Analytical Approach for Sharp Corner Reconstruction in the Kernel Free Boundary Integral Method during Magnetostatic Analysis for Inductor Design
Abstract
:1. Introduction
2. The C-core Problem
2.1. The Dimensions of C-core
2.2. PDEs and BCs for Magnetostatic Analysis
2.3. Inductance Calculation
3. KFBIM Framework for Single Boundary Magnetostatic Problems
4. Boundary Reconstruction and Implementation of the Kernel Free Boundary Integral Method
4.1. Boundary Reconstruction
4.2. Implementation of KFBIM
5. Results and Discussion of KFBIM
5.1. Numerical Example
5.2. Comparison between KFBIM and FEM on Magnetostatic Analysis
6. Conclusions
Author Contributions
Funding
Data Availability Statement
Conflicts of Interest
References
