Design of an In-Operando Cell for X-Ray and Neutron Imaging of Oxygen-Depolarized Cathodes in Chlor-Alkali Electrolysis

1
Institute of Chemistry and Biochemistry, Freie Universität Berlin, Takustraße 3, 14195 Berlin, Germany
2
Institute of Applied Materials, Helmholtz-Zentrum Berlin für Materialien und Energie GmbH, Hahn-Meitner-Platz 1, 14109 Berlin, Germany
3
Institute of Chemical and Electrochemical Process Engineering, Clausthal University of Technology, Leibnizstraße 17, 38678 Clausthal-Zellerfeld, Germany
*
Author to whom correspondence should be addressed.
Materials 2019, 12(8), 1275; https://doi.org/10.3390/ma12081275
Received: 28 March 2019 / Revised: 10 April 2019 / Accepted: 16 April 2019 / Published: 18 April 2019
  |
PDF [4476 KB, uploaded 18 April 2019]
  |

Abstract

Oxygen-depolarized cathodes are a novel concept to be used in chlor-alkali electrolysis in order to generate significant energy savings. In these porous gas diffusion electrodes, hydrophilic and catalytically active microsized silver grains and a hydrophobic polytetrafluoroethylene cobweb structure are combined to obtain the optimum amount of three-phase boundaries between the highly alkaline electrolyte and the oxygen gas phase to achieve high current densities. However, the direct correlation between specific electrode structure and electrochemical performance is difficult. In this work, we report on the successful design and adaptation of an in-operando cell for X-ray (micro-computed tomography, synchrotron) and neutron imaging of an operating oxygen-depolarized cathode under realistic operation conditions, enabling the investigation of the electrolyte invasion into, and distribution inside, the porous electrode for the first time. View Full-Text
Keywords: in-operando and in-situ; X-ray and neutron imaging; cell design; chlor-alkali electrolysis; gas diffusion electrode; oxygen-depolarized cathode; oxygen reduction reaction in-operando and in-situ; X-ray and neutron imaging; cell design; chlor-alkali electrolysis; gas diffusion electrode; oxygen-depolarized cathode; oxygen reduction reaction
