The First Deep-Sea Stylasterid (Hydrozoa, Stylasteridae) of the Red Sea

Abstract

The Stylasteridae, commonly known as lace corals, is a family of colonial calcifying hydrozoans mostly inhabiting deep waters. Stylasterids show a cosmopolitan distribution but, in some areas, they are characterized by low species diversity, such as in the Red Sea, where only a shallow-water species has been reported so far. With this work, we provide the first evidence of a deep-sea stylasterid inhabiting the NEOM region in the northern Saudi Arabian Red Sea, at depths ranging between 166 and 492 m. Morphological examinations revealed that this species was previously unknown and belonging to the genus Stylaster. We, therefore, describe Stylaster tritoni sp. nov., representing the first record of the genus in the Red Sea. Lastly, the phylogenetic position of the species within the Stylasteridae was evaluated, revealing a close relationship with shallow-water Indo-Pacific and Western Atlantic Stylaster species and confirming the polyphyletic nature of the genus Stylaster.

1. Introduction

Despite once being considered a homogeneous and abiotic environment, in the last decades, the deep sea has revealed an extraordinary diversity of life, habitats, and ecosystems [1,2]. The fast-paced technological progress in deep-sea research is constantly widening our knowledge on the diversity, ecology, and evolution of benthic deep-sea life [3]. Key advances, such as the development of manned and unmanned underwater vehicles, are allowing scientists to directly observe and sample deep-sea organisms in their natural environment, facilitating, for instance, biodiversity, distributional, and behavioral studies, as well as new species discovery (e.g., [4,5,6,7]).

Despite the flourishing deep-sea research, some areas remain poorly explored, such as the Red Sea basin. The Red Sea is a young and elongated body of water that stretches over 15° of latitude [8]. As a consequence, it is characterized by diverse environmental conditions along its latitudinal gradient [9]. Overall, the Red Sea is characterized by environmental conditions which have been defined extreme, especially due to the high water temperature and salinity, and the strong seasonal fluctuations of several environmental variables. In its more surficial portion, the Red Sea seawater increases in temperature from north to south, while salinity follows an opposite trend, due to a higher evaporation rate, lack of freshwater input, and exchange with adjacent basins in the north [10]. In its deeper layers, the Red Sea water remains unusually warm and very saline compared to any other ocean, with water temperature never dropping below 21 °C and salinity around 40.5 PSU, thus providing unique environmental conditions and physiological challenges for the organisms which have adapted to live there [11,12].

In recent years, the shallow-water reef communities in the Red Sea have been increasingly investigated, even though many relevant topics may still be underrepresented compared to other better-studied coral reef systems [13,14,15,16]. The current knowledge on the shallow Red Sea marine life reveals this basin as a hotspot for biodiversity and endemism [17,18], mostly due to the peculiar geological history of this sea and the presence of multiple potential isolating barriers [10,19]. Regarding the deep-sea benthos, only a few studies have been conducted in the Red Sea compared to other areas (see Joydas et al. [20] and references therein), and information on some taxa, such as hydrozoans, is scant in literature.

Overall, Red Sea hydrozoans have been scarcely studied in the past, summing up to about 160 species [21,22], even though new species, new records, and possibly endemic cryptic genetic lineages have been recently identified thanks to an integrative taxonomic approach [23,24,25,26]. Indeed, this approach, which relies on combining multiple lines of evidence (such as morphology, genetics, and ecology) to delineate taxonomic units [27], is greatly improving our knowledge of the diversity and biogeography of different marine organisms globally and in the Red Sea (e.g., [28,29,30]). Hydrozoans play important ecological roles in shallow Red Sea waters, especially the calcifying hermatypic species [31,32], such as the three fire coral species of the area [33], which can become dominant in specific reef zones [31]. Another calcifying shallow-water species reported from the Red Sea is Distichopora violacea (Pallas, 1766), which is also the only member of the family Stylasteridae (Gray, 1847) recorded from the area so far [34].

Stylasterids, commonly known as lace corals, are colonial hydrozoans able to produce a calcium carbonate skeleton, similar to fire corals and scleractinians. They are generally smaller in size compared to Scleractinia and do not contribute much to shallow coral reef formation [35]. Only a few species are known to inhabit shallow waters, and Lindner et al. [36] demonstrated that this group originated and largely diversified in the deep sea and only later invaded shallower environments, at least four times. Most species (about 90%) inhabit waters deeper than 50 m [35,37] where, in some cases, they reach large size and densities, representing dominant and habitat-forming species in deep-water coral mounds [1]. A recent example is provided by Hoarau et al. [38], who described mesophotic (75–100 m deep) aggregations of the stylasterid Stylaster flabelliformis (Lamarck, 1816) and the scleractinians Leptoseris spp. in the Western Indian Ocean, providing a habitat for a diverse associated community of vertebrates and invertebrates.

Stylasterids are distributed almost ubiquitously [35], with a predominantly insular distribution [39] and with the tropical southwest Pacific region being the richest in terms of species [40]. However, several areas appear not to be suitable environments for lace corals, including large islands and continental masses [39]. Accordingly, only the widely distributed shallow-water D. violacea has been reported from the Red Sea [34], whereas no deep-sea stylasterid species had been found so far.

In this work, we present the first record of a deep-sea stylasterid and of the genus Stylaster (Gray, 1831) in the Red Sea, describing a new species and assessing its phylogenetic position within the family Stylasteridae.

2. Materials and Methods

From September to November 2020, shallow, mesophotic, and deep-sea explorations were carried out in the NEOM (the largest of the Saudi Arabia development giga-projects) area, on the Saudi Arabian coast of the Gulf of Aqaba and northern Red Sea, in the context of the OceanX-NEOM ‘Deep Blue’ Expedition aboard the M/V OceanXplorer. Sampling took place from two Triton 3300/3 submersibles (Nadir and Neptune) equipped with a Sonardyne Ranger Pro 2 system, light and camera systems including a Wide-Angle Red DSMC2 Helium 8K Canon CN-E15.5–47 mm lens and a macro Red DSMC2 Helium 8K Nikon ED 70–180 mm F4.5-5.6D. One submersible (Neptune) was equipped with a CTD probe, two parallel-aligned scaling lasers providing 100 mm scale, and a Schilling T4 hydraulic manipulator that was used for sampling activities. Video transects from Neptune were conducted using an ArcticRays Eagle Ray 4K camera recorded to a 4K Atmos Shogun monitor.

Stylasterid colonies were collected at thee sampling stations in the northern Saudi Arabian Red Sea, namely NTN0029, NTN0048, and NTN0049 (Figure 1), in a bathymetric range spanning 166 to 492 m deep. After collection, colonies were air-dried at room temperature, and, for two colonies, small fragments were fixed in 99% ethanol. The specimens were firstly observed and photographed using a Leica M205 A stereomicroscope equipped with a Leica DMC 5004 camera in the Red Sea Research Center at King Abdullah University of Science and Technology (KAUST, Thuwal, Saudi Arabia) to assess their general macro-morphology. Subsequently, skeletal fragments were analyzed using a Thermo Fisher Scientific Quattro S Environmental scanning electron microscope (SEM) at KAUST Imaging Core Lab to describe the skeletal structures and using a Zeiss Axioskop 40 compound microscope equipped with a Canon PowerShot G7 X Mark II camera to study the cnidome composition. Specifically, for SEM fine-scale characterization of the skeletal structures, tissues were removed from dry specimens by immersion in a 10% sodium hypochlorite solution for 6–12 h. Skeletons were then rinsed, air-dried, and sputter-coated with Au–Pd. For cnidome characterization, the skeleton of ethanol-fixed fragments was dissolved by immersion in a 10% hydrochloric acid solution for 2–4 h, and the remaining tissues were washed with MilliQ water and directly observed under the compound microscope. All measurements were taken using the ImageJ 1.52p software [41]. The video footage obtained during the sampling campaign was also explored with the open-source software MPC-HC (Media Player Classic Home Cinema) available at https://github.com/mpc-hc/mpc-hc (accessed on 1 October 2021) to find other possible sites where stylasterids were present.

Two ethanol-fixed specimens were used for genomic DNA extraction with the DNeasy Blood and Tissue Kit (Qiagen: Hilden, Germany). Three molecular markers were amplified using polymerase chain reactions (PCRs) following Lindner et al. [36]. Specifically, a ~600 bp portion of the mitochondrial 16S ribosomal DNA (16S rRNA) was amplified using the primers SHB–SHA and protocols in Cunningham and Buss [42], a ~1600 bp portion of the nuclear 18S ribosomal DNA (18S rRNA) was amplified using the primers 18SA–18SB and protocols in Medlin et al. [43], and a ~350 bp portion of the nuclear calmodulin gene (CaM) was amplified using the primers CAMF1–CAMR1 and protocols in Lindner et al. [36]. All PCR products were checked using a QIAxcel Capillary Electrophoresis System (Qiagen: Hilden, Germany), purified with Illustra ExoStar (GE Healthcare: Amersham, UK), and sequenced in forward and reverse directions using an ABI 3730xl DNA Analyzer (Applied Biosystems: Carlsbad, CA, USA) at KAUST Bioscience Core Lab. Geneious 7.1.9 (Biomatters Ltd.: Auckland, New Zealand) was used to visually check and assemble the obtained chromatograms, and the consensus sequences were deposited in GenBank with the accession numbers OM416034, OM416035, OM416037, and OM416038.

Sequences of each DNA region were aligned using MAFFT 7.110 [44] with the E-INS-i option, after adding other available stylasterid sequences and outgroups listed in Lindner et al. [36,45] and after updating species names following Cairns [40] and Cairns and Lindner [46]. The 16S and 18S rRNA datasets were run through Gblocks [47,48] using the default ‘less stringent’ settings to remove ambiguously aligned regions (~9% and ~2% of the alignments, respectively), and all datasets were concatenated using Mesquite 3.2 [49], resulting in a final alignment of 2583 bp. Partition schemes and models for the concatenated dataset were determined with PartitionFinder 1.1.1 [50] using the Akaike information criterion, resulting in partitioning by DNA region and applying the GTR + I + G model to all partitions. Phylogenetic inference was performed using maximum likelihood (ML), maximum parsimony (MP), and Bayesian inference (BI) with RAxML 8.2.12 [51], PAUP 4.0b10 [52], and MrBayes 3.2.6 [53], respectively, as described in Maggioni et al. [54].

The holotype was deposited at the Museo Civico di Storia Naturale, Cnidaria Collection, Milano, Italy, whereas the paratypes at the KAUST. The acronyms for the voucher and deposited material are MSNM-Coe-# (Museo Civico di Storia Naturale, Cnidaria Collection, Milano, Italy) and NTN-# (Neptune).

3. Results

3.1. Sampling and Phylogenetic Analyses

The sampled colonies belonged to the genus Stylaster, representing the first record of a deep-sea stylasterid, as well as the first record of the genus Stylaster, in the Red Sea. According to morphological and molecular analyses (Figure 2), the collected colonies resulted to be conspecific and to belong to Stylaster tritoni sp. nov. (see Section 3.2), a previously unknown species.

PCRs and sequencing were successful for 16S and 18S rRNA, but not for the CaM gene, and the phylogenetic analyses confirmed that S. tritoni sp. nov. was genetically different from any stylasterid species sequenced so far. Specifically, the obtained phylogenetic hypotheses (Figure 2) were comparable to those reported by previous studies [36,45]. Similar to previous phylogenetic reconstructions, deeper nodes within the Stylasteridae family were generally not well supported, and the genus Stylaster as currently defined is polyphyletic. Stylaster tritoni sp. nov. sequences formed a fully supported monophyletic group, sister to a clade composed of shallow-water Stylaster species inhabiting tropical Indo-Pacific waters, apart from Stylaster roseus (Pallas, 1776) from the tropical Western Atlantic [36]. This latter clade, together with S. tritoni sp. nov., formed a clade sister to two deep-sea species from the West Pacific, Stylaster lindneri Cairns, 2015 and Calyptopora reticulata B (identified as Stylaster cf. horologium and Calyptopora sinuosa Cairns, 1991, respectively, in Lindner et al. [36]). All other Stylaster species included in the analyses clustered in two divergent clades, together with species belonging to several other stylasterid genera.

3.2. Taxonomic Account

• Class: Hydrozoa (Owen, 1843)
• Order: Anthoathecata (Cornelius, 1992)
• Family: Stylasteridae (Gray, 1847)
• Genus: Stylaster (Gray, 1831)
• Stylaster tritoni sp. nov. Maggioni, Cairns, Pica & Benzoni
• urn:lsid:zoobank.org:act:194FD2C1-8FEC-4611-AA4E-07B5A9C20B31.

Type material: NTN0048-7 (Holotype): one dry colony and fragments from the same colony in 99% ethanol, station NTN0048, 27.71701° N 35.28974° E, 373 m, 1 November 2020, GenBank accession numbers: OM416035 (16S rRNA), OM416038 (18S rRNA). Voucher number: MSNM-Coe-356.

Additional examined material: NTN0029-5: one dry colony and fragments from the same colony in 99% ethanol, station NTN0029, 27.60023° N 35.33427° E, 492 m, 10 October 2020, GenBank accession numbers: OM416034 (16S rRNA), OM416037 (18S rRNA); NTN0029-19: one dry colony, station NTN0029, 27.58968° N 35.33203° E, 166 m, 10 October 2020; NTN0049-1: one dry colony, station NTN0049, 27.63267° N 35.31033° E, 166 m, 1 November 2020.

Description: Corallum uniplanar or slightly multiplanar in larger colonies, thin, delicate, and highly branched (Figure 3 and Figure 4A–C). Holotype ~17 cm in height and ~28 cm in width, with a basal branch diameter of ~1 cm Figure 3A,B and Figure 4A). Other investigated colonies smaller (Figure 4B–D). Branching generally dichotomous, rarely anastomosing in certain points. Main branches ~3 mm in diameter and other branches thinner, ~1 mm in diameter, terminating in a terminal cyclosystem (Figure 4E). Commensal organisms not observed. Coenosteal texture linear-imbricate (Figure 5A), with strips 47–140 µm wide and slightly ridged, especially in smaller branches (Figure 4G), and slits 43–97 µm wide. Texture becomes more irregular and granular in some points and in larger branches (Figure 5C). Platelets with normal polarity, 52–136 µm µm wide and 11–27 µm high (Figure 5A,B), each one extending entirely across strips and with edges irregular in shape. Coenosteal pores round to slightly elliptic in shape, 14–36 µm in diameter, with (Figure 5C) or without (Figure 5A) small teeth, 5–18 µm in length, projecting inward toward center of pore; teeth observed when texture is more irregular and granular. Coenosteal pores in larger branches more scattered than longitudinally organized in slits (Figure 5E). Conical nematopores present on some of the main and smaller branches (Figure 5D–F), up to 50 µm in height, with apical pore measuring 67–94 µm in diameter. Living colonies uniformly white (Figure 4A–D).

Cyclosystems sympodially arranged, circular to slightly elliptical in outline, with no diastemas, ranging from 0.5–1.0 mm in diameter, with terminal ones being slightly smaller (0.5–0.8 mm in diameter) (Figure 4E,F and Figure 5G–I). Average number of dactylopores per cyclosystem: 12.0 (n = 50, range = 7–16, standard deviation = ±1.6, mode = 12).

Gastropores circular, 0.19–0.34 mm in diameter (Figure 5G–J), leading to cylindrical gastropore tubes (Figure 5K). Gastrostyles generally not visible from surface, cylindrical, with slightly pointed end (Figure 5J,L–N), 0.27–0.37 mm long and 54–94 µm in diameter. Gastrostyles not ridged, with spines often multi-tipped (Figure 5O,P), 8–32 µm long. Annular ring palisade at level of gastrostyle tip, composed of 3–4 rings of cylindrical to clavate elements (Figure 5J,K,M,N and Figure 6A,B), 14–46 µm in length and 8–19 µm in diameter. Dactylopores round to elliptical, dactylotomes measuring 44–107 µm in width (Figure 5G–J), triangular pseudosepta 43–177 µm wide. Older cyclosystems with absent or reduced dactylotomes, generally reducing dactylopore diameter (Figure 5I). Dactylostyles generally absent. Occasionally, in some dactylopores of terminal cyclosystems, small protruding elements 6–14 µm high occur in uppermost part of dactylopore tubes (Figure 5J), resembling dactylostyle elements.

External female ampullae mostly observed on smaller branches (Figure 4F and Figure 6C–F), 0.44–0.68 mm in diameter, with a lateral efferent pore (Figure 6D–F), 77–132 µm in diameter. Male ampullae not observed.

Cnidome composed of three types of nematocysts concentrated in dactylozooids and gastrozooids, but also scattered in the coenosarc: desmonemes (3–4 × 2–3 µm) (Figure 7A), large microbasic euryteles (9–10 × 4–6 µm; shaft: 8) (Figure 7A,B), small microbasic euryteles (5–8 × 2–3 µm; shaft: 5 µm) (Figure 7A,C).

Habitat: Stylaster tritoni sp. nov. was commonly found in aggregations close to other cnidarians, including scleractinians and octocorals, and growing on dendrophylliid and caryophylliid rubble (Figure 3 and Figure 4C). Moreover, it was observed both growing directed upward and downward (Figure 3).

Distribution: Known only from the type locality (northern Saudi Arabian Red Sea). Bathymetric range: 166–492 m. Samples observed in situ but not collected were found at the following stations and depths: NTN0047, 27.56355° N 35.32176° E, 242–271 m, 31 October 2020; NTN0049, 27.63267° N 35.31033° E, 400–414 m, 1 November 2020; NTN0055, 27.95855° N 34.87867° E, 272–276 m, 6 November 2020 (Figure 1).

Etymology: The specific name derives from Triton, a god of the sea in Greek mythology, son of Poseidon and Amphitrite, the god and goddess of the sea, respectively. Triton is also the name of the submersibles used to collect and photograph the species.

Remarks: Stylaster tritoni sp. nov. belongs to the ‘Stylaster Group C’ sensu Cairns [55], by having cyclosystems exclusively arranged in a sympodial fashion on branch edges and branches ending in a terminal cyclosystem. Stylaster tritoni sp. nov. is the only species in the genus and only the second stylasterid species reported from the Red Sea after Distichopora violacea [34], supporting its description as a new species, given the overall limited distributional ranges of stylasterids [39]. Three other Stylaster C species are known to inhabit the Indian Ocean, namely, Stylaster lonchitis Broch, 1947, Stylaster ramosus Broch, 1947, and Stylaster flabelliformis (Lamarck, 1816). The first two species were reported from the Pemba Channel (Tanzania) [56], whereas the latter was reported from Mascarene Islands [57]. Stylaster lonchitis differs from S. tritoni sp. nov. by having diastemas, distinct dactylostyles, and highly corrugated ampullae; conversely, S. ramosus is more similar to the Red Sea species but can be mostly distinguished by a lower number of dactylopores per cyclosystem (average 8.94). Lastly, S. flabelliformis resembles S. tritoni sp. nov., showing nevertheless a more uniplanar corallum, with platelets of the texture not long as the strip, sometimes spines on ampullae and coenosteum, dactylopores in older cyclosystems elliptical (circular in S. tritoni sp. nov.), and no nematopores. Moreover, S. flabelliformis has rudimentary linear dactylostyles, whereas S. tritoni sp. nov. does not show this feature.

4. Discussion

Stylaster is the most species-rich genus in the family Stylasteridae, and among the richest in the whole phylum Cnidaria. With the description of Stylaster tritoni sp. nov., the number of the extant accepted species of the genus rises to 91 [58]. Altogether, stylasterids account for about 10% of the known hydrozoan species [58], and their high diversity may be explained by the fact that they are the only calcifying hydrozoans in the deep sea, also resulting in great adaptive advantages in terms of protection of polyps, ability to reach a large size, and reduced competition [40]. This idea is also supported by the fact that the highest stylasterid diversity is found in deep waters [35].

With this work, we extend the known geographic distribution of the genus Stylaster, since no previous records in the Red Sea were available in the literature. A few other Stylaster species are known from the Western Indian Ocean, such as the ‘Group A’ Stylaster omanensis Cairns & Samimi-Namin, 2015, or the ‘Group C’ Stylaster flabelliformis, Stylaster lonchitis, and Stylaster ramosus [56,57,59], whereas most of the species inhabit the Atlantic and Pacific Oceans. Additionally, another unidentified Stylaster species was collected in the Gulf of Aden during the Meteor Expedition in 1987 (st. 230, 228–235 m), but no detailed morphological information is currently available to precisely determine the species (H. Zibrowius and D. Pica, personal observation). Stylasterid species generally have narrow distributional ranges [39,60], possibly explained by the ecological preferences [39] and the poor dispersal abilities of the larvae [61], resulting in high levels of endemism. Miller et al. [62] demonstrated, for instance, that neighboring populations of Errina novaezelandiae Hickson, 1912 in New Zealand fjords were characterized by limited gene flow and low levels of heterozygosity, typical of organisms with limited dispersal abilities. In this context, Stylaster tritoni sp. nov. may be a Red Sea or even northern Red Sea endemic. Indeed, this basin is characterized by multiple dispersal barriers, including its narrow entrance and heterogeneous salinity, temperature, and primary productivity. These conditions isolate it from adjacent waters and create longitudinal environmental gradients [17,19,63], resulting in genetic breaks among populations (e.g., [64,65,66]) and high levels of endemism [17], as demonstrated by the constant discovery of species only found in the Red Sea (e.g., [67,68,69]). These features, together with the abovementioned reproductive traits of stylasterid species, may indicate a restricted distribution of S. tritoni, but further deep-sea explorations of the Red Sea and neighboring waters are needed to address whether S. tritoni is a Red Sea endemic or not.

The stylasterid genetic diversification patterns were examined by Lindner et al. [36] using three molecular markers, who obtained phylogenetic reconstructions highlighting the strong need of an integrative systematic revision of the family [70]. Indeed, many genera resulted polyphyletic, with low statistical support at nodes, as also observed in our phylogenetic hypotheses. Therefore, it is fundamental to increase the sampling effort in terms of number of samples and geographic coverage, as well as the amount of genetic data. In turn, a detailed genetic characterization of this taxon will enhance our knowledge about the diversity, evolution, and biogeography of stylasterids, contributing toward the development of effective conservation measures for such a peculiar and ecologically important group of hydrozoans.
