Search Results (7)

Search Parameters:
Keywords = time of emptying a tank

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
12 pages, 16508 KiB
Article
Integration of Payload Sensors to Enhance UAV-Based Spraying
by Celso O. Barcelos, Leonardo A. Fagundes-Júnior, André Luis C. Mendes, Daniel C. Gandolfo and Alexandre S. Brandão
Drones 2024, 8(9), 490; https://doi.org/10.3390/drones8090490 - 17 Sep 2024
Cited by 6 | Viewed by 1716
Abstract
This work focuses on the use of load sensors to help with spraying tasks using unmanned aerial vehicles (UAVs). The study details the construction of a prototype for load measurement to validate the proof of concept. To simulate the application of agricultural pesticides, [...] Read more.
This work focuses on the use of load sensors to help with spraying tasks using unmanned aerial vehicles (UAVs). The study details the construction of a prototype for load measurement to validate the proof of concept. To simulate the application of agricultural pesticides, the UAV follows a predefined route and an image processing system detects the presence of diseased plants. After detection, the UAV pauses its route momentarily and activates the spraying device. The payload sensor monitors the fertilizer application process, which determines whether the amount of pesticide has been fully applied. If the storage tank is empty or the remaining quantity is insufficient for another operation, the system will command the UAV to return to the base station for refueling. Experimental validations were carried out in an indoor controlled environment to verify the proposal and the functionality of the in-flight payload monitoring system. Additionally, the UAV’s flight controller demonstrated robust performance, maintaining stability despite the challenges posed by liquid-load oscillations and varying payloads during the spraying process. In summary, our main contribution is a real-time payload monitoring system that monitors weight during flight to avoid over- or under-spraying. In addition, this system supports automatic refueling, detecting low levels of pesticides and directing the UAV to return to base when necessary. Full article
Show Figures

Figure 1

16 pages, 4429 KiB
Article
Accelerated Ballast Tank Corrosion Simulation Protocols: A Critical Assessment
by Remke Willemen, Kris De Baere, Rob Baetens, Maarten Van Rossum and Silvia Lenaerts
Materials 2024, 17(10), 2304; https://doi.org/10.3390/ma17102304 - 13 May 2024
Viewed by 1354
Abstract
In the realm of accelerated testing within controlled laboratory settings, the fidelity of the service environment assumes paramount importance. It is imperative to replicate real-world conditions while compressing the testing duration to facilitate early evaluations, thereby optimizing time and cost efficiencies. Traditional immersion [...] Read more.
In the realm of accelerated testing within controlled laboratory settings, the fidelity of the service environment assumes paramount importance. It is imperative to replicate real-world conditions while compressing the testing duration to facilitate early evaluations, thereby optimizing time and cost efficiencies. Traditional immersion protocols, reflective solely of full ballast tank conditions, inadequately expedite the corrosion process representative of an average ballast tank environment. Through the integration of immersion with fog/dry conditions, aligning the test protocol more closely with the internal conditions of an average ballast tank, heightened rates of general corrosion are achieved. This augmentation yields an acceleration factor of 7.82 times the standard test duration, under the assumption of a general corrosion rate of 0.4 mm/year for uncoated ballast tank steel, with both sides exposed. Subsequently, the fog/dry test protocol, albeit only resembling the environment of an empty ballast tank, closely trails in terms of acceleration efficacy. The fog/dry test protocol offers cost-effectiveness and replicability compared to the AMACORT CIFD-01 protocol, making it a strong competitor despite the relatively close acceleration factor. Full article
(This article belongs to the Section Corrosion)
Show Figures

Figure 1

11 pages, 2582 KiB
Article
Design and Analysis of a Novel Air Bubble Curtain for Mixing and Aeration in Process Vessels
by Omar Chaalal, Chandra Mouli R. Madhuranthakam, Husain Al Hashimi, Marouane Chaalal and Weam S. K. Abudaqqa
Processes 2023, 11(9), 2669; https://doi.org/10.3390/pr11092669 - 6 Sep 2023
Viewed by 2207
Abstract
This article focuses on designing and analyzing a new method for mixing in process vessels. We propose using an air bubble curtain to accomplish the desired mixing. The air bubble curtain used in this study is made of an empty pipe with several [...] Read more.
This article focuses on designing and analyzing a new method for mixing in process vessels. We propose using an air bubble curtain to accomplish the desired mixing. The air bubble curtain used in this study is made of an empty pipe with several holes through which air is pumped, which in turn produces a swarm of bubbles that causes pseudo-turbulent mixing in the tank filled with a liquid solution. A uniform distribution of bubbles within the tank was assured by maintaining a see-saw movement of the air bubble curtain. Mixing inside the tank was quantified by measuring the salt concentration in a laboratory model tank (30 cm × 30 cm × 30 cm) and a pilot-scale tank (200 cm × 100 cm × 100 cm). The optimal flow rates of air and the mixing time in both tanks that can achieve complete mixing were obtained from the experimental results. The proposed air bubble curtain can be of potential use in wastewater treatment, biotechnology, and aquaculture where turbulent mixing is required with minimum energy dissipation per unit mass. Full article
(This article belongs to the Section Chemical Processes and Systems)
Show Figures

Figure 1

20 pages, 2834 KiB
Article
A Study on the Flow Resistance of Fluids Flowing in the Engine Oil-Cooler Chosen
by Bogdan Derbiszewski, Marek Wozniak, Lukasz Grala, Michal Waleciak, Maksym Hryshchuk, Krzysztof Siczek, Andrzej Obraniak and Przemyslaw Kubiak
Lubricants 2021, 9(8), 75; https://doi.org/10.3390/lubricants9080075 - 29 Jul 2021
Cited by 4 | Viewed by 6574
Abstract
Oil-coolers are necessary components in high performance diesel engines. The heat removed by the cooler is a component in the total heat rejection via the engine coolant. Oil-cooler absorbs the heat rejected during the piston cooling and engine rubbing friction power loss. During [...] Read more.
Oil-coolers are necessary components in high performance diesel engines. The heat removed by the cooler is a component in the total heat rejection via the engine coolant. Oil-cooler absorbs the heat rejected during the piston cooling and engine rubbing friction power loss. During flows of both coolant and engine oil via the oil-cooler, some flow resistances occur. The aim of the study is to determine values of the flow resistance coefficient for oil going through the cooler at various temperatures. The test stand was developed to determine time needed to empty tanks from liquids flowing through oil-cooler. The flow model was elaborated to study the mentioned flow resistance coefficient with respect to changing liquid temperature. The 20 °C increase in liquid temperature resulted in a flow resistance coefficient decrease of 30% for coolant and of the much more for engine oil. It was found that better results would be achieved with flows forced by means of pumps instead of using gravitational forces on the test stand. Full article
(This article belongs to the Special Issue Automotive Tribology II)
Show Figures

Figure 1

26 pages, 10575 KiB
Article
Drainage of a Water Tank with Pipe Outlet Loaded by a Passive Rotor
by Mohamed Elgamal, Karim Kriaa and Mohamed Farouk
Water 2021, 13(13), 1872; https://doi.org/10.3390/w13131872 - 5 Jul 2021
Cited by 5 | Viewed by 5428
Abstract
The optimal design of pipe outlets is an essential objective for many engineering projects. For the first time, this paper reports the results of a laboratory investigation on the effect of using a passive rotor (added at the pipe outlet) on the outlet [...] Read more.
The optimal design of pipe outlets is an essential objective for many engineering projects. For the first time, this paper reports the results of a laboratory investigation on the effect of using a passive rotor (added at the pipe outlet) on the outlet performance. Different sizes and numbers of blades of rotors were considered. Through the Tracker software package, video and image processing techniques were applied to capture the temporal variations of the tank water depth and the passive rotor’s angular speed. In addition, a normalized average drainage rate (NADR) parameter is defined to quantify the changes in the tank drainage rate as a result of passive rotor utilization. It is noted that adding a 4-bladed symmetric passive rotor will increase NADR by up to 9.0%. The study also shows that the highest increase in NADR is attained when the rotor diameter size is approximately 1.73 times the pipe outlet’s diameter for the case of symmetric 4-blade rotors, and the corresponding average tip rotor speed ratio is 1.65. It is also found that using an asymmetric 3-blade rotor has a negative impact on the NADR due to the significant perturbation produced by the rotor asymmetry. Full article
(This article belongs to the Section Oceans and Coastal Zones)
Show Figures

Figure 1

33 pages, 6276 KiB
Article
A Case Study of a Small Diameter Gravity Sewerage System in Zolkiewka Commune, Poland
by Tadeusz Nawrot, Radosław Matz, Ryszard Błażejewski and Marcin Spychała
Water 2018, 10(10), 1358; https://doi.org/10.3390/w10101358 - 29 Sep 2018
Cited by 10 | Viewed by 5734
Abstract
This article presents a small diameter gravity sewerage system in a rural area. In this system, domestic wastewater was preliminarily treated in septic tanks equipped with outlet filters, so the effluent features were similar to those of clear water. Additionally, some outlets were [...] Read more.
This article presents a small diameter gravity sewerage system in a rural area. In this system, domestic wastewater was preliminarily treated in septic tanks equipped with outlet filters, so the effluent features were similar to those of clear water. Additionally, some outlets were equipped with floating-ball check valves to avoid backflow. One of the pressure mains was used as a gravity collector conveying septic tank effluent in the direction of the pumping station during pump idle time. The operation of the system was simulated using SWMM computer code. The simulation results were validated for data obtained from part of a sewerage system in Kolonia Zolkiew and Rozki village consisting of two pumping stations and 86 serviced households using polyethylene pipes of outer diameter 50–63 mm. The results of the measurement of the outflows from one pumping station are presented. The simulation results showed good agreement with the empirical data, especially after several simulation days. The greatest discrepancy during the start-up period was the consequence of the initial conditions describing the empty pipework. Thanks to storage in the pump sumps, septic tank and pipes, as well as their smart operation, a relatively uniform inflow to the pumping stations was achieved. Simulations in SWMM showed that there is still potential to optimize the sewerage system through more adequate pump selection and pipe diameters. Full article
(This article belongs to the Special Issue Smart Hydraulics in Wastewater Transport)
Show Figures

Figure 1

16 pages, 31615 KiB
Article
Draining Water from Aircraft Fuel Using Nitrogen Enriched Air
by Michael Frank and Dimitris Drikakis
Energies 2018, 11(4), 908; https://doi.org/10.3390/en11040908 - 12 Apr 2018
Cited by 2 | Viewed by 5658
Abstract
This paper concerns a computational study of the process of removing water from an aircraft’s fuel tank by pumping nitrogen enriched air (NEA) from the bottom of the tank. This is an important procedure for the smooth, efficient, and safe operation of the [...] Read more.
This paper concerns a computational study of the process of removing water from an aircraft’s fuel tank by pumping nitrogen enriched air (NEA) from the bottom of the tank. This is an important procedure for the smooth, efficient, and safe operation of the aircraft’s engine. Due to the low partial pressure of water in the pumped NEA, it absorbs water from the fuel. The water-laden bubbles enter the ullage, the empty space above the fuel, and escape into the environment. The effects of the number of NEA inlets and the NEA mass flow rate on the timescale of the NEA pumping were investigated using Computational Fluid Dynamics. The results reveal that the absorption of water by the NEA bubbles is low and is not affected by the number of the inlets used. Yet, the water content in the fuel decreases fast during the procedure, which is the desired outcome. We show that this is due to the relatively dry NEA entering the ullage and displacing the moist air, thus reducing the partial pressure of water at the fuel/ullage interface. This shift from equilibrium conditions forces water to evaporate from the fuel’s entire surface. Furthermore, the amount of water migrating from the fuel directly into the ullage is significantly greater than that absorbed by the rising bubbles. In turn, the rate of decrease of the water content in the ullage is determined by the total NEA mass flow rate and this is the dominant contributor to the draining time, with the number of NEA nozzles playing a minor role. We confirmed this by pumping NEA directly into the ullage, where we observe a significant decrease of water even when the NEA is not pumped through the fuel. We also show that doubling the mass flow rate halves the draining time. When considering the capability of most modern aircraft to pump NEA through the fuel as part of their inerting system, the proposed method for removing water is particularly attractive, requiring very little (if at all) design modification. Full article
Show Figures

Graphical abstract
