17 pages, 6545 KiB
Article
Metamaterial Inspired Varactor-Tuned Antenna with Frequency Reconfigurability and Pattern Diversity
by Jiahao Zhang, Buyun Wang, Sen Yan, Wei Li and Guy A. E. Vandenbosch
Sensors 2024, 24(6), 1956; https://doi.org/10.3390/s24061956 - 19 Mar 2024
Cited by 1 | Viewed by 2946
Abstract
A metamaterial-inspired varactor-tuned antenna with frequency reconfigurability and pattern diversity is designed. Two different versions of a reconfigurable structure are integrated into a single antenna to excite two different orthogonal patterns, which realizes pattern diversity for MIMO applications. The outer annular Composite Right-/Left-Handed [...] Read more.
A metamaterial-inspired varactor-tuned antenna with frequency reconfigurability and pattern diversity is designed. Two different versions of a reconfigurable structure are integrated into a single antenna to excite two different orthogonal patterns, which realizes pattern diversity for MIMO applications. The outer annular Composite Right-/Left-Handed Transmission Line (CRLH-TL) works at the 1 mode and provides a broadside pattern, and the inner circular radiator loaded with split ring resonators (SRR) operates at the 0 mode and radiates an omnidirectional pattern, which realizes pattern diversity. By using surface-mounted varactors, the operating frequencies for the two radiation patterns can be tuned over a wide frequency range, from 1.7 GHz to 2.2 GHz, covering the 1.71–2.17 GHz LTE band, and a low mutual coupling between the two radiators is achieved. The antenna has also been prototyped. The measured results are in good agreement with the simulation results, verifying the proposed concept. The dual-mode MIMO system equipped with the proposed antenna elements is discussed within the context of a 3-D channel model, and it shows a superior array compactness and spectral efficiency (SE) performance compared to scenarios with single-mode elements. Full article
(This article belongs to the Section Communications)
Show Figures

Figure 1

15 pages, 556 KiB
Article
A New Varactor-Tuned 5.8 GHz Dielectric Resonator Band-Stop Filter for ITS and C-V2X Coexistence with Vehicular DSRC
by Giovanni Collodi, Monica Righini and Alessandro Cidronali
Electronics 2023, 12(2), 453; https://doi.org/10.3390/electronics12020453 - 15 Jan 2023
Cited by 3 | Viewed by 2547
Abstract
In this paper, we introduce an electronically tuneable band-stop filter based on a dielectric resonator, along with its design principles and equivalent circuit model aimed at the coexistence of intelligent transport systems (ITS) and cellular vehicle-to-everything (C-V2X) communications operating at 5.9 GHz, with [...] Read more.
In this paper, we introduce an electronically tuneable band-stop filter based on a dielectric resonator, along with its design principles and equivalent circuit model aimed at the coexistence of intelligent transport systems (ITS) and cellular vehicle-to-everything (C-V2X) communications operating at 5.9 GHz, with the widely spread vehicular dedicated short range communications (DSRC) at 5.8 GHz. The proposed architecture involves a dielectric resonator coupled via a microstrip transmission line to a planar ring resonator. The resonance is electronically tuned by varying the bias voltage of a varactor diode placed in the ring. This design is analyzed theoretically and experimentally. For validation, a filter operating at 5.8 GHz was designed. The prototype is capable of enhancing coexistence exhibiting to features. First, when inserted into the ITS transmitter chain, it reduces unwanted transmitter emissions in the out-of-band spectrum occupied by the DSRC carriers in the 5.8 GHz frequency band of at least 25 dB, with a minimal insertion loss at 5. 9 GHz of 1.6 dB; secondly, when inserted in the ITS receiver chain, it exhibits high linearity that prevents the generation of intermodulation products falling into the filter pass band. The prototype features more than 21 dBm of third-order input intercept points, and a tuning range of 26 MHz while maintaining a minimal loaded Q factor of 93. The prototype is discussed regarding the detailed equivalent circuit parameter extraction and their dependency upon the control voltage. Full article
Show Figures

Figure 1

17 pages, 12013 KiB
Article
Design of Compact Complex Impedance Transformer with Frequency and Terminal Impedance Tunability
by Hongmei Liu, Yongquan Guo, Xinshuo Wang, Shaojun Fang and Zhongbao Wang
Electronics 2022, 11(7), 983; https://doi.org/10.3390/electronics11070983 - 22 Mar 2022
Viewed by 2315
Abstract
In the paper, a compact complex impedance transformer (CIT) composed of the cascading of three varactors loaded coupled lines and two variable shunt susceptances was proposed. Highly flexible tunability functions including only frequency tunable, only impedance tunable, and both frequency and impedance tunable [...] Read more.
In the paper, a compact complex impedance transformer (CIT) composed of the cascading of three varactors loaded coupled lines and two variable shunt susceptances was proposed. Highly flexible tunability functions including only frequency tunable, only impedance tunable, and both frequency and impedance tunable can be achieved by tuning the capacitance of two types of varactors and the value of the susceptance. Design equations were derived using the even–odd mode analysis and examples are given for descripting the design procedures. For validation, a prototype was designed and fabricated. During measurement, three cases were exhibited. When the termination impedance was fixed, the measured center frequency can be tuned in the range of 1.1–2.1 GHz (62.5%). When the frequency was determined, different terminal impedances can be matched by the prototype. The function of frequency tunable at different terminal impedances is also trated by the measured results. After comparison, the potential of the proposed CIT for applications in radio frequency front-end were demonstrated. Full article
(This article belongs to the Section Microwave and Wireless Communications)
Show Figures

Graphical abstract

17 pages, 6866 KiB
Article
A Tunable Planar Balun with an Isolation Circuit Using Varactors Loaded Coupled Lines
by Shaojun Fang, Xiaojian Guo, Hongmei Liu and Zhongbao Wang
Electronics 2020, 9(3), 401; https://doi.org/10.3390/electronics9030401 - 28 Feb 2020
Viewed by 2582
Abstract
In this paper, a frequency tunable planar balun composed of varactors loaded coupled lines (VL-CLs) is presented. By tuning the capacitances of the varactors, a wide frequency tuning range is obtained. Moreover, good impedance match, balanced output ports amplitude, and consistent output ports [...] Read more.
In this paper, a frequency tunable planar balun composed of varactors loaded coupled lines (VL-CLs) is presented. By tuning the capacitances of the varactors, a wide frequency tuning range is obtained. Moreover, good impedance match, balanced output ports amplitude, and consistent output ports phase difference (PD) are maintained during the tuning. A detailed theoretical analysis using the signal flow diagram and the even-odd mode method is presented to clarify the characteristics of the proposed balun. To achieve ideal output matching and isolation for the proposed balun, a novel frequency tuned isolation circuit (IsC) is designed and connected to the balun. In theory, a frequency tuning range of 200% can be realized. In practice, due to the limited capacitances of the varactors, a prototype with a tunable frequency of 1.0 GHz ~ 2.0 GHz (66.7%) is designed, fabricated, and measured. The measured results show that more than21 dB of return loss (RL), 180° ± 1.8° of phase difference, 0.43 dB of amplitude imbalance (AP), and 22 dB of isolation are obtained at all tuning center frequencies, agreeing well with the simulated results. Full article
(This article belongs to the Section Microwave and Wireless Communications)
Show Figures

Figure 1
