Flexible Ecoflex®/Graphene Nanoplatelet Foams for Highly Sensitive Low-Pressure Sensors
Abstract
:1. Introduction
2. Materials and Fabrication Methods
2.1. Ecoflex® Foam Production
2.2. Ecoflex® Foam Infiltration Process
3. Characterization and Testing
3.1. Morphological Characterization
3.2. Mechanical Characterizations
3.3. Electrical Characterizations
3.4. Electromechanical Characterizations
4. Results and Discussion
5. Conclusions
Author Contributions
Funding
Conflicts of Interest
Abbreviations
GNPs | graphene nanoplatelets |
CNTs | carbon nanotubes |
GO | graphene oxide |
PDMS | polydimethylsiloxane |
PU | polyurethane |
3D | three-dimensional |
CVD | chemical vapor deposition |
rGO | reduced graphene oxide |
PI | polyimide |
HT | heat treatment |
MWNT | multiwall carbon nanotubes |
EF | Ecoflex® foam without thinner |
EFT | Ecoflex® foam with thinner |
EB | Ecoflex® bulk without thinner |
EBT | Ecoflex® bulk with thinner |
FE-SEM | field-emission scanning electron microscopy |
DC | direct current |
AC | alternating current |
Al | Aluminum |
References
