Theoretical and Experimental Gas Volume Quantification of Micro- and Nanobubble Ultrasound Contrast Agents
Abstract
1. Introduction
2. Materials and Methods
2.1. Materials
2.2. Bubble Formulation
2.3. Size Characterization of Bubbles
2.4. Quantification of Bubble Perfluoropropane Gas (C3F8) Volume via GC/MS
2.5. Quantification of Bubble Population Acoustic Response
2.6. Theoretical Calculation of Bubble Gas Volume
3. Results and Discussion
4. Conclusions
Supplementary Materials
Author Contributions
Funding
Conflicts of Interest
References
