A Novel Cascaded Multilevel Converter Topology Based on Three-Phase Cells—CHB-SDC †

1
Department of Control and Automation Engineering, Federal Institute of Espírito Santo (IFES), Rod. ES010, Serra 29173-087, Brazil
2
Department of Electronics, Alcalá University (UAH), Plaza San Diego S/N, 28801 Madrid, Spain
3
Department of Electrical Engineering, Federal University of Espírito Santo (UFES), Av. Fernando Ferrari, 514, Vitória 29075-910, Brazil
4
Department of Power Electronics, Siemens Gamesa, 28043 Madrid, Spain
*
Author to whom correspondence should be addressed.
This paper is an extended version of our paper published in 2020 IEEE 29th International Symposium on Industrial Electronics (ISIE), “A Novel Cascaded Multilevel Converter Topology Based on Three-Phase Cells with Model Predictive Control”, Delft, The Netherlands, 17–19 June 2020; pp. 1161–1166.
Energies 2020, 13(18), 4789; https://doi.org/10.3390/en13184789
Received: 6 August 2020 / Revised: 31 August 2020 / Accepted: 11 September 2020 / Published: 14 September 2020
(This article belongs to the Special Issue Dynamic Modelling and Control in Multilevel Converters)
This paper proposes a new cascaded multilevel converter topology based on three-phase H bridge cells with a common DC-link structure. The proposed multilevel converter topology main advantages, compared with literature renowned multilevel converters topologies, are discussed in the paper, such as modularity, construction, implementation cost, and DC voltage ripple mitigation. Despite presenting an elementary structure and easy implementation, the use of classic PWM switching strategies is not feasible for this topology, causing the appearance of several short-circuit states between its capacitors. Thus, a graph theory algorithm combined with a model predictive control is also proposed in this work to identify and avoid the new cascaded multilevel converter short-circuit switching states and, concomitantly, guaranteeing the converter output power quality. In order to validate the presented topology applicability, a low voltage synchronous static compensators (STATCOM) with an optimal switching vector model predictive control (OSV-MPC) is implemented in a hardware-in-the-loop platform. The real-time experimental results prove the proposed multilevel topology and the OSV-MPC control strategy effectiveness. View Full-Text
Keywords: multilevel converter; CHB; model predictive control; CHB-SDC; STATCOM; real-time; OPAL multilevel converter; CHB; model predictive control; CHB-SDC; STATCOM; real-time; OPAL
