A Novel Method of Frequency Band Selection for Squared Envelope Analysis for Fault Diagnosing of Rolling Element Bearings in a Locomotive Powertrain
Abstract
:1. Introduction
2. Review of the SK Method
3. The Algorithm of the New Method
4. Numerical Experiments
4.1. High Repetition Rate of Impacts with High SNR
4.2. High Repetition Rate of Impacts with a Low SNR
4.3. Interference of a Few Impulses in the SES
5. Actual Vibration Data Tests and Recommendation
5.1. Experiment of Outer Ring Defect with a Constant Speed
5.2. Experiment of Outer Ring Defect with a Slight Acceleration of the Speed
5.3. Experiment of Roller Defect with a Constant Speed
6. Conclusions
Author Contributions
Funding
Conflicts of Interest
References
