The China Fusion Engineering Test Reactor (CFETR), a superconducting magnetic confinement tokamak fusion reactor, will develop a high-performance torus cryopump to pump torus plasma exhaust gas. The inlet valve is one of the key components of the cryopump, and it is used to isolate the cryopump from the plasma for regeneration, to control the pumping speed of the cryopump, and to operate as a pressure relief valve in case of a failure, such as the cryopipe breaking inside the cryopump chamber. This paper presents a novel inlet valve. Ensuring that the design of the inlet valve meets the above requirements will be a challenge. In order to verify the reliability of the inlet valve, its critical components are analyzed and optimized by the Finite Element Method. The effect of the stroke of the inlet valve on pumping performance is then estimated by the Monte Carlo Method, and the pressure profile in the whole flow field is studied to predict the cryopump’s behavior. Finally, the seismic capacity of the optimized inlet valve is analyzed, and the mechanical performance of the inlet valve is shown to meet CFETR design criteria. These design and analysis results will provide technical support and references for the development of the CFETR torus cryopump. Full article

In the chemical and water treatment industries, it is necessary to achieve maximum contact between the solid and liquid phase, thus promoting the mass and heat transfer, to obtain a homogeneous solution. Increasing stirring speed is the most recommended solution in different types of reactors: stirred tank, column, and tubular. However, this inadvertently increases the energy consumption of the industry. Determination of the minimum speed, labeled the just suspended speed (N_js) and crucial to attaining homogeneity, has been widely investigated. Numerous studies have been carried out to assess formulas for determining the solid particle speed in various reactor types. Given the limitations of the existing formulations based on a generalization of a unique equation for computing N_js for all soil classifications, it appears that most formulas can only approximate complex phenomena that depend on several parameters. A novel formula was developed, and the results given in this paper demonstrate the effectiveness of generating significant uncertainties for the estimation of N_js. The purpose of this study was the elaboration of experiment-based data-driven formulas to calculate N_js for different particle size classes. Nonlinear multiple regression (MNLR) models were used to generate the new formulas. The gradient descent optimization algorithm was employed to solve the hyperparameters of each novel equation, utilizing supervised learning. A comparison of the data indicated that the unique formulas presented in this study outperformed empirical formulas and provide a useful means for lowering energy consumption, while increasing the heat and mass transfer in torus type reactors. Full article

Chemical processes often exhibit nonlinear dynamics and tend to generate complex state trajectories, which present challenging operational problems due to complexities such as output multiplicity, oscillation, and even chaos. For this reason, a complete knowledge of the static and dynamic nature of these behaviors is required to understand, to operate, to control, and to optimize continuous stirred tank reactors (CSTRs). Through nonlinear analysis, the possibility of output multiplicity, self-sustained oscillation, and torus dynamics are studied in this paper. Specifically, output multiplicity is investigated in a case-by-case basis, and related operation and control strategies are discussed. Bifurcation analysis to identify different dynamic behaviors of a CSTR is also implemented, where operational parameters are identified to obtain self-oscillatory dynamics and possible unsteady-state operation strategy through designing the CSTR as self-sustained periodic. Finally, a discussion on codimension-1 bifurcations of limits cycles is also provided for the exploration of periodic forcing on self-oscillators. Through this synergistic study on the CSTRs, possible output multiplicity, oscillatory, and chaotic dynamics facilitates the implementation of novel operation/control strategies for the process industry. Full article

At present, two main magnetic confinement fusion devices exist: tokamaks and stellarators. Moreover, stellarators have been demonstrated to be a good alternative to tokamaks, due to their ability to operate in continuous mode, which eventually translates into a higher commercial profitability. In stellarators, the magnetic confinement of the plasma is achieved exclusively by the coils, thus no electric current through the plasma is needed. In particular, this article presents the Columbia Non-Neutral Torus stellarator that is located in the Automatic Control Group of Euskal Herriko Unibertsitatea (EHU). This EHU stellarator maintains symmetry in its structure due to the topology of the mesh that is formed by its coils. A cornerstone of future fusion reactors is to obtain real-time control that enables a sustained reaction. In this article, a control-oriented model for the installed magnetic confinement coils is presented. The model is based on matrices that preserve symmetry, which is defined from physical principles and then validated by different sets of experimental data. Then, based on this model, a novel predictive control suited to this particular model with symmetric objective function is implemented in the numerical simulations, and its response is compared to that of traditional controllers. Finally, this control is implemented in a real plant and the satisfactory experiment results provide validation of both the numerical model and proposed controller. Full article

Plasma properties can be useful in a wide spectrum of applications. Experimental projects on controlled nuclear fusion are the most challenging of these applications and, at the same time, the best way to approach plasma science. Since nuclear fusion reactors can ensure a large-scale, safe, environmentally-friendly and virtually inexhaustible source of energy, several fusion-oriented megaprojects and innovative companies are appearing all over the world. PROTO-SPHERA (Spherical Plasma for HElicity Relaxation Assessment) is the first plasma project with a simply connected configuration, namely not requiring additional objects inside the plasma volume. This is obtained by a plasma arc, shaped as a screw pinch, acting as the centerpost of a spherical torus with minimal aspect ratio. Due to its intrinsic physical, engineering and economic advantages, this new approach is attractive also on an industrial scale and with several developments that still needs to be explored. This paper presents the PROTO-SPHERA basic principles, its first encouraging results and its expected and potential evolutions. Full article
