Open AccessArticle
Sensors 2019, 19(8), 1775; https://doi.org/10.3390/s19081775

New Approach to Analysis of Selected Measurement and Monitoring Systems Solutions in Ship Technology

Gdynia Maritime University, Department of Marine Electrical Power Engineering, ul. Morska 81-87, 81-225 Gdynia, Poland
*
Author to whom correspondence should be addressed.
Received: 8 March 2019 / Revised: 7 April 2019 / Accepted: 9 April 2019 / Published: 13 April 2019
  |
PDF [6528 KB, uploaded 13 April 2019]
  |

Abstract

This paper is dedicated to certain types of measurement in ship systems, analyzed based on selected case studies. In the introductory part, a simplified structure of a modern cargo ship as an object of measurement and control is presented. Next, the role of measurement in the ship’s operation process is described and commented on, with focus on specifics of local and remote control, both manual and automatic. The key part of the paper is dedicated to a short overview of selected examples of measuring and monitoring systems. The basic criteria for the aforementioned selection are the vital role of the considered systems for safe and effective ship operation as well as documented innovative contribution of Gdynia Maritime University (GMU) in development of the state-of-the-art in the analysed area of measurement. Based on these criteria, the monitoring of operational parameters of main engine and temperature measurement in the ships hazardous areas have been chosen. The aforementioned measurement and monitoring systems are analysed, taking into account both innovation of technical solutions together with their ship technology environment conditions and related legal requirements. Finally, some concluding remarks are formulated. View Full-Text
Keywords: ship systems; measurement; monitoring; main engine parameters; temperature measurement; ship environment; hazardous areas ship systems; measurement; monitoring; main engine parameters; temperature measurement; ship environment; hazardous areas
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
