Abstract
Current industrial developments, advanced farming techniques, and further anthropogenic activities are adding substantial amounts of heavy metals into the ecosystem and having dangerous effects on lifeforms, including plants and animals, and changing their biological activities. Decontamination following the heavy metal contamination is an important point deserving attention in the current scenario. Among all the other approaches used for this purpose, bioremediation is ecofriendly and green approach that can be used to remediate heavy metal toxicity. In plant cells, the regulation of ionic homeostasis is a primary physiological prerequisite for upholding plant development, growth, and production. To avoid the dreadful effects of toxic heavy metal exposure, plants manifest physiological, biochemical, and structural responses. In the present research, we reported on the isolation and molecular identification of an effective heavy-metal-tolerant bacterial strain, Staphylococcus lentus (E3), having a minimum inhibitory concentration of 300 µg/mL for chromium, Cr, taken from soil polluted with industrial effluents at Kasur, Pakistan. Bacterial inoculations enhanced all the growth parameters of Triticum aestivum and Helianthus annus. To observe the physiological strain, the proline content and peroxidase (POD) activities were estimated under Cr stress in the bacterial-inoculated plants. The chlorophyll content and Cr uptake in the aerial parts the of plants were also studied, along with the overexpression of proteins. The bacterial inoculations produced encouraging results. Bioremediation using PGPR is an efficient, convincing, and reliable approach to attenuating heavy metal toxicity.
1. Introduction
Rapid urbanization and industrialization have resulted in the dramatic utilization of heavy metals. The unregulated disposal of industrial effluents, containing toxic heavy metals, in our surroundings causes devastation to the ecosystem. Chromium (Cr) metal, present in industrial discharges, is considered to be extremely toxic and is often found in the form of dichromate and chromate ions [1]. Chromium is found in the transition elements and is widely used in cement, electroplating, wood preservatives, textile, pigments, and paints, and in the dyeing, steel fabrication, canning, and leather-tanning industries [2]. The oxidation state of Cr determines its fate in ecosystems. Chromium exists in various oxidation states, with a range from Cr2+ to Cr6+, but the trivalent and hexavalent forms of Cr are commonly present and are highly stable, showing remarkable effects on organisms [3]. At all the pH levels, Cr6+ is soluble in water, as Cr3+ either precipitates in the form of Cr (OH)3 or adsorbs on the surface of the soil. Thus, trivalent Cr contaminates the environment and depletes the surface water and aquifers [4]. The Environmental Protection Agency (EPA) lists Cr6+ as a Group ‘A’, which is a major pollutant and human carcinogen. Both the hexavalent and trivalent forms of Cr are causes of allergic contact dermatitis. Hexavalent chromium, Cr (VI), is highly soluble and readily bioavailable, and under neutral conditions, trivalent chromium has less solubility and toxicity and cannot cross the membranes of the cell [5]. Because of its carcinogenicity, mutagenicity, and teratogenicity in plants, humans, and animals, Cr (VI) is classified as a group ‘A’ human carcinogen [6]. Thus, it is necessary to treat this harmful pollutant before disposing of it. Some conventional methods, including adsorption, reduction, ion exchange, precipitation, and electrodialysis, have been used for the treatment of industrial waste containing Cr (VI), but they have some disadvantages, which include a higher consumption of reagents, production of toxic sludges, energy requirements, and incomplete metal removal, and they are not economical [7]. Additionally, a large number of these methods have limitations. They are economically viable at very high or moderate metal concentrations but are not viable at low concentrations. Due to these difficulties, the strategy of bioremediation for the detoxification of heavy metals has vast implications [8]. Therefore, a great interest in microbe-metal interactions has emerged in the past few decades, as investigators and industrialists learn to eliminate, stabilize, or recover heavy metals in effluents and soil. Microbial products and microorganisms are efficient in eliminating particulate and soluble forms of metals, particularly from dilute solutions, through bioaccumulation. Thus, microbe-based technologies provide an alternative [9]. Though the levels of Cr (VI) are toxic to many microbes, various resistant bacterial species have been identified, which could ultimately be employed in strategies of remediation. An initial site evaluation is required for the formulation of an in-situ method that can be used to remove Cr (VI) efficiently, followed by bacterial strain selection, which is based on the extent of contamination [10]. In a recent study, a strain of Escherichia coli isolated from heavily polluted soil was used to efficiently reduce Cr (VI) to the less toxic Cr (III) form [11]. Another study reported a similar strategy of reducing Cr (VI) to a less harmful form, trivalent chromium (Cr3+), using Bacillus sp. [12]. Keeping in view the microbial potential of bioremediation, the present study was designed to isolate and identify a potential microbial agent displaying a strong potential to reduce the Cr metal present in industrial wastewater. The technology used for the removal of Cr (VI) should adhere to regulatory requirements and standards. In general, many heavy metals are constantly released by the industries into open environments, where these metals produce deleterious effects on our ecosystem. The identified bacterial strains could be adopted as an emerging technology that can be used to minimize the deleterious effects of other heavy-metal-related problems [13].
2. Materials and Methods
2.1. Industrial Effluent Sample Collection
Industrial effluent samples containing heavy metals were collected from leather industries in Kasur (31.1179° N, 74.4408° E), Pakistan. The samples were collected in clean screw-capped bottles, properly labeled, and transported to the laboratory within 8 h. All the collected samples were processed immediately for the isolation of bacterial strains.
2.2. Isolation and Identification of Cr-Tolerant Bacterial Strain
Heavy-metal-tolerant bacterial strains were isolated from the collected water samples following the spread plate procedure [11]. In brief, wastewater was serially diluted, and a 100 µL of appropriate dilution was spread over L-agar-containing plates, followed by incubation for 24 h at 37 °C. After incubation, the pure bacterial colonies with distinct characteristics were selected and streaked on the L-agar plates, freshly supplemented with 150 µg/mL Cr. Successfully grown bacteria were further cultured on Petri plates containing Cr at a 500 µg/mL concentration until the bacterial proliferation was completely inhibited by the Cr. The chromium level that completely inhibited the bacterial growth was designated as the minimum inhibitory concentration (MIC). The bacterial strains that were unable to grow at any Cr level were discarded; only the Cr-tolerant strains were further exposed to a higher Cr concentration of 300 µg/mL. Four bacterial strains showing tolerance at up to 300 µg/mL were selected for further studies. After that, in the screening process, the further molecular identification of these bacterial strains was performed by amplifying the 16S rDNA region using universal primers: 27 F (5′-AGA GTT TGA TCC TGG CTC AG-3′) and 1462 R (5′-GGT GTT TGA TTG TTA CGA CTT-3′). The final sequences were submitted to the GenBank database in order to assign accession numbers to the nucleotides (https://www.ncbi.nlm.nih.gov/genbank/, accessed on 3 March 2018).
2.3. Seed Sample Procurement and Sterilization
Certified seeds of Triticum aestivum (variety, FSD. 08) and Helianthus annus (NKS 278) were procured from Punjab Seed Corporation, Lahore. Healthy seeds were surface-sterilized by treating them with 0.1% HgCl2 solution for 3–4 min and then repeatedly washed (5–6 times) with sterilized distilled water. All the seeds were placed on blotter paper to absorb the excessive moisture.
2.4. Bacterial Inoculations and Chromium Treatments
Bacterial strains were grown for 24 h at 37 °C using an L-broth medium. After 24 h of incubation, the pellet was re-suspended in an equal amount of autoclaved distilled water, and the optical density of the bacterial culture was recorded at 600 nm and was adjusted to the same value. The bacterial cultures adjusted to the same O.D. were used for the inoculations of the seeds for plant–microbe interaction growth experiment. The seeds of T. aestivum and H. annus were soaked in bacterial cultures of S. lentus for 40 min and sown in pots containing 275 g of dried and sieved soil. Seven inoculated seeds were sown at uniform distances in each pot for three sets of treatments, along with the respective untreated control. The experiment was performed with 7 replicates for each bacterial treatment and without bacterial treatment as a control. After the germination of the seeds, a 10 mL solution of 150 µg/mL and 300 µg/mL of K2CrO4 was poured into the 2nd and 3rd set of each bacterial treatment, respectively, and into the control (without bacterial treatment).
2.5. Study of the Growth Parameters and Stress Tolerance Index
The seedlings were removed from the pots after 20 days, and various parameters, including the shoot length, root length, fresh weight, and dry weight, were studied. Moreover, the stress tolerance index is an important tool used to determine the threshold potential of plants’ tolerance against specific stress factors. The stress tolerance percentage was determined using the given formula [14]. The root length stress tolerance index (RLSTI) = (Root length of stress plant/Root length of control plant) × 100.
The shoot length stress tolerance index (SLSTI) = (Shoot length of stress plant/Shoot length of control plant) × 100.
Fresh biomass (FSTI) = (Root fresh weight of stress plant/Root fresh weight of control plant) × 100.
2.6. Protein Contents
The Lowery method for total protein estimation was used for the soluble protein estimation. The absorbance was taken at 750 nm using a spectrophotometer. The amount of soluble protein was calculated using a standard curve [15].
2.7. Proline Contents
The total proline content was measured using the modified method of Bates et al. (1973). Its absorbance was measured at 520 nm, and the amount of proline was determined in µg/g using a standard curve [16].
2.8. Chlorophyll Contents
The chlorophyll estimation was performed according to the modified method of Wellburn [17]. The absorbance of the solution was read at 663 and 645 nm using a spectrophotometer [18]. The total chlorophyll content was calculated using the following formula:
Chlorophyll ‘a’ (mg/g) = (12.72A663 − 2.59A645) V/(m × 1000)
Chlorophyll ‘b’ (mg/g) = (22.88A663 − 4.67A645) V/(m × 1000)
Total chlorophyll content = Chl ‘a’ + Chl ‘b’
2.9. Chromium Uptake
The chromium uptake in the aerial parts of the plants was measured using the method of [19] with Aqua Regia as a digesting mixture and 1,5-diphenylcarbazide as a color-developing reagent. The absorbance was measured at 540 nm using a spectrophotometer.
2.10. Peroxidase Contents
The peroxidase contents were determined by using the method of (Arnon, 1949). The absorbance was recorded at 420 nm to determine the amount of purpurogallin formed against the blank. One unit of enzyme activity denoted the quantity of the enzyme that inhibited 50% of the auto-oxidation rate of pyrogallol at 25 °C. The enzyme activity was expressed as the unit mg−1 of protein [20].
3. Results
The tolerance of the bacterial strain was evaluated through the relation of the minimum inhibitory concentration (MIC) to Cr. The results expressed that Cr stress greater than 300 µg/mL led to the inhibition of bacterial growth. Thus, this Cr concentration was considered as the MIC, and an efficient bacterial strain (E3) was selected for further studies. The bacterial E3 was molecularly characterized through 16S rDNA sequencing. After matching the partial sequences of 16S rDNA with sequences in GenBank, the BLAST results suggested that E3 expressed a 99% similarity with Staphylococcus lentus. These sequences were submitted to the GenBank database under the accession number MG988293.
3.1. Effects of Bacterial Inoculation on the Growth Attributes and Cr-Tolerance Index
The results regarding the effects of the bacterial inoculations on the growth parameters indicated that Cr stress significantly decreased the shoot length, root length, fresh weight, and dry weight as compared to the non-inoculated plants grown without stress treatments. However, the inoculations of plants with Cr-resistant S. lentus improved the growth of all these parts of the plant under Cr stress as compared to the non-inoculated Triticum aestivum (Figure 1) and Helianthus annus (Figure 2) plants grown in contaminated pots.
Figure 1.
Effects of bacterial inoculation (E3) with and without Cr stress (K2CrO4 (0, 150, and 300 µg/mL)) on the growth of Triticum aestivum. A—control, B—non-inoculated treatment with Cr stress (150 µg/mL), C—non-inoculated treatment with Cr stress (300 µg/mL), D—inoculated treatment with E3, E—E3 + Cr stress (150 µg/mL), F—E3 + Cr stress (300 µg/mL).
Figure 2.
Effects of bacterial inoculation (E3) with and without Cr stress (K2CrO4 (0, 150 and 300 µg/mL)) on the growth of Helianthus annuus. A—control, B—non-inoculated treatment with Cr stress (150 µg/mL), C—non-inoculated treatment with Cr stress (300 µg/mL), D—inoculated treatment with E3, E—E3 + Cr stress (150 µg/mL), F—E3 + Cr stress (300 µg/mL).
The maximum reduction in the shoot length in non-inoculated plants under a Cr stress of 150 and 300 µg/mL ranged between 40 and 52% in T. aestivum and between 45 and 58% in H. annus, respectively, as compared to the non-inoculated plants without stress treatment. However, the inoculations with the bacterial isolate E3 caused maximal enhancements of up to 50, 36, and 34% under 0, 150, and 300 µg/mL Cr stress in T. aestivum and up to 46, 55, and 34% in H. annus, respectively, compared to non-inoculated control treatment. The root length was reduced by up to 19 and 29% under a Cr stress of 150 and 300 µg/mL as compared to the non-inoculated plants without stress treatment in the case of T. aestivum, but in H. annus, reductions of up to 22 and 37%, respectively, were observed. Plants inoculated with isolate E3 expressed the best results by increasing their root lengths by up to 26, 21, and 21% under Cr concentrations of 0, 150, and 300 µg/mL in T. aestivum and up to 36, 31, and 28% in H. annus, respectively, as compared to the non-inoculated plants with the respective stress treatments. Cr concentrations of 150 and 300 µg/mL decreased the fresh weight of plants by up to 52 and 65% in T. aestivum and up to 32- and 43-fold in H. annus, respectively, compared to the non-inoculated controls without stress treatment. The inoculation of seeds with bacterial isolate E3 was the most effective and increased the fresh weight by up to 45, 53, and 34% under 0, 150, and 300 µg/mL of Cr stress in T. aestivum and up to 52, 76, and 49% in H. annus, respectively, compared to the non-inoculated controls with the respective stress treatments.
Similarly, Cr stresses of 150 and 300 µg/mL decreased the dry weight of the plants by up to 22 and 64% in T. aestivum and led to increases of up to 60 and 81% in H. annus. Inoculations with bacterial isolate E3 increased the dry weight of the plants by up to 72, 47, and 27% in T. aestivum under Cr stress of 0, 150, and 300 µg/mL, respectively, and inoculations further increased the dry weight of H. annus by up to 141, 24, and 6%, respectively, compared to the non-inoculated controls with the respective stress treatments. Table 1.
Table 1.
Effects of Staphylococcus lentus inoculations on the growth parameters of Triticum aestivum and Helianthus annus under Cr stress.
The shoot length stress tolerance index (SLSTI) of T. aestivum and H. annus was decreased by (59.8%, 55.4%) at the 150 µg/mL Cr level and (47.7%, 42.4%) at the 300 µg/mL Cr level, respectively. On the other hand, the bacterial inoculations increased the SLSTI by (136.4%, 154.7%) and (134.2%, 134%) in T. aestivum and H. annus, respectively, as compared to the non-inoculated treatments. Similarly, the bacterial inoculants displayed significant effects on the root length stress tolerance index (RLSTI) percentage and fresh biomass stress tolerance index (FSTI) percentage of both the T. aestivum and H. annus plants. At the 150 µg/mL and 300 µg/mL Cr doses, the RLSTI percentages of T. aestivum and H. annus were recorded as (82.3%, 78%) and (70.5%, 63.3%), respectively, while the bacterial inoculations enhanced the RLSTI to (121.5%, 131%) and (120.8%, 128.3%) at the 150 µg/mL and 300 µg/mL doses, as presented in Table 2. Similar trends were observed in the fresh biomass stress tolerance index (FSTI) percentage of both the plants. The FSTI percentage was observed as (47.7%, 67.7%) and (35.1%, 57.6%) at 150 µg/mL and 300 µg/mL Cr doses in T. aestivum and H. annus. In contrast, the bacterial inoculation enhanced the tolerance index percentage, reaching (154%, 177.5%) and (133.5%, 150%), as compared to respective stress treatments of both non-inoculated plants.
Table 2.
Effects of Staphylococcus lentus inoculations on the tolerance index (TI) of Triticum aestivum and Helianthus annus under Cr stress.
3.2. Effect of Bacterial Inoculations on the Protein Contents
Generally, an increase in the protein content was observed following bacterial treatment, but the inoculations with isolate E3 caused maximal enhancements in the protein content by up to 69 and 63% in T. aesivum and H. annus in comparison to the non-inoculated controls without Cr stress treatment. Cr stresses of 150 and 300 µg/mL increased the protein content by up to 41 and 75% in T. aestivum and 38 and 82% in H. annus, respectively, as compared to the non-inoculated controls without stress treatment. However, inoculations with bacterial isolate E3 further caused a maximal increase in the protein content by up to 34 and 108% under Cr stresses of 150 and 300 µg/mL in T. aestivum and up to 24 and 111% in H. annus, respectively, as compared to the non-inoculated controls with the respective stress treatments.
3.3. Effect of Bacterial Inoculation on the Proline Content
The bacterial inoculations expressed significant effects on the proline content by increases of up to 67 and 272% in T. aestivum and H. annus, respectively, after inoculations with bacterial isolate E3, as compared to the non-inoculated plants without stress control. Cr stresses of 150 and 300 µg/mL increased the proline content by up to 124 and 152% in T. aestivum and up to 255 and 283% in H. annus, respectively, as compared to the non-inoculated controls without stress treatment, but inoculations with bacterial isolate E3 decreased the proline content by up to 46 and 37% in T. aestivum and up to 41 and 29% in H. annus as compared to the non-inoculated plants with the respective stress control treatments.
3.4. Effect of Bacterial Inoculation on the Chlorophyll Contents
Bacterial inoculations exerted significant effects on the chlorophyll content of wheat and sunflower. Inoculations with bacterial isolate E3 enhanced the chlorophyll ‘a’, ‘b’, and ‘a+b’ by up to 365, 235, and 277%, respectively, in the absence of Cr stress as compared to the non-inoculated controls without stress treatment. Cr stresses of 150 and 300 µg/mL reduced the chlorophyll content of (‘a’, ‘b’ and ‘a+b’) by up to (30, 39, and 36%) and (34, 51, and 46%) in T. aestivum and up to (15, 46, and 34%) and (83, 74, and 79%), respectively, compared to the non-inoculated controls without stress treatment. However, inoculations with isolate E3 increased the chlorophyll content of (‘a’, ‘b’, and ‘a+b’) by up to (529, 241 and 343%) in T. aestivum and up to (419, 435, and 437%) in H. annus, respectively, under a Cr stress of 150 µg/mL, and inoculations with isolate E3 caused maximal enhancements in the chlorophyll content of (‘a’, ‘b’, and ‘a+b’) by up to (506, 230, and 341%) in T. aestivum and up to (866, 789, and 809%), respectively, under a Cr stress of 300 µg/mL compared to the non-inoculated controls with the respective stress treatments.
3.5. Effect of Bacterial Inoculation on Chromium Uptake in the Aerial Parts
Bacterial inoculations had significant effects on the Cr content in the aerial parts of the plants by decreasing translocation from the root to the upper parts. Inoculations of seeds with bacterial isolate E3 caused maximal decreases in the Cr content in the aerial parts of the plants by up to 81 and 85% under Cr stresses of 150 and 300 µg/mL in T. aestivum and up to 82 and 49% in H. annus, respectively, as compared to the non-inoculated controls with the respective stress treatments. A significant increase in the peroxidase content in wheat plants was observed after increasing the Cr stress, with increases of up to 18 and 73% under Cr concentrations of 150 and 300 µg/mL in T. aestivum and up 51 and 112% in H. annus, respectively, compared to the non-inoculated controls without stress treatment. However, inoculations of seeds with bacterial isolate E3 increased the peroxidase content by up to 187, 224, and 150% under Cr stresses of 0, 150, and 300 µg/mL in T. aestivum and up to 60, 60, and 40% in H. annus, respectively, compared to the non-inoculated controls with the respective stress treatments (Table 3).
Table 3.
Effects of Staphyllococcus lentus inoculations on the biochemical and physiological attributes of Triticum aestivum and Helianthus annus under Cr stress.
3.6. Effect of Chromium on Peroxidase Content
A significant decreasing trend in the peroxidase content was observed in the wheat plants growing under Cr stress with increased concentrations ranging from 150 to 300 µg/mL. Under Cr stresses of 150 and 300 µg/mL, the peroxidase content decreased by up to 62 and 97%, respectively, as compared to the plants grown without Cr stress. Microbial inoculations also exerted significant effects on the peroxidase content. The inoculation of Triticum aestivum seed with microbial isolate E3 increased the peroxidase content by up to 48% compared to the non-inoculated control without stress. Similarly, under a Cr stress of 150 µg/mL, inoculations with these E3 bacterial isolates increased the peroxidase content by up to 41% compared to the non-inoculated control with the respective Cr stress. Under a Cr stress of 300 µg/mL, inoculations of the seeds with the Cr-resistant microbial isolate E3 increased the peroxidase content by up to 39% as compared to non-inoculated control with the respective stress.
A significant increasing trend in the peroxidase content was observed in sunflower plants growing under Cr stress with increasing concentrations ranging from 150 to 300 µg/mL. Under Cr stresses of 150 and 300 µg/mL, the peroxidase content was increased by up to 131 and 138% as compared to plants grown without Cr stress. Microbial inoculations also exerted significant effects on the peroxidase content. The inoculation of sunflower seeds with microbial isolate E3 increased the peroxidase content by up to 101% compared to the non-inoculated control without stress. Similarly, under a Cr stress of 150 µg/mL, the inoculations of these bacterial isolates E3 also increased the peroxidase content by up to 5% compared to the non-inoculated control with the respective Cr stress. Under a Cr stress of 300 µg/mL, the inoculations of seeds with the Cr-resistant microbial isolate E3 increased the peroxidase content by up to 33% as compared to the non-inoculated control with the respective stress.
4. Discussion
The microbes present in heavy metal (HM)-contaminated soils and industrial effluents show varying tendencies to survive under conditions of HM contamination. In our study, bacterial strains isolated from industrial wastewater were screened for the selection of Cr-tolerant bacterial strains. The bacterial strain E3 showed the highest tolerance against Cr at concentrations of up to 300 µg/mL. These findings are supported by a re study where isolates of Pseudomonas, Micrococcus, and Aeromonas reduced 70% of the Cr (VI) under anoxic conditions, and nearly 38% of the bacterial isolates displayed tolerance against Cr (VI) at a concentration level of more than 400 µg/mL [21].
Chromium has toxic effects on plant growth and development. It has been observed that it can alter the germination process, including the growth of roots, stems, and leaves, because of which total dry matter production and yield are also affected [22]. Along with this, plant physiological processes such as photosynthesis, water relation, and mineral nutrition are adversely affected by Cr contaminants [23]. In the current study, Cr-resistant S. lentus (E3) was isolated, and its impacts in reducing the Cr toxicity and improving the plant growth were studied.
Triticum aestivum (wheat) and Helianthus annus (sunflower) seeds were treated with the selected Cr-tolerant bacterial strains and were grown in Cr-contaminated soil to evaluate their microbial-assisted plant growth promotion abilities under Cr stress. In our experiment, the Cr stress showed negative effects on all the growth parameters of the plants grown at all the Cr concentration levels. On the other hand, the seeds bacterized with S. lentus showed significant enhancements in all the plant growth parameters, including the shoot and root length, along with the fresh and dry weight and chlorophyll pigments. Overall, E3 showed a significant increase in the shoot length of T. aestivum and H. annus under 0, 150, and 300 µg/mL Cr stress in comparison to the respective non-inoculated stress treatments. In a recent study, Providencia sp. and Proteus mirabilis, two potential bacterial agents, were reported to increase the plant growth parameters and plant photosynthetic efficiency under drought and Cr stress conditions [24].
With increasing concentrations of Cr stress, the toxic effects of Cr on the water and nutrient uptake from the roots to the shoots and on the physiological mechanisms increase, which results in reductions in the shoot and root lengths of plants. Cr-resistant bacterial isolates can convert Cr (VI) into Cr (III) in the roots of the plants, and it becomes unavailable to the plants for absorption. Multiple possible mechanisms of action are involved in the development and growth patterns of T. aestivum in the context of the inoculation of Cr-tolerant rhizobacterial isolates [25]. In our study, the inoculation of T. aestivum and H. annus with Cr-resistant S. lentus (E3) showed significant increase in the plant growth parameters. Similar findings were reported in other studies [26,27]. Various bacterial attributes, including phosphate solubilization and phytohormones production, guarantee growth promotion in plants. Bacterial inoculants produce phytohormones, auxin, ethylene, gibberellins, and cytokinins, which can result in plant growth promotion. Moreover, auxins are very important hormones that regulate the development of plants, including the processes of organogenesis, differentiation, and cell expansion [28].
In our study, the non-inoculated plants grown under various Cr stress levels showed a decreased tolerance index, while the plants bacterized with E3 showed a significant increase in the tolerance index. A similar study reported that bacterial seed inoculation significantly increased the seed germination and metal tolerance capacity by minimizing the passage of HMs to the plants [29]. A more recent study showed that a multi-HM-resistant bacterial strain of Streptomyces sp. significantly improved the plant growth attributes in Maize and also increased the metal tolerance index under As3+ and Cr6+ stress [30].
Chromium toxicity decreases the chlorophyll contents, which has direct effect on the photosynthetic activity and, ultimately, results in less biomass production [31]. The chlorophyll content decreases because of the degradation and deterioration of antenna complex proteins. Heavy metals rigorously restrict plant growth and cause the death of plants by upsetting the movement of nutrients, which causes deterioration of chlorophyll, ultimately resulting in decreased photosynthetic activity [32]. In contrast, bacterial inoculation improves the pigment content of plants. Our study reported an increase in the protein contents of T. aestivum and H. annus under Cr stress conditions when inoculated with S. lentus. Similarly, the seeds’ inoculation with bacterial isolate E3 showed a maximum increase in the protein content compared to the non-inoculated plants. Heavy metal stress is responsible for the additional proteins formation and restriction of the synthesis of cellular proteins. The proteins produced under conditions of heavy metal toxicity may be involved in the synthesis of specialized proteins which stabilize the membranes [33].
In this study, the proline contents of T. aestivum and H. annus were affected by bacterial inoculation, as well as Cr stress. Previous research demonstrated that the plants could withstand water deficit stress conditions by osmoregulation, which is a function of proline. Proline can be included among the antioxidants (non-enzymatic) which are utilized by animals, plants, and microbes to cope with abiotic stress [33,34]. A recent study reported that seed inoculation with Providencia sp. and Proteus mirabilis significantly increased the plant growth parameters, pigments, proteins, phenolics, and relative water contents and decreased the lipid peroxidation, proline, and superoxide dismutase activity (SOD) under drought and Cr stress [24].
Our analysis of the Cr uptake showed that there is always a high level of Cr in the roots in comparison to the shoots of plants growing under a Cr stress environment. There might be a restricted uptake of Cr from the roots to the shoots [35]. Treatments of T. aestivum seeds with Cr-tolerant bacterial isolates significantly decreased the translocation of Cr (VI) from the soil to the roots and then, finally, to the shoots. When Cr stress is increased in plants, it results in the formation of reactive oxygen species, which cause oxidative damage and disturbance in the functions of the cell. There are some defense mechanisms, such as peroxidase and catalase enzymes, that provide protection against the damage caused by these reactive oxygen species [36]. In this study, the inoculations of bacterial isolates showed significant effects on the peroxidase content as compared to the non-inoculated treatments under Cr stress of 0, 150, and 300 µg/mL. The inoculations of T. aestivum and H. annus seeds with the Cr-resistant bacterial isolate E3 caused a maximal enhancement in the peroxidase content in wheat plants as compared to non-inoculated controls without Cr stress. A recent study supported the notion that the bacterial inoculation of Klebsiella sp. and Enterobacter sp. significantly enhanced the superoxide dismutase, catalase, peroxidase, total phenolic, and ascorbic acid levels in tomato plants grown under Cr stress conditions [37].
In the current study, the S. lentus strain showed a significant ability to reduce Cr (VI) to Cr (III) and to induce plant growth promotion under Cr stress conditions. Hence, this bacterium can act as a promising inoculant for bioremediating the toxic Cr species and could be tested against other HMs. The results of this study are important, particularly in regard to future research, with respect to the water crisis and climate change [38,39,40,41,42,43], which will increase the need to use groundwater and wastewater treatments.
5. Conclusions
The current study concludes that inoculations with heavy-metal-resistant Staphylococcus lentus enhanced the growth parameters of plants subjected to growth under Cr stressed conditions in terms of the root and shoot lengths and fresh and dry weights. A considerable increment in the levels of photosynthetic pigment was also observed in Triticum aestivum and Helianthus annus plants exposed to Cr stress. It was also observed that microbial inoculation also reduced the Cr uptake and accumulation in the aerial parts of the plants, because inoculated bacteria have the capacity to alleviate Cr toxicity by converting hexavalent chromium into the trivalent form, which becomes unavailable for absorption and reduces translocation to the shoots. Increments in the peroxidase and proline contents, which are involved in the defense mechanisms of plants growing under stress conditions, were also observed. The current study therefore envisions the influence of microbes as bioremediating agents that can be used to alleviate Cr toxicity in plants, providing better health, along with a better performance of all the biological activities, even in HM stress environments.
Author Contributions
Conceptualization, N.J. and A.A.; methodology, all authors; software, M.Y., M.U.Z.; formal analysis, M.Y., R.R. and R.I.; investigation, N.J.; writing—original draft preparation, N.J. and S.H.; writing—review and editing, all authors; supervision, A.A.; funding acquisition, S.H., R.I., R.R. and M.V. All authors have read and agreed to the published version of the manuscript.
Funding
This research received no external funding.
Institutional Review Board Statement
Not applicable.
Informed Consent Statement
Not applicable.
Data Availability Statement
The genomic sequence of the bacteria has been deposited in GenBank under the accession number MG988293.
Acknowledgments
The University of Punjab, Lahore, Pakistan, is acknowledged with gratitude for providing the facilities for this research work.
Conflicts of Interest
The authors declare no conflict of interest.
