Open AccessArticle
Micromachines 2018, 9(3), 123;

Three-Dimensional Reservoir-Based Dielectrophoresis (rDEP) for Enhanced Particle Enrichment

Department of Mechanical Engineering, Clemson University, Clemson, SC 29634-0921, USA
Department of Chemical Engineering & Biotechnology, University of Cambridge, Cambridge CB3 0AS, UK
Authors to whom correspondence should be addressed.
Received: 25 January 2018 / Revised: 24 February 2018 / Accepted: 9 March 2018 / Published: 10 March 2018
(This article belongs to the Special Issue Micro/Nano-Chip Electrokinetics, Volume II)
Full-Text   |   PDF [2301 KB, uploaded 12 March 2018]   |


Selective enrichment of target species is crucial for a wide variety of engineering systems for improved performance of subsequent processes. Dielectrophoresis (DEP) is a powerful electrokinetic method that can be used to focus, trap, concentrate, and separate a variety of species in a label-free manner. The commonly employed methods for DEP suffer from limitations such as electrode fouling and high susceptibility to Joule heating effects. Recently, our group has demonstrated DEP-based manipulations of particles and cells using a novel method of reservoir-based dielectrophoresis (rDEP) which exploits the naturally produced electric field gradients at the reservoir-microchannel junction. Although this method reasonably addresses the limitations mentioned above while maintaining a high simplicity of fabrication, all of our demonstrations so far have used a two-dimensional rDEP, which limits the performance of the devices. This work aims to improve their performance further by making the DEP three-dimensional. Through detailed experimental and numerical analysis, we demonstrate a six-fold increase in the enrichment performance of latex beads and a significant reduction in the power consumption for the new devices, which would allow a more reliable integration of the same into micro-total analysis systems. View Full-Text
Keywords: dielectrophoresis; electrokinetics; particle focusing; particle trapping; microfluidics dielectrophoresis; electrokinetics; particle focusing; particle trapping; microfluidics
