Ultrasonic TOFD imaging, as an important non-destructive testing method, has a wide range of applications in pipeline girth weld inspection and testing. Due to the limited bandwidth of ultrasonic transducers, near-surface defects in the weld are masked and cannot be recognized, resulting in poor longitudinal resolution. Affected by the inherent diffraction effect of scattered acoustic waves, defect images have noticeable trailing, resulting in poor transverse resolution of TOFD imaging and making quantitative defect detection difficult. In this paper, based on the assumption of the sparseness of ultrasonic defect distribution, by constructing a convolutional model of the ultrasonic TOFD signal, the Orthogonal Matching Pursuit (OMP) sparse deconvolution algorithm is utilized to enhance the longitudinal resolution. Based on the synthetic aperture acoustic imaging model, in the wavenumber domain, backpropagation inference is implemented through phase transfer technology to eliminate the influence of diffraction effects and enhance transverse resolution. On this basis, the time-domain sparse deconvolution and frequency-domain synthetic aperture focusing methods mentioned above are combined to enhance the resolution of ultrasonic TOFD imaging. The simulation and experimental results indicate that this technique can outline the shape of defects with fine detail and improve image resolution by about 35%. Full article

In this study, the full-focusing (FF) algorithm is reviewed with the objective of optimizing it for processing data from different types of surfaces probed in altimetry. In particular, this work aims to provide a set of optimal FF processing parameters for the Sentinel-6 Michael Freilich (S6-MF) mission. The S6-MF satellite carries an advanced radar altimeter offering a wide range of potential FF-based applications which are just beginning to be explored and require prior optimization of this processing. In S6-MF, the Synthetic Aperture Radar (SAR) altimeter acquisitions are known to be aliased in the along-track direction. Depending on the target, aliasing can be tolerated or may be a severe impairment to provide the level of performance expected from FF processing. Another key aspect to consider in this optimization study is the unprecedented resolution of the FF processing, which results in a higher posting rate than the standard SAR processing. This work investigates the relationship between posting rate and noise levels and provides recommendations for optimal algorithm configurations in various scenarios, including transponder, open ocean, and specular targets like sea-ice and inland water scenes. The Omega–Kappa (WK) algorithm, which has demonstrated superior CPU efficiency compared to the back-projection (BP) algorithm, is considered for this study. But, unlike BP, it operates in the Doppler frequency domain, necessitating further precise spectral and time domain settings. Based on the results of this work, real case studies using S6-MF acquisitions are presented. We first compare S6-MF FF radargrams with Sentinel-1 (S1) images to showcase the potential of optimally configured FF processing. For highly specular surfaces such as sea-ice, distinct techniques are employed for lead signature identification. S1 relies on image-based lineic reconstruction, while S6-MF utilizes phase coherency of focalized pulses for lead detection. The study also delves into two-dimensional wave spectra derived from the amplitude modulation of image/radargrams, with a focus on a coastal example. This case is especially intriguing, as it vividly illustrates different sea states characterized by varying spectral peak positions over time. Full article

As a key object on the ocean, regulating civilian and military ship targets more effectively is a very important part of maintaining maritime security. One of the ways to obtain high-resolution images of ship targets is the inverse synthetic aperture radar (ISAR) imaging technique. However, in the actual ISAR imaging process, ship targets in a formation often lead to complicated motion conditions. Due to the close distance between the ship targets, the rough imaging results of the targets cannot be completely separated in the image domain, and the small differences in motion parameters lead to overlapping phenomena in the Doppler history. Therefore, for situations in which ship formation targets with little difference in motion parameters are included in the same radar beam, this paper proposes a multi-domain joint ISAR separation imaging method for multi-ship targets. First, the method performs echo separation using the Hough transform (HT) with the minimum entropy autofocus method in the image domain. Secondly, the time–frequency curve is extracted in the time–frequency domain using the short-time Fourier transform (STFT) for time–frequency analysis, which solves the problem of the ship formation targets being aliased on both echo and Doppler history after range compression and achieves the purpose of separating the echo signals of the sub-ship targets with high accuracy. Eventually, better-focused images of each target are obtained via further motion compensation and precise imaging. Finally, the effectiveness of the proposed method is verified using a simulation and measured data. Full article

Traditional ultrasonic testing uses a single probe or phased array probe to investigate and visualize defects by adapting certain imaging algorithms. The time-domain synthetic aperture focusing technique (T-SAFT) is an imaging algorithm that employs a single probe to scan along the test specimen in various positions, to generate inspection images with better resolution. Both the T-SAFT and phased array probes are contact methods with limited bandwidth. This work aims to combine the advantages of the T-SAFT and phased array in a noncontact way with the aid of laser ultrasonics. Here, a pulsed laser beam is employed to generate ultrasonic waves in both thermoelastic and ablation regimes, whereas the laser Doppler vibrometer is used to acquire the generated signals. These two lasers are focused on the test specimen and, to avoid the plasma and crater influence in the ablation regime, the transmission beam and reception beam are separated by 5 mm. By moving the test specimen with a step size of 0.5 mm, a 1D linear phased array (41 and 43 elements) with a pitch of 0.5 mm was synthesized, and three side-drilled holes (Ø 8 mm—thermoelastic regime, Ø 10 mm and Ø 2 mm—ablation regime) were introduced for inspection. The A-scan data obtained from these elements were processed via the T-SAFT algorithm to generate the inspection images in various grid sizes. The results showed that the defect reflections obtained in the ablation regime have better visibility than those from the thermoelastic regime. This is due to the high-amplitude signals obtained in the ablation regime, which pave the way for enhancing the pixel intensity of each grid. Moreover, the separation distance (5 mm) does not have any significant effect on the defect location during the reconstruction process. Full article

A method to enhance laser ultrasound (LUS) image reconstruction with the time-domain synthetic aperture focusing technique (T-SAFT) is presented, in which the acoustic velocity is extracted in situ with curve fitting. The operational principle is provided with the help of a numerical simulation, and the confirmation is provided experimentally. In these experiments, an all-optic LUS system was developed by using lasers for both excitation and detection of ultrasound. The acoustic velocity of a specimen was extracted in situ by fitting a hyperbolic curve to its B-scan image. The needle-like objects embedded within a polydimethylsiloxane (PDMS) block and a chicken breast have been successfully reconstructed using the extracted in situ acoustic velocity. Experimental results suggest that knowing the acoustic velocity in the T-SAFT process is important not only in finding the depth location of the target object but also for producing a high resolution image. This study is expected to pave the wave to the development and usage of all-optic LUS for bio-medical imaging. Full article

We propose a GPU-accelerated implementation of frequency-domain synthetic aperture focusing technique (SAFT) employing truncated regularized inverse k-space interpolation. Our implementation achieves sub-1s reconstruction time for data sizes of up to 100 M voxels, providing more than a tenfold decrease in reconstruction time as compared to CPU-based SAFT. We provide an empirical model that can be used to predict the execution time of quasi-3D reconstruction for any data size given the specifications of the computing system. Full article

We present a new solution for the phase-preserving focusing of synthetic aperture radar (SAR) raw data acquired through the Terrain Observation with Progressive Scan (TOPS) mode. The proposed algorithm consists of a first interpolation stage of the TOPS raw data, which takes into account the Doppler Centroid frequency variations due to the azimuth antenna steering function, and allows us to unfold the azimuth spectra of the TOPS raw data. Subsequently, the interpolated signals are processed by using conventional phase-preserving SAR focusing methods that exploit frequency domain and spectral analyses algorithms, which are extensively used to efficiently process Stripmap and ScanSAR data. Accordingly, the developed focusing approach is easy to implement. In particular, the presented focusing approach exploits one of the available frequency domain Stripmap processing techniques. The only modification is represented by the inclusion, within the 2D frequency domain focusing step, of a spurious azimuth chirp signal with a properly selected azimuthal rate. This allows us to efficiently carry out the TOPS azimuth focusing through the SPECAN method. Furthermore, an important aspect of this algorithm is the possibility to easily achieve a constant and tunable output azimuth pixel size without any additional computing time; this is a remarkable feature with respect to the full-aperture TOPS-mode algorithms available in the existing literature. Moreover, although tailored on Sentinel-1 (S1) raw data, the proposed algorithm can be easily extended to process data collected through the TOPS mode by different radar sensors. The presented experimental results have been obtained by processing real Sentinel-1 raw data and confirm the effectiveness of the proposed algorithm. Full article
