In this paper, a high-efficiency GaN Doherty power amplifier (DPA) for 5G applications in the N78 sub-6 GHz band is introduced. The theoretical analysis of the matching networks for the peak and carrier transistors is presented, with a focus on the impact of unequal power splitting for both transistors and the recommendation of a post-harmonic suppression network. The proposed design features an unequal Wilkinson power divider at the input and a post-harmonic suppression network at the output, both of which are crucial for achieving high efficiency. The Doherty power amplifier comprises two GaN 10 W HEMTs, measured across the 3.3 GHz to 3.8 GHz band (the N78 band), and the results reveal significant improvements in gain, output power, drain efficiency, and power-added efficiency. Specifically, the proposed design achieved a power gain of over 12 dB and 42 dBm saturated output power. It also achieved a drain efficiency of 80% at saturation and a power-added efficiency of 75.2%. Furthermore, the proposed harmonic suppression network effectively attenuated the harmonics at the output of the amplifier from the second to the fourth order to more than −50 dB, thus enhancing the device’s linearity. Full article

In this paper, a wideband absorptive filtering power divider (AFPD) which features the characteristics of high selectivity and flat output distributions is proposed. It is composed of one unequal width three-coupled line (TCL), two coupled lines (CLs), two stepped open-circuited stubs, two kinds of isolation resistors, and two types of absorptive branches. The design equations of the proposed AFPD are derived using an even-odd decomposition method, and parametric investigations are also performed. It is found that the passband bandwidth can be adjusted by the stepped open-circuited stub which generates two transmission zeros (TZs). By combining the TCL with the CLs, the passband bandwidth is effectively enlarged. In addition, two isolated resistors are utilized for achieving good isolation and output-port matching performance. Without affecting the passband responses, the input port absorptive feature within the whole frequency band can be obtained by loading the absorptive branches both on the input and output ports. For validation, an example operating at the center frequency of 2 GHz was modeled and tested. Results exhibit that the passband FBW reaches 72% under 1 dB criterion, which illustrates flat output port distributions. In addition, for 10 dB return loss, the input and output impedance matching bandwidths are 250% and 78%, respectively. The features of good filtering responses are demonstrated by realizing the rectangle coefficient of 1.24 and the out-of-band suppression of more than 20 dB. Full article

A compact unbalanced two-way filtering power splitter with an integrated Chebyshev filtering function is presented. The design is purely based on formulations, thereby eliminating the constant need for developing complex optimization algorithms and tuning, to deliver the desired amount of power at each of the two output ports. To achieve miniaturization, a common square open-loop resonator (SOLR) is used to distribute energy between the two integrated channel filters. In addition to distributing energy, the common resonator also contributes one pole to each integrated channel filter, hence, reducing the number of individual resonating elements used in achieving the integrated filtering power splitter (FPS). To demonstrate the proposed design technique, a prototype FPS centered at 2.6 GHz with a 3 dB fractional bandwidth of 3% is designed and simulated. The circuit model and layout results show good performances of high selectivity, less than 1.7 dB insertion loss, and better than 16 dB in-band return loss. The common microstrip SOLR and the microstrip hair-pin resonators used in implementing the proposed integrated FPS ensures that an overall compact size of 0.34 λg × 0.11 λg was achieved, where λg is the guided-wavelength of the 50 Ω microstrip line at the fundamental resonant frequency of the FPS passband. Full article
