In this work, we attempt to explain the phenomenon of sulfur corrosion of power boiler water walls under the conditions of large fluctuations in carbon monoxide concentrations. To assess the conditions required for corrosion formation, a criterion based on the chemical and flow field parameters of the flue gas is proposed. The formulated sulfur corrosion criterion is based on the mixture fraction variance and the turbulence time scale. Numerical modeling of coal combustion in a 250 MW power boiler is performed using ANSYS. Two cases of combustion in a boiler are analyzed, with the first simulating the boiler operated using classic high-swirl burners and the second one accounting for boiler operation with modified low-swirl burners. Calculations of pulverized coal combustion are performed using the standard k-$\epsilon$ turbulence model and the combustion described by the mixture fraction. The simulation results reveal that the low-swirl burner is characterized by higher values of the mixture fraction variance and a higher frequency of fluctuation of the velocity field, which is strongly related to an increased corrosion rate. The study outcomes show the validity of using the criterion of the mixture fraction variance and velocity field fluctuations to determine the areas at risk of sulfur corrosion. Full article

This study analyzes the combustion of pellets and briquettes made of plant biomass in low-power heating devices powered periodically with fuel being placed on the grate, as well as after modification using an automatic fuel feeding system in the gutter burner. The use of herbaceous biomass in the form of pellets in low-power heating devices with automatic fuel feeding and combustion in a gutter burner is not widely promoted and popular. Therefore, this study used four types of herbaceous waste biomass (wheat straw, rye straw, oat straw and hay) and one type of woody waste biomass (birch sawdust) for testing. The basic chemical characteristics were determined for the raw materials. After appropriate preparation, the selected starting materials were subjected to briquetting and pelleting processes. Selected physical properties were also determined for the obtained biofuels. Biofuels made from birch sawdust had the lowest heat value (16.34 MJ·kg⁻¹), although biofuels made from wheat, rye and hay straw had a slightly lower calorific value, respectively: 16.29; 16.28 and 16.26 MJ·kg⁻¹. However, the calorific value of oat straw biofuels was only 15.47 MJ kg⁻¹. Moreover, the ash content for herbaceous biomass was 2–4 times higher than for woody biomass. Similar differences between herbaceous and woody biomass were also observed for the nitrogen and sulfur content. To burn the prepared biofuels, a domestic grate-fired biomass boiler was used, periodically fed with portions of fuel in the form of pellets or briquettes (type A tests), which was then modified with a gutter burner enabling the automatic feeding of fuel in the form of pellets (type B tests). During the combustion tests with simultaneous timing, the concentration of CO₂, CO, NO and SO₂ in the exhaust gases was examined and the temperature of the supplied air and exhaust gases was measured. The stack loss (qA), combustion efficiency index (CEI) and toxicity index (TI) were also calculated. The research shows that the use of automatic fuel feeding stabilizes the combustion process. The combustion process is balanced between herbaceous and woody biomass biofuels. Disparities in CO₂, CO and T_gas emissions are decreasing. However, during type B tests, an increase in NO emissions is observed. At the same time, the research conducted indicates that the combustion of herbaceous biomass pellets with their automatic feeding into the combustion chamber is characterized by an increase in combustion efficiency, indicating that when the combustion process is automated, they are a good replacement for wood biofuels—both pellets and briquettes. Full article

The filtration of liquid sulfur is a key operation in the production of sulfuric acid that is used for phosphate fertilizer production in Morocco and elsewhere. The purpose of the filtration process is to remove solid impurities from liquid sulfur, which could clog the sulfur burner spray nozzles, leading to the reduction of the lifetime of the sulfuric acid production unit. The standard life cycle operation for sulfuric acid units is 24 months, while due to clogging, this lifetime can be reduced to less than 18 months, which is obviously a tremendous economic disadvantage. In the liquid sulfur filtration process, a precoat made of diatomaceous earth is usually used. In this work, the performance of a standard diatomaceous earth filter aid was compared to the performance of two commercial, inexpensive, cellulose-based filter aids, namely, FILTER-900 and FILTER-1100, which are distinguished by their respective Dalton numbers (900 Da and 1100 Da). The experiments were realized using an industrial sulfur filtration device, and the results indicated that all three of the filter aids yielded similar performance in terms of the impurity content in the filtered liquid sulfur. The cellulose-based filter aids did, however, show a lower specific filter-aid consumption, accompanied by an increase in operating cycle times from 24 to 72 h. In addition, the use of the cellulose-based filters allowed for the relatively easy removal of the filter cake without damaging the filter cloths (which is often an issue with the diatomaceous earth filter aids). It was further noticed that the filtered liquid sulfur obtained using the cellulose-based filter aids remained uncontaminated by silicate, which is one of the main elements that can result in clogging of the sulfur spray nozzles. The first experimental data presented here are therefore promising, and further industrial tests as well as economic analysis for using cellulose-based filter aids in industrial sulfuric acid production are encouraged. Full article

A small combustion chamber was developed and manufactured for empirical combustion testing of several alternative fuels developed to meet IMO emission limits for fuel oil used in ships. The combustion chamber consists of four independent tanks and a circulation system with a two-stage heating function owing to the high viscosity and temperature of ship fuel. A gun-type burner is mounted on the side of the combustion chamber, which possesses a cylindrical shape and a capacity of less than 300 L. This device was manufactured in accordance with several variables such that the basic stage performance and simulation tests of each fuel could be sufficiently completed before performing the combustion test to simulate the engines of large ships. To conduct an initial experiment using the developed combustion chamber, low-sulfur MGO with a sulfur content less than or equal to 0.05% was chosen, and ideal operating parameters were selected according to the measurement tests based on load control. The exhaust gas temperature differed by approximately 10.7% as a result of burning MGO at a burner load state of 80–100%. The use of a normal oxygen concentration of 4% helped remove approximately 14.31 ppm of nitrogen oxide and 1.91% of carbon dioxide. The maximum combustion efficiency was 70.17%, indicating the chamber’s potential for use in a variety of combustion tests of alternative fuels for ships in the forthcoming years. Full article

This paper presents the results of research on the energetic use of self-combusted hemp pellets and co-firing with pine pellets. The tests were carried out with the use of a boiler equipped with a Lester Projekt Company gasifying burner and an automatic fuel feeding system. The boiler is equipped with an additional heat exchanger that enables the simulation of any heat load. The experimental stand so built guaranteed to obtain results adequate to the real operating conditions. The research material consisted of pellets made of waste biomass of the Futura 75 sowing hemp and pine sawdust pellets. The experiment was carried out in five proportions by mass of mixtures of both fuels (C-hemp, P-pine): 0:100 (P100), 25:75 (C25/P75), 50:50 (C50/P50), 75:25 (C75/P25), 100:0 (C100). For each variant, the following were determined: effective boiler power, boiler energy balance, boiler energy efficiency, the volumetric composition of flue gas (carbon monoxide, carbon dioxide, hydrogen, sulfur dioxide, nitrous oxide), excess air coefficient and the dust content of particle matter—PM10, PM2.5. The heating value was also determined for hemp pellets and pine sawdust pellets, accordingly 17.34 and 19.87 MJ·kg⁻¹. The obtained test results were related both to the volume of exhaust gases leaving the boiler and to one kilowatt hour of heat produced. The obtained test results showed that the boiler fed with pine pellets achieved the highest thermal power (P100)—14.17 kW, while the smallest—hemp pellets (C100)—4.92 kW. The CO₂ emissivity increased with the addition of pine pellets, from 26.13 g (C100) to 112.36 g (P100) relating to 1 m³ and from 430.04 g (C100) to 616.46 g (C25/P75) relating to 1 kWh of heat. In terms of dust emissions, it was found that the combustion of hemp pellets and mixtures thereof is a little worse than that of pine pellets. Full article

In industrial smelters, sulfuric acid is manufactured using the elemental sulfur in a series of three-unit operations: elemental sulfur oxidation, sulfur dioxide catalytic conversion, and sulfur trioxide absorption. The sulfur oxidation, which is the basic step in this process, is generally performed under a sulfur combustion furnace that ensures the production of the process gas stream, which will be the main supply stream to the other unit operations. In this paper, a dynamic model is developed based on the fundamental mass and energy balance, including the sulfur oxidation and the dynamic flow behavior aspects within the furnace. The obtained model is simulated in the Matlab/Simulink environment and data from an industrial plant were used to validate the model. The simulation results and the plant measurement comparison showed an accuracy of 96%, with a mean absolute error of 16.12 °C and a root mean square error of 23.27 °C. Afterwards, the effect of different operating conditions and disturbance parameters on the sulfur combustion furnace performance were studied. Finally, the relationship and a correlation between the temperature and sulfur dioxide molar fraction at the outlet of the furnace were investigated for industrial use. Full article

The paper presents the estimation of sulfur dioxide emissions as an effect of coal and pellet combustion in an automatic boiler equipped with a retort burner based on the actual heat consumption required for heating a building and heating domestic hot water for a single-family house in Poland. In Poland, automatic boilers with an installed retort burner are popular and can be used to burn various fragmented solid fuels. In Poland, the most popular solid fuel burned in boilers with a retort burner is crushed coal, called eco-pea coal. The second fuel used in automatic boilers with a retort planer is biomass in the form of pellets, which is classified as a renewable energy source. Heat consumption during the combustion of eco-pea coal was measured over a period of three years. Based on the heat consumption and coal and pellet combustion emission factors in the automatic boilers, the average annual emissions of sulfur dioxide using the eco-pea coal and pellets were estimated. The presented results of the analysis indicate a significant reduction in the sulfur dioxide emitted into the atmosphere by replacing eco-pea coal with fuel sourced from biomass in the form of pellets. Full article
