High Spatial Resolution Remote Sensing for Salt Marsh Mapping and Change Analysis at Fire Island National Seashore

1
Department of Natural Resources Science, University of Rhode Island, Kingston, RI 02881, USA
2
Currently at the Yale School of Forestry & Environmental Studies, New Haven, CT 06511, USA
*
Author to whom correspondence should be addressed.
Remote Sens. 2019, 11(9), 1107; https://doi.org/10.3390/rs11091107
Received: 3 April 2019 / Revised: 30 April 2019 / Accepted: 6 May 2019 / Published: 9 May 2019
(This article belongs to the Special Issue Remote Sensing Applications in Monitoring of Protected Areas)
  |
PDF [5869 KB, uploaded 9 May 2019]
  |

Abstract

Salt marshes are changing due to natural and anthropogenic stressors such as sea level rise, nutrient enrichment, herbivory, storm surge, and coastal development. This study analyzes salt marsh change at Fire Island National Seashore (FIIS), a nationally protected area, using object-based image analysis (OBIA) to classify a combination of data from Worldview-2 and Worldview-3 satellites, topobathymetric Light Detection and Ranging (LiDAR), and National Agricultural Imagery Program (NAIP) aerial imageries acquired from 1994 to 2017. The salt marsh classification was trained and tested with vegetation plot data. In October 2012, Hurricane Sandy caused extensive overwash and breached a section of the island. This study quantified the continuing effects of the breach on the surrounding salt marsh. The tidal inundation at the time of image acquisition was analyzed using a topobathymetric LiDAR-derived Digital Elevation Model (DEM) to create a bathtub model at the target tidal stage. The study revealed geospatial distribution and rates of change within the salt marsh interior and the salt marsh edge. The Worldview-2/Worldview-3 imagery classification was able to classify the salt marsh environments accurately and achieved an overall accuracy of 92.75%. Following the breach caused by Hurricane Sandy, bayside salt marsh edge was found to be eroding more rapidly (F1, 1597 = 206.06, p < 0.001). However, the interior panne/pool expansion rates were not affected by the breach. The salt marsh pannes and pools were more likely to revegetate if they had a hydrological connection to a mosquito ditch (χ2 = 28.049, p < 0.001). The study confirmed that the NAIP data were adequate for determining rates of salt marsh change with high accuracy. The cost and revisit time of NAIP imagery creates an ideal open data source for high spatial resolution monitoring and change analysis of salt marsh environments. View Full-Text
Keywords: Salt marsh; change analysis; Worldview-2; Worldview-3; NAIP aerial data; Topobathymetric LiDAR; Fire Island National Seashore Salt marsh; change analysis; Worldview-2; Worldview-3; NAIP aerial data; Topobathymetric LiDAR; Fire Island National Seashore
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
SciFeed

Share & Cite This Article

MDPI and ACS Style

Campbell, A.; Wang, Y. High Spatial Resolution Remote Sensing for Salt Marsh Mapping and Change Analysis at Fire Island National Seashore. Remote Sens. 2019, 11, 1107.
