Search Results (2)

Search Parameters:
Keywords = thermal time-of-flight (TTOF)

Order results
Result details
Results per page
Show export options expand_more Show export options expand_less
Select all
Export citation of selected articles as:
14 pages, 8245 KiB
Communication
Semi-Empirical Approach to Gas Flow Velocity Measurement by Means of the Thermal Time-of-Flight Method—Further Investigation
by Jacek Sobczyk
Energies 2022, 15(6), 2166; https://doi.org/10.3390/en15062166 - 16 Mar 2022
Cited by 1 | Viewed by 1760
Abstract
This paper describes a study to expand the knowledge as to whether a thermal wave anemometer can be used to measure the velocity of flowing gases or gas mixtures in situ. For this purpose, several series of measurements were performed in laboratory conditions [...] Read more.
This paper describes a study to expand the knowledge as to whether a thermal wave anemometer can be used to measure the velocity of flowing gases or gas mixtures in situ. For this purpose, several series of measurements were performed in laboratory conditions using both the previously used probe and other probes of similar design. The probes were not modified mechanically or electrically in any way. The obtained results were compared with each other, and on this basis, the optimal, though purely empirical, form of the calibration function was determined (4). The analysis of the relative differences between the measured and set velocity values showed that they do not exceed 1% in the velocity range from 0.05 to 2.5 m/s. Lowering the sensitivity of the method for velocities below approx. 0.05 m/s results in a rapid increase in the observed deviations, reaching 15% for 0.015 m/s. The conducted research also revealed an increased resistance of the proposed measurement method to small flow disturbances, both longitudinal and transverse, and a reduced sensitivity to non-optimal positioning of the probe in relation to the flow direction, relative to the methods using both detectors. Full article
►▼ Show Figures

Figure 1

16 pages, 3185 KiB
Communication
A Semi-Empirical Approach to Gas Flow Velocity Measurement by Means of the Thermal Time-of-Flight Method
by Jacek Sobczyk, Andrzej Rachalski and Waldemar Wodziak
Sensors 2021, 21(17), 5679; https://doi.org/10.3390/s21175679 - 24 Aug 2021
Cited by 2 | Viewed by 2005
Abstract
This paper presents a method of measuring gas flow velocity based on the thermal time-of-flight method. The essence of the solution is an analysis of the time shift and the shape of voltage signals at the transmitter and at a temperature wave detector. [...] Read more.
This paper presents a method of measuring gas flow velocity based on the thermal time-of-flight method. The essence of the solution is an analysis of the time shift and the shape of voltage signals at the transmitter and at a temperature wave detector. The measurements used a probe composed of a wave transmitter and a detector, both in the form of thin tungsten wires. A rectangular signal was used at the wave transmitter. The time-of-flight of the wave was determined on the basis of the time shift of two selected characteristic points of the voltage waveform at the transmitter and the wave detector. To obtain the correct velocity indication, a correction in the form of a simple power function was applied. From the measurements performed, the relative uncertainty of the method was obtained, from approx. 4% of the measured value at an inflow velocity of 6.5 cm/s to 1% for an inflow velocity of 50 cm/s and higher. Full article
(This article belongs to the Section Physical Sensors)
►▼ Show Figures

Figure 1
