Toxins 2017, 9(4), 139; https://doi.org/10.3390/toxins9040139

Article
Assessment of the Antimicrobial Activity and the Entomocidal Potential of Bacillus thuringiensis Isolates from Algeria
1
Microbiology Group, Laboratory of Cellular and Molecular Biology, Faculty of Biological Sciences, University of Science and Technology Houari Boumediene (USTHB), BP 32, EL ALIA, Bab Ezzouar, 16111 Algiers, Algeria
2
ERI BIOTECMED and Department of Genetics, Universitat de València, Dr. Moliner, 50, BURJASSOT, 46100 Valencia, Spain
3
Department of Science and Technology, Faculty of Science, University Dr Yahia Frès, 26000 Médéa, Algeria
*
Author to whom correspondence should be addressed.
Academic Editor: Vernon L. Tesh
Received: 14 March 2017 / Accepted: 11 April 2017 / Published: 13 April 2017

Abstract

:
This work represents the first initiative to analyze the distribution of B. thuringiensis in Algeria and to evaluate the biological potential of the isolates. A total of 157 isolates were recovered, with at least one isolate in 94.4% of the samples. The highest Bt index was found in samples from rhizospheric soil (0.48) and from the Mediterranean area (0.44). Most isolates showed antifungal activity (98.5%), in contrast to the few that had antibacterial activity (29.9%). A high genetic diversity was made evident by the finding of many different crystal shapes and various combinations of shapes within a single isolate (in 58.4% of the isolates). Also, over 50% of the isolates harbored cry1, cry2, or cry9 genes, and 69.3% contained a vip3 gene. A good correlation between the presence of chitinase genes and antifungal activity was observed. More than half of the isolates with a broad spectrum of antifungal activity harbored both endochitinase and exochitinase genes. Interestingly, 15 isolates contained the two chitinase genes and all of the above cry family genes, with some of them harboring a vip3 gene as well. The combination of this large number of genes coding for entomopathogenic proteins suggests a putative wide range of entomotoxic activity.
Keywords:
B. thuringiensis; antibacterial; antifungal; cry; vip3; chitinase; biocontrol

1. Introduction

The economies of most countries worldwide are based on agriculture, which are threatened by various phytopathogens such as bacteria, fungi, or insects. Up to now, B. thuringiensis is the most used biological agent for the control of insect pests, mainly Lepidopteran species, the most injurious pests of cereals [1,2], and palms [3,4], which are the most important cultivated crops in North Africa.
Bacillus thuringiensis is a ubiquitous Gram positive bacterium found in various ecological habitats such as soil, sediment, stored products, dust, dead insects, phylloplane, and aquatic environments [5,6,7,8,9,10,11]. It has been the subject of most of the research and applications in the biological control of phytopathogenic insects, mainly due to the entomotoxic properties of some strains. The main interest of its use is to replace chemical pesticides with a new sustainable alternative, that is biodegradable and friendly to the environment and public health. Cry and Vip proteins, synthesized during the stationary and the vegetative phase, respectively, form the primary axis in B. thuringiensis based biological control of insect pests. In addition, other molecules synthesized by this bacterium can either act in synergy with Cry and Vip proteins or as an antimicrobial agent against several pathogenic and/or phytopathogenic bacteria and fungi. These could be chitinases [12,13], acylhomoserine lactone lactonase [14,15], some lipopeptides [16,17,18], and certain antibiotics such as zwittermycin [19,20].
The Cry proteins (or δ-endotoxins) accumulate during sporulation producing crystalline inclusions with several morphologies [21,22,23,24]. They exhibit specific activity against one or several orders of insects belonging to the orders Lepidoptera, Diptera, and Coleoptera [22,25,26], mainly due to the specificity of membrane receptors [27,28]. These receptors are absent in beneficial insects, plants, and mammals [26,29]. The identification of B. thuringiensis isolates carrying a wide variety of cry genes suggests a broad entomotoxic spectrum against different insect hosts [30,31].
Vip proteins are known to complement or synergize the insecticidal activities of Cry proteins [32]. They are produced by certain B. thuringiensis strains and bind to receptors that are different from those of Cry proteins [33,34], and thus, they have a spectrum of activity complementary to that of the Cry proteins. Therefore, a combination of Cry and Vip proteins could broaden the spectrum of insecticidal activity [35,36,37,38] and prevent the evolution of resistance of insects to Cry proteins [39,40,41].
A threat to the B. thuringiensis-based insecticides is the development of resistance by the insect populations exposed to them or to transgenic crops expressing their insecticidal proteins (Bt-crops) [39,42]. Therefore, the search for novel genes or new alleles encoding for insecticidal proteins, or other type of biomolecules that could synergize the action of the Cry and Vip proteins, is highly desirable.
Chitinases are enzymes that hydrolyze chitin (β-1,4-N-acetyl-aligned-glucosamine polymer), the main component of the invertebrates’ exoskeleton and fungi outer wall. They have been used for a long time to control several fungal pests [12,13,43,44,45], as synergistic agents to increase the entomotoxicity of biopesticides [46,47,48,49,50] and in the production of recombinant strains of B. thuringiensis [51,52] or transgenic plants [53,54]. Within the insect, chitinase potentiates the toxicity of the B. thuringiensis Cry proteins by perforating the peritrophic barrier of the midgut of the larvae, and thus, increasing the access of δ-endotoxins to the receptors located in the outer membrane of the epithelial cells [47]. The subsequent pores that are formed facilitate the penetration of spores in the hemolymph [46,48].
The aim of the present study was to screen B. thuringiensis isolates for the presence of a wide variety of biomolecules with the potential for insect, bacterial, and fungi control. This is the first initiative to perform a country-wide study of this bacterial species in Algeria, a Mediterranean country with a vast area (about 2382 million km2), large landscape diversity, and a high variability of climatic regions (Mediterranean, Sub-arid, and Desert).

2. Results

2.1. Isolation and Distribution of B. thuringiensis Isolates

A total of 157 crystalliferous colonies (B. thuringingiensis) were isolated from 54 samples collected from five ecological niches (rhizospheric and non rhizospheric soil, sediment, dead insects, and grain storage) distributed over three geographical areas of Algeria viz., Mediterranean, Semi-arid, and Desert (Table 1 and Figure 1).
As shown in Table 1, B. thuringiensis was found in 51 (94.4%) out of the 54 collected samples. It was present with a high recovery (more than 50%) in all the ecological sources. With respect to the geographical origin, 100% of the samples collected from the Mediterranean and Semi-arid area harbored B. thuringiensis isolates, whereas their frequency in the Desert was 78.6%. The global Bt index was 0.41 and it varied considerably depending on the sample source. Within the different ecological niches, it ranged from 0.27 (in the non-rhizospheric soil) to 0.48 (in the rhizospheric soil). Regarding the geographical distribution, the Bt index varied from 0.32 (in samples from the Semi-arid area) to 0.44 (in samples from the Mediterranean area). The highest Bt index (0.51) was obtained with samples collected from rhizospheric soil either in the Mediterranean area or from the Desert.
From the original 157 B. thuringingiensis isolates, 137 were chosen for further phenotypic, biological, and molecular characterization.

2.2. Phenotypic Characterization of Parasporal Crystals

Based on the morphology of the crystalline inclusions (independent of whether they were present alone or in combination with other shapes), the isolates were classified into seven groups (Table 2). The most abundant shape was spherical (64.2% of isolates) and the least abundant one was the elongate crystal (3.6%). An example of the observed shapes is shown in Figure 2.
Regarding the number of different crystal shapes found within the same strain, 57 out of the 137 isolates (41.6%) harbored only one crystal shape, while 80 isolates (58.4%) had several shapes including 59 (43.1%) with two shapes and 21 (15.3%) having more than two shapes. We also observed that the most abundant combination was spherical-bipyramidal (10.9%) followed by spherical-geometrical (8%), spherical-triangular (4.4%), bipyramidal-geometrical (3.6%), and spherical-cuboidal (2.9%). The cuboidal and elongate crystal shapes were present only when combined with other crystal shapes.

2.3. Screening of the Biological Activity

2.3.1. Antibacterial Activity

Bacillus thuringiensis isolates were tested for their antibacterial activity against four pathogenic bacteria, two Gram positive (Staphylococcus aureus including a wild type variant (SM) and a resistant to methicillin variant (RM)), and two Gram negative (Escherichia coli and Pseudomonas aeruginosa) (Figure 3A). Among the 137 B. thuringiensis isolates, 41 (29.9%) showed activity against at least one tested pathogenic bacteria (Table 3). Considering each test bacterium independently, 30 B. thuringiensis isolates were active against S. aureus SM (21.9%), 27 isolates were active against S. aureus RM (19.7%), 20 against E. coli (14.6%), and 10 against P. aeruginosa (7.3%). Table 3 summarizes the combined/single antibacterial activity of those isolates.

2.3.2. Antifungal Activity

The antifungal activity of B. thuringiensis isolates was tested against five phytopathogenic fungi (Figure 3B). Almost all isolates tested (135 out of 137) exhibited activity against at least one fungus and 81 (59%) isolates were active against at least three fungi (Table 4). Considering each test fungus independently, 106 B. thuringiensis isolates (77.4%) inhibited the growth of Aspergilus niger, 98 isolates (71.5%) were active against Colletotricum sp., 81 (59.1%) against Monilia sp., 65 (47.4%) against Thielaviopsis sp., and 54 (39.4%) against Fusarium sp. Table 4 summarizes the combined/single antifungal activity of those isolates.

2.4. Molecular Screening

2.4.1. cry and vip Gene Families (cry1, cry2, cry9, and vip3)

Identification of gene-families coding for lepidopteran-active toxins was carried out with universal primers used for amplifying the cry1, cry2, cry9, and vip3 genes (Table 5). Isolates giving an amplicon of the expected size were considered positive to the corresponding gene-type (Figure 4). Table 6 shows that out of the 137 B. thuringiensis isolates, 112 (82%) were positive for at least one cry gene. Genes from the cry1, cry2, and cry9 families occurred in 54%, 59.9%, and 50.4% of the isolates, respectively. The vip3 gene was found in 95 (69.3%) of the isolates, 13 of which did not contain any other lepidopteran-active toxin gene.

2.4.2. Exochitinase (chi36) and Endochitinase (chit) Genes

The occurrence of exochitinase and endochitinase genes was assessed by PCR amplification using gene-specific primers (Table 5 and Figure 5). Overall, 88 (64.2%) of the 137 B. thuringiensis isolates harbored at least one type of the chitinase gene, with 66 (48.2%) being positive for the exochitinase gene and 82 (59.9%) being positive for the endochitinase gene (Table 6). Sixty isolates (43.8%) harbored both types of genes and 28 (20.4%) exhibited only one of them.
Table 7 shows the relationship between the chitinase genes content and the spectrum of antifungal activity. Among the 81 B. thuringiensis isolates showing a wide spectrum against at least three fungi, 50 isolates harbored both exochitinase and endochitinase genes, and out of the 54 isolates with a narrower spectrum of antifungal activity, 27 were negative for both chitinase genes.

3. Discussion

The current work is the first initiative to perform a country-wide study of B. thuringiensis in Algeria. A collection of 157 B. thuringiensis isolates was built from samples collected from various niches (soil, sediment, dead insects, and grain storage) in three different climatic regions (Mediterranean, Semi-arid, and Desert). In all locations, no Bt-based biopesticide had been previously applied. Overall, 94.4% of the samples collected yielded at least one colony of B. thuringiensis. This high recovery reflected the large abundance of this species in Algeria. It is comparable to that found in earlier studies surveying various ecosystems, where B. thuringiensis recovery was over 79% [58,59,60]. Our results confirm the ubiquity of B. thuringiensis, since it was detected in samples from all the ecological and geographical habitats analyzed, including very arid ecosystems.
The global Bt index observed was relatively high (0.41) compared to earlier screening programs (less than 0.18) [10,58,61,62]. The Bt index differed among the different climatic regions (from 0.32 to 0.44) with the Mediterranean area being the richest source (0.44) (Table 1). It was relatively high to moderate in all niches (from 0.27 to 0.48). In agreement with earlier studies, samples from rhizospheric soil [58,60] and grain storage [61] were better sources for B. thuringiensis isolation (Bt index was 0.48 and 0.39, respectively). We found the non-rhizospheric soil to be the one with the lowest Bt index (0.27), also in agreement with previous studies [63,64,65,66]. This difference may be related to different factors, mainly the vegetation abundance, which constitutes a nutrient supply and an extra source of B. thuringiensis isolates, and also the physicochemical features of the biotope, as well as the presence of other symbiotic bacteria. In this context, several studies described the widespread presence of B. thuringiensis in the phylloplane [67,68,69,70]. Therefore, when performing screening of B. thuringiensis from soil samples, it would be important to distinguish between rhizospheric and non-rhizospheric soil samples.
The frequency values of the crystal shapes given in Table 2 refers to how often a given shape is found in the 137 B. thuringiensis isolates, independent of whether it was combined with other shapes or not. Despite the fact that bipyramidal crystals are generally reported to be the most abundant ones [9,10,71,72], in our collection the crystals with a spherical shape were the most abundant (64.2% of the isolates) (Table 2). The latter were found at a similar high frequency (about 40%) in studies carried out in Colombia [69] and Spain [59], but at very low frequency in other studies from Iran (5%) [10] and India (3.6%) [72]. Bipyramidal and irregular/geometrical crystal shapes were also frequent within the Algerian collection (33.6% and 40.1%, respectively). This percentage is comparable to that found in a study from India (28% and 21.5%, respectively) [72]. Triangular and cuboidal crystal shapes were present in 13% and 11.7% of our isolates, respectively. The differences in the distribution of the crystal shapes could be a consequence of the adaptation of this bacterium to the biotope.
A high percentage of our B. thuringiensis isolates (58.4%) produced more than one crystal shape (Table 2). This percentage is relatively high when compared to those found by Seifinejad et al. (40%) [10] and Mahadeva Swamy et al. (36%) [72]. Among the diverse combinations observed, spherical crystals were found combined with bipyramidal crystals (10.9%), geometrical crystals (8%), triangular crystals (4.4%), and cuboidal crystals (2.9%). These results demonstrated the high diversity and variability of the native B. thuringiensis isolates from Algeria and reflected their genetic diversity.
Some crystal shapes have been related to the expression of specific Cry proteins [24,55,68,71]. For example, the expression of cry4, cry10, or cry11 genes give rise to spherical shape crystals, and their respective proteins are known to be active against Diptera [73,74,75,76]. Crystals with a bipyramidal shape result from the accumulation of Cry1 or Cry9 proteins, which are active mainly against Lepidoptera [24,77,78]. Cry2 proteins, some of which are active against both Lepidoptera and Diptera, form cuboidal crystals [24,77,78,79]. Therefore, the combination of several crystal shapes within an individual B. thuringiensis isolate, which is an indication of the presence of Cry proteins from different families, holds the potential for a spectrum of activity against a broad range of insect pests [30,31].
Overall, 29.9% of the B. thuringiensis isolates in our collection were active against at least one pathogenic bacterium. Three isolates inhibited all four pathogenic bacteria, including the resistant variant of S. aureus. This reflected a wide range of antibacterial molecules synthetized by these B. thuringiensis isolates, which could be further used in the control of some pathogenic and/or phytopathogenic diseases. It would be interesting to survey those isolates against some phytopathogenic bacteria causing serious losses in fruits and vegetables in Algeria, such as Erwinia amylovora and Erwinia carotovora [80,81]. In 2012, Djenane [82] investigated 97 isolates of Bacillus spp. and showed that the most potent Bacillus species in terms of antibacterial activity do not belong to the B. thuringiensis species, but mainly to B. amyloliquefasiens and B. subtilis. The same finding was reported by Mora et al. [83], who found that the B. thuringiensis species belonged to the group of plant-associated bacteria with the lowest antimicrobial activity.
It is important to note that in the reported antibacterial activity of B. thuringiensis isolates from our study, the activity was observed after 24 h using a fresh culture on the surface of a rich medium (MHA plates). These conditions are appropriate for bacterial growth but not for B. thuringiensis sporulation. Thus, some molecules synthetized during the stationary phase, and exhibiting an antibacterial activity, such as Cry11A and Cry4B [84], the 28 kDa and 37 kDa fragments from Cry1A, and the 49 kDa fragment from Cry3Aa [85], could not have contributed to the reported activity.
Bacillus thuringiensis isolates collected in Algeria form a good source of antifungal-specific candidates (98%) compared to the antibacterial ones (29.9%). It might be a consequence of the adaptation of this bacterium to the appropriate biotope (soil, phylloplane, grain storage, dust), where fungus proliferation is common. More than 60% of the isolates showed activity against Monolia sp., Colletotricum sp., and A. flavus, 47% against Thielaviopsis sp., and 39% against Fusarium sp. Moreover, 59% of the isolates exhibited broad spectrum activity against at least three phytopathogenic fungi and, among them, 24 isolates (17.5%) were active against all the five fungi tested. These high antifungal potentials could be related to a panoply of antimicrobial molecules such as zwittermycin [86], lipopeptides [17,83,87], and chitinase [12,13,43,44]. Earlier surveys showed the contribution of lipopeptides to the antifungal activitiy in some Bacillus species [16,83,87,88]. The latter was confirmed in B. thuringiensis strains from Algeria by Abderrahmani et al. [17,89]. The 24 isolates with the highest spectrum of activity could be good candidates to control fungal pests of serious economic impact in agriculture, both in North Africa and the rest of the world [90,91]. Specifically, in Algeria, the most injurious fungus species affecting palms are Fusarium oxysporum, the causal agent of ‘bayoud’, or Fusarium wilt [92,93], and Thielaviopsis paradoxa, the agent of the black scorch disease [94,95]. Different species of the genus Fusarium also affect cereals [2,96], forest trees (Aleppo Pine) [97,98], vegetables [99], and legumes [100]. Similar to the antibacterial activity, earlier studies showed that B. thuringiensis isolates were less potent, in terms of antifungal activity, compared to other Bacillus species such as B. amyloliquefaciens and B. subtilis [82,83].
Other than lipopeptides, chitinase enzymes exhibit a strong antifungal activity [12,13,43,44,45]. In the current work, a good correlation between the presence of both chitinase genes in B. thuringiensis isolates and their broad antifungal activity was observed. Essentially, more than half of the isolates (ratio 0.6) showing a broad spectrum of antifungal activity (against at least three fungi) had both chitinase genes (Table 7). These isolates would form the best candidates for fungal pest control. A synergistic activity between chitinase enzymes and other biomolecules could enhance and broaden the antifungal activity. However, it is interesting to note that 20 isolates had a broad spectrum of antifungal activity but did not exhibit any of the tested chitinase genes. Thus, possibly other chitinases and/or other antifungal molecules could be involved in that high antifungal activity.
Lepidoptera-specific insecticidal protein genes were present in a high frequency within the Algerian collection of B. thuringiensis: 82% of the 137 isolates harbored at least one cry gene, which is similar to what was found in earlier surveys investigating cry1, cry2, and cry9 genes [10,66,101]. Every cry gene family was found in more than half of the isolates (54% cry1, 60% cry2, and 50% cry9). Among the isolates containing a cry1 gene, 76% carried a cry2 gene and 58% carried a cry9 gene. Among those containing a cry2 gene, 68% and 60% carried a cry1 and a cry9 gene, respectively; and among those containing a cry9 gene, 62% and 71% carried a cry1 and a cry2 gene, respectively. Previous studies [9,55,62] suggested that the cry1 and cry2 genes are genetically associated since they occur together in a high frequency. Several complete genome sequencing programs described that many cry genes (most of them belonging to the cry1 and cry2 families) are located on the same plasmid [102,103,104,105,106]. This could also explain the pair-wise co-occurrence of the cry1, cry2, and cry9 genes within the Algerian B. thuringiensis collection.
The vip3 gene family was also present in a high percentage of the isolates (69.3%). This high frequency of vip3 genes was previously found by Seifinejad et al. [10] (82% out of the 70 B. thuringiensis isolates from Iran), Yu et al. [107] (67.4% of the 2134 B. thuringiensis isolates from China), and Hernández-Rodríguez et al. [57] (48.9% of the 507 B. thuringiensis isolates from Spain).
In our study, the genetic diversity observed among isolates based on the morphological variability of crystal shapes (58.4% of the isolates harbored more than one crystal shape) correlated with the diversity in cry genes. Despite the fact that we studied only three cry gene families coding for crystals with a cuboidal shape (cry2) and bipyramidal/geometrical shape (cry1 and cry9), 58% of B. thuringiensis isolates from Algeria contained more than one cry gene family, of which 35 (25%) contained all three studied cry genes.
Relating the results of the cry gene content with the chitinase gene content may help to select isolates with a wider spectrum of activity, since the chitinase activity was described to help synergize the effect of Cry toxins [46,47,50]. Table 6 shows that many of the isolates have a high potential for insecticidal activity because they contain a wide set of entomotoxic protein genes. Interestingly, 15 isolates contained all the three studied cry gene families as well as exochitinase and endochitinase genes and, among these, 11 also carried a vip3 gene (data not shown). These isolates could be preselected as putative candidates with a high and broad spectrum of insecticidal activity due to a possible synergistic action of several insecticidal molecules. Further entomotoxic assays against a wide range of lepidopteran species would help to select the best candidate for biological control.

4. Conclusions

In summary, the current work showed that Algerian samples are a good source of B. thuringiensis isolates with potential applications in agricultural pest control. A high abundance of this species was noted within the different ecological and geographical sources. Also, a high number of isolates showed a strong activity against phytopathogenic fungi, which could be related to the role of this bacterium in its natural habitat. In addition, molecular screening evidenced the high genetic diversity of B. thuringiensis isolates in terms of cry, vip3, and chitinase gene content. This study lays the basis to select those B. thuringiensis isolates, with a wide set of entomotoxic genes, to be subjected to a screening program to evaluate their insecticidal activity in bioassays with lepidopteran pests.

5. Materials and Methods

5.1. Sample Collection

A total of 54 samples were collected from different habitats (soil, sediment, stored grains and dead insects) from 20 different locations within the Algerian territory (Table 1 and Figure 1). The source of these samples had no history of treatment with any bio-pesticide. Soil samples were collected with a sterile scraper at a depth of 10–15 cm after removing the top layer of soil. Dust or grains were collected by scooping directly from the floor or with machinery from storage. All samples including dead insects were directly transferred into sterile plastic bags and stored at 4 °C until processed.

5.2. Reference Strains

The pathogenic bacteria used for the antibacterial test belonged to the American Type Collection Culture. The species and strains used were Pseudomonas aeruginosa ATCC25853 (P. aeruginosa), Escherichia coli ATCC25922 (E. coli), Staphylococcus aureus sensitive to methicillin ATCC25923 (S. aureus SM), and Staphylococcus aureus resistant to methicillin ATCC34300 (S. aureus RM).
The phytopathogenic fungi, used for the antifungal test, were kindly provided by the Algerian National Institute for Plant Protection (Fusarium sp., Colletotrichum sp., Monilia sp., Thielaviopsis sp., and Aspergilus niger).

5.3. Bacillus Thuringiensis Culturing and Isolation

Isolation of B. thuringiensis was carried out according to the method of Travers et al. [108] with slight modifications. One gram from each sample was suspended in 9 mL sterile physiological solution (0.9% NaCl). This stock solution was heated at 70 °C for 10 min and then used to prepare 10−1, 10−2, and 10−3 dilutions. An aliquot (100 µL) of each solution was spread onto three Nutrient Agar (NA) plates. The plates were incubated at 30 °C for at least 3 days. The preselected Bacillus like-colonies (whitish, not bright, flat, dry, rough surface, and irregular border) were examined by phase-contrast microscopy. Only colonies containing bacillary cells producing spores and crystals (phase-bright inclusions) were selected as B. thuringiensis. Within the same sample, when colonies showed a similar macroscopic and/or microscopic aspect, only one colony was selected. Thereby, we reduced the number of sibling strains and avoided duplicates. The selected B. thuringiensis colonies were plated again for single-colony purification and stored at −20 °C in 20% and 50% glycerol medium. The Bt index was defined as the number of crystalliferous colonies as a fraction of Bacillus-like colonies in a sample; it serves as an estimation of the success in B. thuringiensis isolation and depends on the isolation procedure as well as the sampled material [59]. Since SDS-PAGE or Western blot was not performed, it cannot be ruled out that some of the observed parasporal inclusions are non-proteinaceous.

5.4. Screening for Antibacterial Activity with the Agar Plug Diffusion Method

The presence of antibacterial activity was tested using a technique similar to that used in the disk-diffusion method [109,110], which is based on the NCCLS diffusion method [111]. The target bacteria (S. aureus, P. aeruginosa, and E. coli) were inoculated on the surface of NA plates and incubated at 37 °C for 24–48 h. Then, three to five isolated colonies were suspended in saline (physiological water 0.9%). The turbidity of the test suspension was adjusted to 0.5 McFarland turbidity standard (corresponding to 1.5 × 108 CFU mL−1), and used as an inoculum within the following 15 min. On the surface of Mueller Hinton Agar (MHA) plates (4 mm of depth), the suspension was spread by swabbing. The B. thuringiensis agar-plugs were cut aseptically from pre-inoculated NA plates (4 mm depth) after 24 h of incubation at 30 °C, using a sterile cork borer. Four agar-plugs, containing a single colony each and corresponding to four different B. thuringiensis isolates, were transferred onto the surface of MHA plates. The antibacterial activity was observed by the appearance of a growth inhibition zone around the B. thuringiensis agar-plug (Figure 3A) and, for comparison purposes, it was expressed as the diameter of the inhibition zone measured after 24 h of incubation at 37 °C.

5.5. Screening for the Antifungal Activity

The antifungal activity was tested using the dual culture method [110,112] with slight modifications. Each fungal strain was spot-inoculated on Potato Dextrose Agar (PDA) plates and incubated for 7 days at 28 °C. A series of six mm diameter plugs were cut out from these fungal cultures (test fungi) using a sterile cork borer. Similarly, 6 mm B. thuringiensis plugs containing a single colony (tested bacterium) were obtained from pre-inoculated NA plates as described in the antibacterial activity method. The dual culture method consists on culturing both fungal and bacterial plugs together under the appropriate conditions of the fungal strains.
On the surface of PDA plates, fungal and bacterial plugs were aseptically transferred using a sterile toothpick. The fungal plug of one test fungus was placed at the center of the plate and three bacterial test plugs, corresponding to three different B. thuringiensis isolates, were deposited radially 2.5 cm away, leaving a fourth position in the plate empty as a negative control. After incubation at 28 °C for 3 to 7 days, the radius of fungal growth facing the bacterial plug or control position was measured. The antifungal effect of the B. thuringiensis isolates (Figure 3B) was estimated by the “inhibition radius” (IR), which is inversely proportional to the antifungal potency. The IR is defined as Rs/Rc, where, Rs and Rc correspond to the fungal growth facing the tested bacterium (B. thuringiensis isolates) and the control position, respectively (Figure 3B1).

5.6. DNA Extraction and PCR Analysis

Total DNA from B. thuringiensis isolates was extracted following the method described by Ferrandis et al. [113]. The polymerase chain reaction (PCR) was used for the screening of endo-chitinase, exo-chitinase, and lepidopteran-active protein coding genes cry1, cry2, cry9, and vip3. Each amplification process was performed in a 25 µL reaction mixture containing 1.0 U of Taq DNA polymerase (BIOTOOLS B&M Labs, S.A., Madrid, Spain), 1× Taq polymerase buffer, 0.4 µM of each primer, 2.5 mM MgCl2, 0.2 mM of dNTPs, and 1.0 µL of DNA template (about 100 ng/µL). All PCR reactions were performed in an Eppendorf Mastercycler thermal cycler (Eppendorf AG, Barkhausenweg, Germany). The amplification protocol consisted of an initial denaturation step of 4 min at 94 °C, 35 cycles of denaturation (94 °C for 40 s), annealing (50 °C for 1 min for cry2, vip3, and exochitinase, 50 °C for 45 s for cry9 and endochitinase, and 48 °C for 50 s for cry1), and extension (72 °C for 1–2 min), and a final extension step at 72 °C for 7 min. PCR products were analyzed in a 1% agarose gel containing 0.5 µg/mL ethidium bromide. Primers used for the molecular screening were selected from previous studies, except the vip3 reverse primer, which was designed from a conserved region (from 1442 to 1472) based on the alignment of previously published sequences of vip3 genes [114]. Primers’ sequence, melting temperature, and expected amplicon size are shown in Table 5.

Acknowledgments

This work corresponds to a part of PhD thesis of Djenane, Z. Part of this work was supported by the PNE research grant from the Algerian Ministry of Higher Education and Scientific Research (No. 100/PNE/ENS./ESPAGNE/2015-2016), by the Spanish Ministry of Science and Innovation (grant Ref. AGL2015-70584-C2-1-R), by a grant of the Generalitat Valenciana, Spain (GVPROMETEOII-2015-001), and by European FEDER funds.

Author Contributions

J.F. and F.N. conceived and designed the experiments; Z.D. performed isolation of the B. thuringiensis strains, biological and molecular characterization, and wrote the manuscript. J.G.-C. contributed to the primer design of vip3-scII(r) and the molecular screening. M.A., F.E.-A., and H.K. performed the isolation and antimicrobial characterization of 57 isolates of the B. thuringiensis collection. All the experiments, results analysis, and manuscript revision, which correspond to a part of PhD thesis of Z.D. were performed under the supervision of J.F. and F.N.

Conflicts of Interest

The authors declare no conflict of interest.
