNA sequencing data. Nat. Genet. 2011, 43, 491–498. [Google Scholar] [CrossRef]
  40. McLaren, W.; Gil, L.; Hunt, S.E.; Riat, H.S.; Ritchie, G.R.S.; Thormann, A.; Flicek, P.; Cunningham, F. The ensembl variant effect predictor. Genome Biol. 2016, 17, 122. [Google Scholar] [CrossRef] [Green Version]
  41. García-Rostán, G.; Costa, A.M.; Pereira-Castro, I.; Salvatore, G.; Hernandez, R.; Hermsem, M.J.A.; Herrero, A.; Fusco, A.; Cameselle-Teijeiro, J.; Santoro, M. Mutation of the PIK3CA gene in anaplastic thyroid cancer. Cancer Res. 2005, 65, 10199–10207. [Google Scholar] [CrossRef] [Green Version]
Cancers 12 01973 g001 550
Figure 1. Anaplastic thyroid carcinoma. Common morphologic patterns include epithelial (a), sarcomatoid (b), and giant cell (c) pattern (H&E, 200×). Papillary carcinoma (d) and follicular carcinoma (e) coexist with the anaplastic component in an intermingled arrangement or with a sharp border (H&E, 100×). Cases positive for PAX8 (f), TTF-1 (g), and BRAF VE1 (h) immunostains are shown (200×).
Figure 1. Anaplastic thyroid carcinoma. Common morphologic patterns include epithelial (a), sarcomatoid (b), and giant cell (c) pattern (H&E, 200×). Papillary carcinoma (d) and follicular carcinoma (e) coexist with the anaplastic component in an intermingled arrangement or with a sharp border (H&E, 100×). Cases positive for PAX8 (f), TTF-1 (g), and BRAF VE1 (h) immunostains are shown (200×).
Cancers 12 01973 g001
Cancers 12 01973 g002 550
Figure 2. Summary of the mutational profile of the 27 cases of anaplastic thyroid carcinoma analyzed by next-generation sequencing and mass spectrometry. WDTC, coexisting well-differentiated thyroid carcinoma; P, papillary carcinoma; F, follicular carcinoma; pTERT, TERT promoter.
Figure 2. Summary of the mutational profile of the 27 cases of anaplastic thyroid carcinoma analyzed by next-generation sequencing and mass spectrometry. WDTC, coexisting well-differentiated thyroid carcinoma; P, papillary carcinoma; F, follicular carcinoma; pTERT, TERT promoter.
Cancers 12 01973 g002
Cancers 12 01973 g003 550
Figure 3. Survival analysis of anaplastic thyroid carcinoma (ATC). Kaplan–Meier survival analysis was performed with cases stratified by RAS mutations (a), PIK3CA exon 2 and exon 9 mutations (b), BRAFV600E mutation (c), TERT promoter mutation (d), and TP53 non-synonymous mutations (e). Survival differences were analyzed by log-rank test with significance at p value < 0.05 (bold type). WT, wild-type; pTERT, TERT promoter.
Figure 3. Survival analysis of anaplastic thyroid carcinoma (ATC). Kaplan–Meier survival analysis was performed with cases stratified by RAS mutations (a), PIK3CA exon 2 and exon 9 mutations (b), BRAFV600E mutation (c), TERT promoter mutation (d), and TP53 non-synonymous mutations (e). Survival differences were analyzed by log-rank test with significance at p value < 0.05 (bold type). WT, wild-type; pTERT, TERT promoter.
Cancers 12 01973 g003
Table
Table 1. Summary of clinicopathological features of 39 anaplastic thyroid carcinoma cases.
Table 1. Summary of clinicopathological features of 39 anaplastic thyroid carcinoma cases.
Age, n (%)
≤554 (10.3)
>5535 (89.7)
Gender, n (%)
Female20 (51.3)
Male19 (48.7)
Stage, n (%) a
IVA5 (13.9)
IVB11 (30.6)
IVC20 (55.6)
Surgery, n (%)
Subtotal thyroidectomy9 (23.1)
Total thyroidectomy24 (61.5)
Biopsy only6 (15.4)
Other Therapies b, n (%)
Chemotherapy7 (24.1)
Radioiodine6 (21.4)
External radiation7 (25)
Targeted therapy5 (15.1)
Tumor size c (cm)7.14
Histologic Pattern, n (%)
Epithelial+28 (71.8%)
-11 (28.2%)
Giant cell+5 (12.8%)
-34 (87.2%)
Sarcomatoid+17 (43.6%)
-22 (56.4%)
Coexisting WDTC, n (%)
PTC+10 (25.6)
-29 (74.4)
FTC+3 (7.7)
-36 (92.3)
a Of patients with available information regarding tumor stage. b Of patients with available information regarding therapies. c Median size of the tumors. WDTC, well-differentiated thyroid carcinoma; PTC, papillary thyroid carcinoma; FTC, follicular thyroid carcinoma.
Table
Table 2. Summary of the results of immunohistochemistry.
Table 2. Summary of the results of immunohistochemistry.
Case Numbern (%)
PAX8TTF-1BRAF VE1Retained MMR Proteins
All3922 (56.4)2 (5.1)10 (25.6)39 (100)
Coexisting WDTC
None2615 (5.8)2 (7.7)4 (15.4)26 (100)
PTC107 (70)06 (60)10 (100)
FTC30003 (100)
WDTC, well-differentiated thyroid carcinoma; PTC, papillary thyroid carcinoma; FTC, follicular thyroid carcinoma; MMR, mismatch repair.
Table
Table 3. Summary of clinicopathological features of 27 anaplastic thyroid carcinoma cases with stratification by BRAFV600E and RAS mutations.
Table 3. Summary of clinicopathological features of 27 anaplastic thyroid carcinoma cases with stratification by BRAFV600E and RAS mutations.
BRAFRASNon-BRAF/RASp Value
Case Number7119
Age, n (%)
≤551 (14.3)1 (9.1)2 (22.2)0.803
>556 (85.7)10 (90.9)7 (77.8)
Gender, n (%)
Female2 (28.6)10 (90.9)4 (44.4)0.012 *
Male5 (71.4)1 (9.1)5 (55.6)
Stage, n (%) a
IVA1 (14.3)0 (0)2 (25)0.445
IVB3 (42.9)4 (44.4)1 (12.5)
IVC3 (42.9)5 (55.6)5 (50)
Surgery, n (%)
Subtotal Tx1 (14.3)2 (18.2)4 (44.4)0.488
Total Tx6 (85.7)8 (72.7)4 (44.4)
Biopsy only01 (9.1)1 (11.1)
Other Therapies b, n (%)
Chemotherapy1 (16.7)3 (33.3)2 (33.3)0.851
Radioiodine1 (16.7)2 (22.2)0 (0)0.763
External radiation1 (16.7)4 (44.4)1 (20)0.568
Targeted therapy2 (33.3)1 (10)0 (0)0.314
Tumor size, cm5.17.87.50.253
Histologic Pattern, n (%)
Epithelial+6 (85.7)8 (72.7)6 (66.7)0.860
-1(14.3)3 (27.3)3 (33.3)
Giant cell+1 (14.3)1 (9.1)1 (11.1)1
-6 (85.7)10 (90.9)8 (88.9)
Sarcomatoid+1 (14.3)5 (45.5)7 (77.8)0.045 *
-6 (85.7)6 (54.5)2 (22.2)
Coexisting WDTC, n (%)
PTC+3 (42.9)2 (18.2)1 (11.1)0.369
-4 (57.1)9 (81.8)8 (88.9)
FTC+0 (0)1 (9.1)1 (11.1)1.000
-7 (100)10 (90.9)8 (88.9)
a Of patients with available information regarding tumor stage. b Of patients with available information regarding therapies * Statistically significant. Tx, thyroidectomy; WDTC, well-differentiated thyroid carcinoma; PTC, papillary thyroid carcinoma; FTC, follicular thyroid carcinoma.

Share and Cite

MDPI and ACS Style

Lai, W.-A.; Liu, C.-Y.; Lin, S.-Y.; Chen, C.-C.; Hang, J.-F. Characterization of Driver Mutations in Anaplastic Thyroid Carcinoma Identifies RAS and PIK3CA Mutations as Negative Survival Predictors. Cancers 2020, 12, 1973. https://doi.org/10.3390/cancers12071973

AMA Style

Lai W-A, Liu C-Y, Lin S-Y, Chen C-C, Hang J-F. Characterization of Driver Mutations in Anaplastic Thyroid Carcinoma Identifies RAS and PIK3CA Mutations as Negative Survival Predictors. Cancers. 2020; 12(7):1973. https://doi.org/10.3390/cancers12071973

Chicago/Turabian Style

Lai, Wei-An, Chih-Yi Liu, Shih-Yao Lin, Chien-Chin Chen, and Jen-Fan Hang. 2020. "Characterization of Driver Mutations in Anaplastic Thyroid Carcinoma Identifies RAS and PIK3CA Mutations as Negative Survival Predictors" Cancers 12, no. 7: 1973. https://doi.org/10.3390/cancers12071973

APA Style

Lai, W.-A., Liu, C.-Y., Lin, S.-Y., Chen, C.-C., & Hang, J.-F. (2020). Characterization of Driver Mutations in Anaplastic Thyroid Carcinoma Identifies RAS and PIK3CA Mutations as Negative Survival Predictors. Cancers, 12(7), 1973. https://doi.org/10.3390/cancers12071973

Note that from the first issue of 2016, this journal uses article numbers instead of page numbers. See further details here.

Article Metrics

Back to TopTop
