Micromachines 2015, 6(10), 1459-1468;

Shielding Electric Fields to Prevent Coalescence of Emulsions in Microfluidic Channels Using a 3D Metallic Coil

HKU-Shenzhen Institute of Research and Innovation (HKU-SIRI), Shenzhen 518000, China
Department of Mechanical Engineering, University of Hong Kong, Hong Kong, China
Author to whom correspondence should be addressed.
Academic Editors: Andrew deMello and Xavier Casadevall i Solvas
Received: 14 August 2015 / Revised: 16 September 2015 / Accepted: 23 September 2015 / Published: 30 September 2015
(This article belongs to the Special Issue Droplet Microfluidics: Techniques and Technologies)
Full-Text   |   PDF [3012 KB, uploaded 30 September 2015]   |


In microfluidics, electric fields are widely used to assist the generation and the manipulation of droplets or jets. However, uncontrolled electric field can disrupt the operation of an integrated microfluidic system, for instance, through undesired coalescence of droplets, undesired changes in the wettability of the channel wall or unexpected death of cells. Therefore, an approach to control the distribution of electric fields inside microfluidic channels is needed. Inspired by the electro-magnetic shielding effect in electrical and radiation systems, we demonstrate the shielding of electric fields by incorporating 3D metallic coils in microfluidic devices. Using the degree of coalescence of emulsion drops as an indicator, we have shown that electric fields decrease dramatically in micro-channels surrounded by these conductive metallic coils both experimentally and numerically. Our work illustrates an approach to distribute electric fields in integrated microfluidic networks by selectively installing metallic coils or electrodes, and represents a significant step towards large-scale electro-microfluidic systems. View Full-Text
Keywords: droplet coalescence; electric field; microfluidics; coils; shielding droplet coalescence; electric field; microfluidics; coils; shielding

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).

Supplementary material


Share & Cite This Article

MDPI and ACS Style

Li, J.; Liu, Z.; Huang, H.; Shum, H.C. Shielding Electric Fields to Prevent Coalescence of Emulsions in Microfluidic Channels Using a 3D Metallic Coil. Micromachines 2015, 6, 1459-1468.
