Compact Acoustic Rainbow Trapping in a Bioinspired Spiral Array of Graded Locally Resonant Metamaterials

1
Temasek Laboratories, Nanyang Technological University, 50 Nanyang Drive, Singapore 637553, Singapore
2
School of Aeronautics, Northwestern Polytechnical University, Xi’an 710072, China
*
Author to whom correspondence should be addressed.
Sensors 2019, 19(4), 788; https://doi.org/10.3390/s19040788
Received: 21 December 2018 / Revised: 10 February 2019 / Accepted: 14 February 2019 / Published: 15 February 2019
(This article belongs to the Special Issue Sensors and Sensing Networks Based on Smart Materials)
  |
PDF [3357 KB, uploaded 15 February 2019]
  |

Abstract

Acoustic rainbow trappers, based on frequency selective structures with graded geometries and/or properties, can filter mechanical waves spectrally and spatially to reduce noise and interference in receivers. These structures are especially useful as passive, always-on sensors in applications such as structural health monitoring. For devices that face space and weight constraints, such as microelectromechanical systems (MEMS) transducers and artificial cochleae, the rainbow trapping structures must be compact as well. To address this requirement, we investigated the frequency selection properties of a space-saving design consisting of Helmholtz resonators arranged at sub-wavelength intervals along a cochlear-inspired spiral tube. The height of the Helmholtz resonators was varied gradually, which induced bandgap formation at different frequencies along the length of the spiral tube. Numerical simulations and experimental measurements of acoustic wave propagation through the structure showed that frequencies in the range of 1–10 kHz were transmitted to different extents along the spiral tube. These rainbow trapping results were achieved with a footprint that was up to 70 times smaller than the previous structures operating at similar bandwidths, and the channels are 2.5 times of the previous structures operating at similar bandwidths. View Full-Text
Keywords: acoustic rainbow trapping; artificial cochleae; Helmholtz resonator; spiral; locally resonant metamaterial acoustic rainbow trapping; artificial cochleae; Helmholtz resonator; spiral; locally resonant metamaterial
