Development of a Novel Piezoelectric Harvester Excited by Raindrops
Abstract
:1. Introduction
2. Theoretical Background
2.1. Impact Mechanics
2.2. Raindrop Harvester Vibrations
3. Development and Testing of the Prototype
- Filled spoon or dry spoon.
- Dry spoon with rigid masses corresponding to water mass.
- Open-circuit and on-load circuit with resistive load.
4. Experimental Results
4.1. Open-Circuit Voltage
4.2. On-Load Voltage
5. Conclusions
Author Contributions
Funding
Conflicts of Interest
Appendix A
Material | Elastic Modulus E [GPa] | Poisson’s Ratio ν | Density |
---|---|---|---|
Polyester | 3.65 | 0.48 | 1380 |
Copper | 110 | 0.34 | 1300 |
Steel AISI 304 | 193 | 0.29 | 8000 |
Polyimide | 4.1 | 0.34 | 1410 |
Property | Symbol | Value | Unit |
---|---|---|---|
Relative permittivity | 3800 | ||
Piezoelectric constant | [C/N] | ||
Piezoelectric constant | [C/N] | ||
Young’s modulus | [Pa] | ||
Young’s modulus | [Pa] | ||
Density |
Geometric Property | Symbol | Value [mm] |
---|---|---|
Cantilever Length | L | 42.9 |
Cantilever width | b | 23.3 |
Cantilever thickness | h | 0.41 |
PZT 5H thickness | hPZT | 0.15 |
Steel thickness | hSt | 0.15 |
Copper thickness | hCu | 0.03 |
Polyimide thickness | hPm | 0.03 |
Polyester thickness | hPs | 0.05 |
Lateral edge | Le | 1.25 |
Tip edge | Te | 1.80 |
