Search Results (10)

Supercritical open channel flows contribute substantially to the air–water transfer process in spillways, rivers, and streams. They are characterized by strong turbulent mixing and a substantial amount of air entrainment. The microscopic air–water properties in non-uniform self-aerated flows are investigated experimentally with various chute slopes, including air chord size and air–water transfer frequency. Microscopic air–water structures are primarily affected by chute slope, whereas the approach flow Reynolds number hardly influences them, resulting in self-similarity of the probability distribution of air chord length and air–water transfer frequency distribution in the self-aerated region. The distribution of bubble chord length is more continuous from the small to large scale in the high-air-concentration region for a greater chute slope, and the position of maximum air frequency moves to the higher-aeration zone and gets closely to the free surface. Moreover, empirical relationships are provided to predict the microscopic air–water properties in non-uniform self-aerated flows. Full article

Transfer chutes are crucial components in handling bulk materials using belt conveyors. The flow of material through these devices is influenced by several variables. Traditionally, these devices have been designed based on prior experience. However, the increase in computational capacity has enabled the application of the Discrete Element Method (DEM) in their simulation by modeling the behavior of individual particles forming the bulk. The greatest challenge in this process is the selection of appropriate contact models and parameters that accurately reflect the material response. The work describes an approach used to calibrate contact parameters of a sample of moist iron ore while interacting with two distinct surface materials. The methodology starts with a variety of bench-scale tests, followed by experiments in a pilot-scale handling system, concluding with a semi-quantitative verification in an industrial-scale chute using three commercial DEM software. The findings indicate that certain tests are more responsive to specific material behavior, so that their combined use allows for a realistic representation of the material flow, even when using virtual spherical particles. Full article

In the field of handling, storage and transportation, chutes are used to transfer bulk solids between conveyors and warehouses. In these systems, traditional analytical methods based on the principles of continuum mechanics approximate an accelerated flow that contains the physical body solid properties obtained from standardized tests. Because it is difficult to physically observe the flow inside the transfer structure, there have been few studies to validate the method at full scale. In contrast, discrete element modeling (DEM) allows flow visualization through a transfer chute and qualitative and quantitative analysis if accurate simulation parameters are selected. In order to adapt to the needs of modern intelligent warehousing, we reduced the grain crushing and damage in the process of grain storage. To design and investigate the motion performance of grain particles in a sliding dustpan, this paper utilizes rocky simulation technology, combined with the corresponding bench experiments, to study the impact of the angle arrangement of the dustpan, and to verify the results of the simulation analysis based on the stress–strain analysis of the particle impact. It was found that when the angle of the dustpan arrangement was 40 degrees, the flow of all particles had a better performance in terms of pass ability and energy loss. In the continuous cycle obtained from the simulation, the particle group state at each moment is almost the same as the particle characteristics in the experiment, indicating that the angle of the bucket has an effect on the particle permeability. In this paper, the results of the study on the state of the grain group on the silo device will provide a useful reference for the design of a grain silo device. Full article

In the material transfer area, the belt is exposed to considerable damage, the energy of falling material is lost, and there is significant dust and noise. One of the most common causes of failure is transfer chute blockage, when the flow of material in the free fall or loading zone is disturbed by oversized rock parts or other objects, e.g., rock bolts. The failure of a single transfer point may cause the entire transport route to be excluded from work and associated with costly breakdowns. For this reason, those places require continuous monitoring and special surveillance measures. The number of methods for monitoring this type of blockage is limited. The article presents the research results on the possibility of visual monitoring of the transfer operating status on an object in an underground copper ore mine. A standard industrial RGB camera was used to obtain the video material from the transfer point area, and the recorded frames were processed by a detection algorithm based on a neural network. The CNN autoencoder was taught to reconstruct the image of regular transfer operating conditions. A data set with the recorded transfer blockage state was used for validation. Full article

Ore passes are often the main part of sublevel caving transportation systems, and they use gravity to move material to lower levels in the mine. During operations, the ore pass structures are exposed to the risk of stoppage and failure, leading to a long-term reduction in operational capacity and affecting productivity. The failed ore passes can be restored or rehabilitated, but the rehabilitation cost is normally high and the time to restore is usually long. To minimize disturbances and stoppage of the ore pass, alternative strategies should be considered. The appropriate design and operation of an ore pass is crucial. Therefore, this study compared running ore pass systems in a filled, near-empty, or flow-through manner using discrete event simulation. The aim was to compare the ore pass operational performance and impact on reaching the daily and 90-day production targets of 76.4 Ktonnes and 6.9 Mtonnes, respectively. The results showed that running the ore pass in flow-through mode, filled manner, and near-empty manner achieved 96%, 80%, and 81% of the production target, respectively. In mining operations where ore pass systems are used to transfer material, running them in a flow-through mode can ensure higher production and fewer hang-ups, as it lessens the chance of blocks arching over a chute throat and leads to less blasting. Full article

Sliding wear of bulk handling equipment (e.g., shovel bucket, mill and transfer chute) can be dramatically reduced by using a convex pattern surface compared to a flat surface, by adjusting the flow behavior of particles moving along the convex pattern surface. To study the effect of particle size relative to the dimensions of the convex pattern surface, a coarse graining technique is applied. Comparisons of bulk flow and wear behavior between the convex pattern and flat surfaces illustrate the two-sided effect of the convex pattern surface on sliding wear. The bulk flow behavior indicates that the particle size has a minor effect on the velocity and angular velocity of particles for the flat surface, while it has a significant effect on those of the convex pattern surface. The wear results show that the particle size has negligible influence on the sliding wear of a flat surface and a linear relationship with the sliding wear of the convex pattern surface. The convex pattern surface can reduce the sliding wear through influencing the flow behavior of the bulk material when the equivalent radius of the convex is larger than $r_{50}$ of particles. This research reveals the relationship between the dimensions of the convex pattern and the particle size on the sliding wear caused by the interaction between bulk material and bulk handling equipment. The relationship should be carefully considered for the applications of the convex pattern surface to bulk handling equipment. Full article

Transfer chutes for bulk material conveying systems have significant importance in ship loading and unloading and are ‘worn’ from large mass flow and fast granular material flow conditions. In this investigation, the impact forces of different granular materials on the transfer chute wear process are considered; the DEM–FEM (Discrete Element Method–Finite Element Method) coupling method was used to calculate the wear and the deformation of the transfer chute. The stress–strain and cumulative contact energy from three different granular materials were analyzed under different working conditions. The results show that the wear, stress–strain, and cumulative contact energy of the transfer chute are closely related to the belt speed, the chute inclination angle, and the types of granular materials; the impact force and the stress–strain on the transfer chute achieves maximum value under a 4 m/s belt speed condition; meanwhile, with the increase of belt speed by 0.5 m/s, the wear of the transfer chute increases 25% and the deformation increases 20%; the shape variable, wear area, and normal cumulative contact capacity of the transfer chute are the smallest with a transfer chute inclination angle from 40° to 45°. Full article

This paper addresses the problem of conveyor transfer station design in harsh operating conditions, aiming to identify and eliminate a failure phenomenon which interrupts aggregate supply. The analyzed transfer station is located in a Polish granite quarry. The study employs laser scanning and reverse engineering methods to map the existing transfer station and its geometry. Next, a discrete element method (DEM) model of granite aggregate has been created and used for simulating current operating conditions. The arch formation has been identified as the main reason for breakdowns. Alternative design solutions for transfer stations were tested in DEM simulations. The most uncomplicated design for manufacturing incorporated an impact plate, and a straight chute has been selected as the best solution. The study also involved identifying areas of the new station most exposed to wear phenomena. A new transfer point was implemented in the quarry and resolved the problem of blockages. Full article

As with most high-velocity free-surface flows, stepped spillway flows become self-aerated when the drop height exceeds a critical value. Due to the step-induced macro-roughness, the flow field becomes more turbulent than on a similar smooth-invert chute. For this reason, cascades are oftentimes used as re-aeration structures in wastewater treatment. However, for stepped spillways as flood release structures downstream of deoxygenated reservoirs, gas transfer is also of crucial significance to meet ecological requirements. Prediction of mass transfer velocities becomes challenging, as the flow regime differs from typical previously studied flow conditions. In this paper, detailed air-water flow measurements are conducted on stepped spillway models with different geometry, with the aim to estimate the specific air-water interface. Re-aeration performances are determined by applying the absorption method. In contrast to earlier studies, the aerated water body is considered a continuous mixture up to a level where 75% air concentration is reached. Above this level, a homogenous surface wave field is considered, which is found to significantly affect the total air-water interface available for mass transfer. Geometrical characteristics of these surface waves are obtained from high-speed camera investigations. The results show that both the mean air concentration and the mean flow velocity have influence on the mass transfer. Finally, an empirical relationship for the mass transfer on stepped spillway models is proposed. Full article

The multiple protocols that have been developed to characterize river hydromorphology, partly in response to legislative drivers such as the European Union Water Framework Directive (EU WFD), make the comparison of results obtained in different countries challenging. Recent studies have analyzed the comparability of existing methods, with remote sensing based approaches being proposed as a potential means of harmonizing hydromorphological characterization protocols. However, the resolution achieved by remote sensing products may not be sufficient to assess some of the key hydromorphological features that are required to allow an accurate characterization. Methodologies based on high resolution aerial photography taken from Unmanned Aerial Vehicles (UAVs) have been proposed by several authors as potential approaches to overcome these limitations. Here, we explore the applicability of an existing UAV based framework for hydromorphological characterization to three different fluvial settings representing some of the distinct ecoregions defined by the WFD geographical intercalibration groups (GIGs). The framework is based on the automated recognition of hydromorphological features via tested and validated Artificial Neural Networks (ANNs). Results show that the framework is transferable to the Central-Baltic and Mediterranean GIGs with accuracies in feature identification above 70%. Accuracies of 50% are achieved when the framework is implemented in the Very Large Rivers GIG. The framework successfully identified vegetation, deep water, shallow water, riffles, side bars and shadows for the majority of the reaches. However, further algorithm development is required to ensure a wider range of features (e.g., chutes, structures and erosion) are accurately identified. This study also highlights the need to develop an objective and fit for purpose hydromorphological characterization framework to be adopted within all EU member states to facilitate comparison of results. Full article
