Sensors 2018, 18(2), 590; https://doi.org/10.3390/s18020590

Error Modelling for Multi-Sensor Measurements in Infrastructure-Free Indoor Navigation

Finnish Geospatial Research Institute (FGI), Geodeetinrinne 2, 02430 Masala, Finland
*
Author to whom correspondence should be addressed.
Received: 16 January 2018 / Revised: 9 February 2018 / Accepted: 9 February 2018 / Published: 14 February 2018
(This article belongs to the Section Physical Sensors)
Full-Text   |   PDF [6172 KB, uploaded 14 February 2018]   |

Abstract

The long-term objective of our research is to develop a method for infrastructure-free simultaneous localization and mapping (SLAM) and context recognition for tactical situational awareness. Localization will be realized by propagating motion measurements obtained using a monocular camera, a foot-mounted Inertial Measurement Unit (IMU), sonar, and a barometer. Due to the size and weight requirements set by tactical applications, Micro-Electro-Mechanical (MEMS) sensors will be used. However, MEMS sensors suffer from biases and drift errors that may substantially decrease the position accuracy. Therefore, sophisticated error modelling and implementation of integration algorithms are key for providing a viable result. Algorithms used for multi-sensor fusion have traditionally been different versions of Kalman filters. However, Kalman filters are based on the assumptions that the state propagation and measurement models are linear with additive Gaussian noise. Neither of the assumptions is correct for tactical applications, especially for dismounted soldiers, or rescue personnel. Therefore, error modelling and implementation of advanced fusion algorithms are essential for providing a viable result. Our approach is to use particle filtering (PF), which is a sophisticated option for integrating measurements emerging from pedestrian motion having non-Gaussian error characteristics. This paper discusses the statistical modelling of the measurement errors from inertial sensors and vision based heading and translation measurements to include the correct error probability density functions (pdf) in the particle filter implementation. Then, model fitting is used to verify the pdfs of the measurement errors. Based on the deduced error models of the measurements, particle filtering method is developed to fuse all this information, where the weights of each particle are computed based on the specific models derived. The performance of the developed method is tested via two experiments, one at a university’s premises and another in realistic tactical conditions. The results show significant improvement on the horizontal localization when the measurement errors are carefully modelled and their inclusion into the particle filtering implementation correctly realized. View Full-Text
Keywords: error modelling; sensor fusion; indoor positioning; particle filtering error modelling; sensor fusion; indoor positioning; particle filtering
