In a tritium-breeding blanket of a fusion reaction, helium, used as a tritium-purging gas, will purge the tritium breeder pebble beds to extract the tritium in blanket. The purge gas flow characteristics will affect the tritium extraction efficiency. The effect of the fixed wall on the pebble packing structures and purge gas flow characteristics was investigated by combining the discrete element method (DEM) and computational fluid dynamics (CFD) method. The results indicate that the fixed wall leads to a regular packing of the pebbles adjacent to the fixed wall in association with drastic fluctuations in the porosity of the pebble bed, which can affect the purge gas flow behaviors. Further analyses of helium flow behaviors show that the helium pressure in the pebble bed decreases in a linear manner along the flow direction, whereas the pressure drop gradient of helium increases gradually with an increase in the packing factor. The reduction in porosity in the pebble bed leads to a notable escalation in helium flow velocity. Concerning the direction perpendicular to the helium gas flow, the evolution of the cut-plane averaged velocity of helium is similar to that of the porosity, except in the region immediately adjacent to the wall. The pressure drop and flow characteristics obtained in this study can serve as input for the thermohydraulic analysis of the tritium blowing systems in the tritium-breeding blanket of a fusion reactor. Full article

The flow characteristics of purge gas helium in the pebble bed of the tritium breeding blanket are important in analyzing the tritium purging process and optimizing the design of the solid breeder blanket. Therefore, the flow characteristics of helium gas in randomly packed pebble beds are investigated experimentally with a focus on the analysis of the pressure loss distribution. The results show that gas velocity, bed dimension, and pebble diameters have an obvious influence on the helium flow characteristics in pebble beds. With the increase in the inlet helium gas velocity, the pressure drop gradient of helium in the pebble bed gradually increased. With increases in the pebble bed dimension, the pressure drop gradient of helium in the pebble bed gradually increased. With the increase in the pebble diameter, the pressure drop gradient gradually decreased. In addition, the effect of temperature on the pressure drop of helium in the pebble bed was also preliminarily investigated. The pressure drop gradient of the helium through the pebble bed obviously increased with the increase in the helium and the bed temperature. The experimentally obtained pressure loss characteristics can be used for the validation of the simulation of a blanket pebble bed and as input parameters in the thermo-hydraulic analysis of solid-tritium breeder blankets. Full article

Research and development of the DEMOnstration power plant (DEMO) breeder blanket (BB) has been performed in recent years based on a predefined DEMO tritium breeding ratio (TBR) requirement, which determines a loss of wall surface due to non-breeding in-vessel components (IVCs) which consume plasma-facing wall surface and do not contribute to the breeding of tritium. The integration of different IVCs, such as plasma limiters, neutral beam injectors, electron cyclotron launchers and diagnostic systems, requires cut-outs in the BB, resulting in a loss of the breeder blanket volume, TBR and power generation, respectively. The neutronic analyses presented here have the goal of providing an assessment of the TBR losses associated with each IVC. Previously performed studies on this topic were carried out with simplified, homogenized BB geometry models. To address the effect of the detailed heterogeneous structure of the BBs on the TBR losses due to the inclusion of the IVCs in the tokamak, a series of blanket geometry models were developed for integration in the latest DEMO base model. The assessment was performed for both types of BBs currently developed within the EUROfusion project, the helium-cooled pebble bed (HCPB) and water-cooled lead–lithium (WCLL) concepts, and for the water-cooled lead and ceramic breeder (WLCB) hybrid BB concept. The neutronic simulations were performed using the MCNP6.2 Monte Carlo code with the Joint Evaluated Fission and Fusion File (JEFF) 3.3 data library. For each BB concept, a 22.5° toroidal sector of the DEMO tokamak was developed to assess the TBR and nuclear power generation in the breeder blankets. For the geometry models with the breeder blanket space filled only with blankets without considering IVCs, the results of the TBR calculations were 1.173, 1.150 and 1.140 for the HCPB, WCLL and WLCB BB concepts, respectively. The TBR impact of all IVCs and the losses of the power generation were estimated as a superposition of the individual effects. Full article

Two-phase lithium ceramic Li₂TiO₃-Li₄SiO₄ is considered as a tritium multiplier for use in the solid blanket of fusion reactors. To date, the most accurate understanding of the processes of tritium and helium production and release occurring in the breeder blanket materials under neutron irradiation can only be obtained from experiments in fission research reactors. At that, irradiations in vacuum give the possibility to register even very fast gas release processes (bursts) from the ceramics’ voids and pores, although it reduces the thermal conductivity of the pebble bed. The purpose of this work was to simulate the heating of mono-sized pebble bed (1 mm in diameter) of two-phase lithium ceramic 25 mol%Li₂TiO₃+75 mol%Li₄SiO₄ in an ampoule device during neutron irradiation at the WWR-K research reactor under vacuum conditions, and to determine experimental parameters in order to prevent heating of the lithium ceramics up to the Li₄SiO₄-Li₂SiO₃ phase transition temperatures (>900 °C). For the first time, it was obtained that the effective thermal conductivity of a 1 mm mono-sized pebble bed of 25 mol%Li₂TiO₃+75 mol%Li₄SiO₄ significantly decreases (four times) when it is irradiated with neutrons in a vacuum (at a helium pressure of approximately 10 Pa), compared to a similar calculation at 100 kPa of helium (when the He sweep is used). It was concluded that it is difficult to evaluate the maximal temperature of the ceramics in the capsule by measuring the temperature of its outer metal wall (according to thermocouple readings) without using the results of thermophysical calculations for each type of ceramic, taking into account its quantity, specific heat release and pebble size(s). To control the temperature of the ceramics during an irradiation experiment in a vacuum, an in-capsule thermocouple should be used, placed in the center of the pebble bed. Measuring the temperature of the pebble bed based on the capsule wall temperature can lead to overheating of the ceramics and phase changes. Full article

An emerging breeding blanket that fulfills performance criteria, meets the safety requirements, and is reliable enough to meet the plant availability is a challenging issue that assumes complex studies involving numerous neutronic analyses based on the Monte Carlo simulations with MCNP code. Two different concepts are now candidates to be implemented as a driver blanket for DEMO fusion reactor: WCLL (Water-Cooled Lithium Lead) and HCPB (Helium-Cooled Pebble Bed). The current R&D work within the EUROfusion DEMO project is concentrated on a search for the new water-cooled blanket layouts: a deep upgrade of the WCLL blanket to ensure a sufficient tritium breeding capability and an elaboration of the hybrid concept coupling technological advantages of water coolant, lead neutron multiplier, and ceramic breeder. To this end, very detailed, fully heterogeneous MCNP geometry models were developed for the newest designs of the WCLL-db (WCLL-double bundle) and WLCB (Water-cooled liquid Lead Ceramic Breeder) DEMO blankets to verify the new engineering solutions. This makes rigorous calculations possible to find an optimal breeder blanket layout. The basic response, tritium breeding ratio (TBR), was assessed for both concepts, and it appeared to be TBR = 1.16 for the WCLL-db and TBR ≤ 1.13 for the WLCB DEMOs, respectively. Several geometry layouts of the WLCB breeder blanket were investigated to reach the TBR sufficient for a sustainable tritium fuel cycle. Two promising novel solutions were suggested to enhance the tritium breeding performance of the WLCB blanket and to achieve TBR ≥ 1.16: heavy water coolant and an advanced breeder ceramic. Various nuclear safety aspects of the technologies utilized in both blanket concepts are addressed in this work to facilitate engineering decisions aimed at the consolidated blanket design for the upcoming DEMO reactor. Full article

For the stable and self-sufficient functioning of the DEMO fusion reactor, one of the most important parameters that must be demonstrated is the Tritium Breeding Ratio (TBR). The reliable assessment of the TBR with safety margins is a matter of fusion reactor viability. The uncertainty of the TBR in the neutronic simulations includes many different aspects such as the uncertainty due to the simplification of the geometry models used, the uncertainty of the reactor layout and the uncertainty introduced due to neutronic calculations. The last one can be reduced by applying high fidelity Monte Carlo simulations for TBR estimations. Nevertheless, these calculations have inherent statistical errors controlled by the number of neutron histories, straightforward for a quantity such as that of TBR underlying errors due to nuclear data uncertainties. In fact, every evaluated nuclear data file involved in the MCNP calculations can be replaced with the set of the random data files representing the particular deviation of the nuclear model parameters, each of them being correct and valid for applications. To account for the uncertainty of the nuclear model parameters introduced in the evaluated data file, a total Monte Carlo (TMC) method can be used to analyze the uncertainty of TBR owing to the nuclear data used for calculations. To this end, two 3D fully heterogeneous geometry models of the helium cooled pebble bed (HCPB) and water cooled lithium lead (WCLL) European DEMOs were utilized for the calculations of the TBR. The TMC calculations were performed, making use of the TENDL-2017 nuclear data library random files with high enough statistics providing a well-resolved Gaussian distribution of the TBR value. The assessment was done for the estimation of the TBR uncertainty due to the nuclear data for entire material compositions and for separate materials: structural, breeder and neutron multipliers. The overall TBR uncertainty for the nuclear data was estimated to be 3~4% for the HCPB and WCLL DEMOs, respectively. Full article

This work continues the development of a numerical model to simulate transient tritium transport on the breeder zone (BZ) level for the EU helium-cooled pebble bed (HCPB) concept for DEMO. The basis of the model is the open-source field operation and manipulation framework, OpenFOAM. The key output quantities of the model are the tritium concentration in the purge gas and in the coolant and the tritium inventory inside the BZ structure. New model features are briefly summarized. As a first relevant application a simulation of tritium transport for a single pin out of the KIT HCPB design for DEMO is presented. A variety of scenarios investigates the impact of the permeation regime (diffusion-limited vs. surface-limited), of an additional hydrogen content of 300 Pa H₂ in the purge gas, of the released species (HT vs. T₂), and of the choice of species-specific rate constants (recombination constant of HT set twice as for H₂ and T₂). The results indicate that the released species plays a minor role for permeation. Both permeation and inventory show a considerable dependence on a possible hydrogen addition in the purge gas. An enhanced HT recombination constant reduces steel T inventories and, in the diffusion-limited case, also permeation significantly. Scenarios with 80 bar vs. 2 bar purge gas pressure indicate that purge gas volumetric flow is decisive for permeation. Full article

In the tritium breeding blanket of nuclear fusion reactors, the heat transfer behavior and thermal-mechanical response of the tritium breeder pebble bed are affected by the inner packing structure, which is crucial for the design and optimization of a reliable pebble bed in tritium breeding blanket. Thus, the effect of pebble size distribution and fixed wall effect on packing structure and contact force in the poly-disperse pebble bed were investigated by numerical simulation. The results show that pebble size distribution has a significant influence on the inner packing structure of pebble bed. With the increase of the dispersion of pebble size, the average porosity and the average coordination number of the poly-disperse pebble bed gradually decrease. Due to the influence of the fixed wall, the porosity distribution of the pebble bed shows an obvious wall effect. For poly-disperse pebble bed, the influenced region of the wall effect gradually decreases with the increase of the dispersion of pebble size. In addition, the gravity effect and the pebble size distribution have an obvious influence on the contact force distribution inside the poly-disperse pebble bed. The majority of the contact force are weak contact force that is less than the average contact force. Only a few of pebbles have strong contact force that is greater than average contact force. This investigation can help in analyzing the pebble crushing characteristics and the thermal hydraulic analysis in the poly-disperse tritium breeder pebble bed. Full article

An open issue for the fusion power reactor is the choice of breeding blanket material. The possible use of Helium-Cooled Pebble Breeder ceramic material in the form of pebble beds is of great interest worldwide as demonstrated by the numerous studies and research on this subject. Lithium orthosilicate (Li₄SiO₄) is a promising breeding material investigated in this present study because the neutron capture of Li-6 allows the production of tritium, 6Li (n, t) 4He. Furthermore, lithium orthosilicate has the advantages of low activation characteristics, low thermal expansion coefficient, high thermal conductivity, high density and stability. Even if they are far from the industrial standard, a variety of industrial processes have been proposed for making orthosilicate pebbles with diameters of 0.1–1 mm. However, some manufacturing problems have been observed, such as in the chemical stability (agglomeration phenomena). The aim of this study is to provide a new methodology for the production of pebbles based on the drip casting method, which was jointly developed by the DICI-University of Pisa and Industrie Bitossi. Using this new (and alternative) manufacturing technology, in the field of fusion reactors, appropriately sized ceramic pebbles could be produced for use as tritium breeders. Full article
