Fabrication of QFN-Packaged Miniaturized GaAs-Based Bandpass Filter with Intertwined Inductors and Dendritic Capacitor
Abstract
1. Introduction
2. Design and Fabrication
2.1. Design and Circuit Analysis
2.1.1. Model inside the Segment Box
2.1.2. Models outside the Segment Box
2.1.3. Embedded Capacitor
2.1.4. Substrate-Related Parasitic Effects
2.2. Fabrication
3. Results and Discussion
4. Conclusions
Author Contributions
Funding
Conflicts of Interest
References
