The aim of this study is to prove that it is possible to control the static behavior of tensegrity plate-like structures. This possibility is very important, particularly in the case of deployable structures. Here, we analyze the impact the support conditions of the structure have on the existence of specific characteristics, such as self-stress states and infinitesimal mechanisms, and, consequently, on the active control. Plates built with Simplex modules are considered. Firstly, the presence of the specific characteristics is examined, and a classification is carried out. Next, the influence of the level of self-stress state on the behavior of structures is analyzed. A geometrically non-linear model, implemented in an original program, written in the Mathematica environment, is used. The results confirm the feasibility of the active control of stiffness of tensegrity plate-like structures characterized by the presence of infinitesimal mechanisms. In the case when mechanisms do not exist, structures are insensitive to the initial prestress level. It is possible to control the occurrence of mechanisms by changing the support conditions of the structure. Based on the obtained results, tensegrity is very promising structural concept, applicable in many areas, when conventional solutions are insufficient. Full article

The study includes a parametric analysis of a group of tensegrity plate-like structures built with modified Quartex modules. The quantitative assessment, including the calculation of the structure’s response to constant loads, was carried out. A static parametric analysis was performed, with particular emphasis on the influence of the initial prestress level on the displacements, the effort, and the stiffness of the structure. A geometrical non-linear model was used in the analysis. A reliable assessment required introducing a parameter for determining the influence of the initial prestress level on the overall stiffness of the structure at a given load. The stiffness of the structure was found to depend not only on the geometry and material properties, but also on the initial prestress level and external load. The results show that the effect of the initial prestress on the overall stiffness of the structure is greater with less load and that the effect of load is most significant with low pre-stressing forces. The analysis demonstrates that the control of static parameters is possible only when infinitesimal mechanisms occur in the structure. Full article

The study includes parametric analysis of special spatial rod grids called tensegrity plate-like structures. Tensegrity structures consist of only compression and tension components arranged in a system, whose unique mechanical and mathematical properties distinguish them from conventional cable–strut frameworks. Complete analysis of tensegrity structures is a two-stage process. The first stage includes the identification of self-stress states and infinitesimal mechanisms (qualitative analysis). The second stage focuses on the behaviour of tensegrities under external loads (quantitative analysis). In the paper, a qualitative analysis of tensegrity plate-like structures built with modified Quartex modules was conducted. Starting from a single-module structure, more complex cases were sequentially analysed. The different ways of plate support were considered. To carry out a qualitative assessment, a spectral analysis of the truss matrices and singular value decomposition of the compatibility matrix were used. The characteristic features of tensegrity structures were identified. On this basis, the plates were classified into one of the four groups defined in the paper, i.e., ideal tensegrity, “pure” tensegrity and structures with tensegrity features of class 1 or class 2. This classification is important due to different behaviours of the structure under external actions. The qualitative analysis carried out in the paper is the basis for a quantitative analysis. Full article

By finding the minimum total potential energy of a structural system with a defined degree of freedoms assigned as design variables, it is possible to find the equilibrium condition of the deformed system. This method, called total potential optimization using metaheuristic algorithms (TPO/MA), has been verified on truss and truss-like structures, such as cable systems and tensegric structures. Harmony Search (HS) algorithm methods perfectly found the analysis results of the previous structure types. In this study, TPO/MA is presented for analysis of plates for plane stress members to solve general types of problems. Due to the complex nature of the system, a novel hybrid Harmony Search (HHS) approach was proposed. HHS is the hybridization of local search phases of HS and the global search phase of the Flower Pollination Algorithm (FPA). The results found via HHS were verified with the finite element method (FEM). When compared with classical HS, HHS provides smaller total potential energy values, and needs less iterations than other new generation metaheuristic algorithms. Full article
