Currently, the integration of the Global Navigation Satellite System (GNSS), Ultra-Wideband (UWB), and Inertial Navigation System (INS) has become a reliable positioning method for outdoor dynamic vehicular and airborne applications, enabling high-precision and continuous positioning in complex environments. However, environmental interference and limitations of single positioning sources pose challenges. Especially in areas with limited access to satellites and UWB base stations, loosely coupled frameworks for GNSS/INS and UWB/INS are insufficient to support robust estimation. Furthermore, within a tightly coupled framework, parameter estimations from different sources can interfere with each other, and errors in computation can easily contaminate the entire positioning estimator. To balance robustness and stability in integrated positioning, this paper proposes a comprehensive quality control method. This method is based on the semi-tightly coupled concept, utilizing the INS position information and considering the dilution of precision (DOP) skillfully to achieve complementary advantages in GNSS/UWB/INS integrated positioning. In this research, reliable position and variance information obtained by INS are utilized to provide a priori references for a robust estimation of the original data from GNSS and UWB, achieving finer robustness without increasing system coupling, which fully demonstrates the advantages of semi-tight integration. Based on self-collected data, the effectiveness and superiority of the proposed quality control strategy are validated under severely occluded environments. The experimental results demonstrate that the semi-tightly coupled robust estimation method proposed in this paper is capable of accurately identifying gross errors in GNSS and UWB observation data, and it has a significant effect on improving positioning accuracy and smoothing trajectories. Additionally, based on the judgment of the DOP, this method can ensure the output of continuous and reliable positioning results in complex and variable environments. Verified by actual data, under the conditions of severe sky occlusion and NLOS (Non-Line-of-Sight), compared with the loosely coupled GNSS/INS, the positioning accuracy in the E, N, U directions of the semi-tight coupled GNSS/INS proposed in this paper has improved by 37%, 46%, and 28%. Compared with the loosely coupled UWB/INS, the accuracy in the E and N directions of the semi-tight coupled UWB/INS has improved by 60% and 34%. In such environments, GNSS employs the RTD (Real-Time Differential) algorithm, UWB utilizes the two-dimensional plane-positioning algorithm, and the positioning accuracy of the semi-tight coupled robust model of GNSS/UWB/INS in the E, N, U directions is 0.42 m, 0.55 m, and 3.20 m respectively. Full article

The INS system’s update rate is faster than that of the GNSS receiver. Additionally, GNSS receiver data may suffer from blocking for a few seconds for different reasons, affecting architecture integrations between GNSS and INS. This paper proposes a novel GNSS data prediction method using the k nearest neighbor (KNN) predictor algorithm to treat data synchronization between the INS sensors and GNSS receiver and overcome those GNSS receiver’s blocking, which may occur for a few seconds. The experimental work was conducted on a flying drone over a minor Hungarian (Mátyásföld, 47.4992 N, 19.1977 E) model airfield. The GNSS data are predicted by four different scenarios: the first is no blocking of data, and the other three have blocking periods of 1, 4, and 8 s, respectively. Ultra-tight architecture integration is used to perform the GNSS/INS integration to deal with the INS sensors’ inaccuracy and their divergence throughout the operation. The results show that using the GNSS/INS integration system yields better positioning data (in three axes (X, Y, and Z)) than using a stand-alone INS system or GNSS without a predictor. Full article

The superiority of a global navigation satellite system (GNSS)/inertial navigation system (INS) ultra-tight integration navigation system has been widely verified. For those systems with centralized structure based on coherent-accumulation measurements (I/Q), the conversion from I/Q signals to navigation information is implemented by an observation equation. As a result, the model is highly complex and nonlinear, exerting essential influence on system performance. Based on the analysis of previous studies, a novel model and its linearization method are proposed, aiming at the integrity, stability and implicit nonlinear factors. Unlike the one-order precision in the common Jacobian matrix, two-order components are partly reserved in this model, which makes it possible for higher positioning accuracy and better convergence. For the positioning errors caused by ignoring code-loop deviation, a method to approximate code-phase is proposed without introducing new measurements. Consequently, the effect of code error can be significantly reduced, especially when the tracking loops are unstable. In the end, using real-sampled satellite signals, semi-physical experiments are carried out and the effectiveness and superiority of new methods are proved. Full article

Ultra-tight integration was first proposed by Abbott in 2003 with the purpose of integrating a global navigation satellite system (GNSS) and an inertial navigation system (INS). This technology can improve the tracking performances of a receiver by reconfiguring the tracking loops in GNSS-challenged environments. In this paper, the models of all error sources known to date in the phase lock loops (PLLs) of a standard receiver and an ultra-tightly integrated GNSS/INS receiver are built, respectively. Based on these models, the tracking performances of the two receivers are compared to verify the improvement due to the ultra-tight integration. Meanwhile, the PLL error distributions of the two receivers are also depicted to analyze the error changes of the tracking loops. These results show that the tracking error is significantly reduced in the ultra-tightly integrated GNSS/INS receiver since the receiver’s dynamics are estimated and compensated by an INS. Moreover, the mathematical relationship between the tracking performances of the ultra-tightly integrated GNSS/INS receiver and the quality of the selected inertial measurement unit (IMU) is derived from the error models and proved by the error comparisons of four ultra-tightly integrated GNSS/INS receivers aided by different grade IMUs. Full article
