Int. J. Mol. Sci. 2018, 19(9), 2533; https://doi.org/10.3390/ijms19092533

Transgenic Silkworm-Based Silk Gland Bioreactor for Large Scale Production of Bioactive Human Platelet-Derived Growth Factor (PDGF-BB) in Silk Cocoons

1,2,3
,
1,2,3
,
1,2,3
,
1,2,3
,
1,2,3
,
1,2,3
,
1,2,3
,
1,2,3
,
4
,
4
and
1,2,3,*
1
State Key Laboratory of Silkworm Genome Biology, Southwest University, Chongqing 400715, China
2
Chongqing Engineering and Technology Research Center for Novel Silk Materials, Southwest University, Chongqing 400715, China
3
Chongqing Key Laboratory of Mulberry Silkworm, Southwest University, Chongqing 400715, China
4
Institute for Clean Energy & Advanced Materials, Faculty of Materials & Energy, Southwest University, Chongqing 400715, China
*
Author to whom correspondence should be addressed.
Received: 27 July 2018 / Accepted: 20 August 2018 / Published: 27 August 2018
(This article belongs to the Special Issue Cytokines: Biological Effects and Therapeutic Uses)
Full-Text   |   PDF [4358 KB, uploaded 27 August 2018]   |

Abstract

Human platelet derived growth factor (PDGF) is a major therapeutic protein with great demand in the clinical setting; however, its rate of supply is far from meeting needs. Here, we provide an effective strategy to produce PDGF-BB in large quantities using a transgenic silkworm. The codon-optimized PDGF-B gene regulated by the highly efficient sericin-1 expression system was integrated into the genome of a silkworm. The high transcriptional expression of the PDGF-BB gene in the transgenic silkworm competitively inhibited the transcription expression of the endogenous sericin-1 gene which caused a significant 37.5% decline. The PDGF-BB synthesized in the middle silk gland (MSG) of transgenic silkworms could form a homodimer through intermolecular disulfide bonds, which is then secreted into sericin lumen and finally, distributed in the sericin layer of the cocoon. In this study, a protein quantity of approximately 0.33 mg/g was found in the cocoon. Following a purification process, approximately 150.7 μg of recombinant PDGF-BB with a purity of 82% was purified from 1 g of cocoons. Furthermore, the bioactivity assays showed that the purified recombinant PDGF-BB was able to promote the growth, proliferation and migration of NIH/3T3 cells significantly. These results suggest that the silk gland bioreactor can produce active recombinant PDGF-BB as an efficient mitogen and wound healing agent. View Full-Text
Keywords: silkworm; silk gland; recombinant expression; human platelet-derived growth factor silkworm; silk gland; recombinant expression; human platelet-derived growth factor
Figures

Graphical abstract

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
SciFeed

Share & Cite This Article

MDPI and ACS Style

Chen, W.; Wang, F.; Tian, C.; Wang, Y.; Xu, S.; Wang, R.; Hou, K.; Zhao, P.; Yu, L.; Lu, Z.; Xia, Q. Transgenic Silkworm-Based Silk Gland Bioreactor for Large Scale Production of Bioactive Human Platelet-Derived Growth Factor (PDGF-BB) in Silk Cocoons. Int. J. Mol. Sci. 2018, 19, 2533.
