Analysis of Detection Enhancement Using Microcantilevers with Long-Slit-Based Sensors
Abstract
:1. Introduction
2. Theoretical Analysis
2.1. The Typical Rectangular Microcantilever
2.1.1. Deflections of the Typical Rectangular Microcantilever
2.1.1.1. Concentrated Force Loading
2.1.1.2. Prescribed Differential Surface Stress
2.1.2. The Disturbance in the Deflections of the Typical Rectangular Microcantilever
2.2. The Rectangular Microcatilever with a Long-slit
2.2.1. Deflections of the Rectangular Microcatilever with Long-slit
2.2.1.1. Concentrated Force Loadings
2.2.1.2. Prescribed Differential Surface Stress
2.2.2. The Disturbance in the Deflections of the Rectangular Microcantilever with Long-slit
3. Results and Discussion
3.1. Validation of the Results
3.2. Discussion of the Results
3.2.1. Discussion of the Results of First Detection Enhancement Indicator
3.2.2. Discussion of the Results of Clearness Indicator of Typical Rectangular Microcantilever
3.2.3. Discussion of the Results of Second Detection Enhancement Indicator
4. Conclusions
