“Three straight and two flat” is the inevitable demand when realizing the intelligent mining of a fully mechanized mining face. To address the crucial technical issue of lacking accurate perception of the shape of the scraper conveyor during intelligent coal mining, a three-dimensional curvature sensor involving fiber Bragg grating (FBG) is used as a perceptive tool to conduct curve reconstruction research based on different local motion frames and to reconstruct the shape of the scraper conveyor. Firstly, the formation process of the ‘S’-shaped bending section of the scraper conveyor during the pushing process is determined. Based on the FBG sensing principle, a mathematical model between the variation in the central wavelength and the strain and curvature is established, and the cubic B-spline interpolation method is employed to continuously process the obtained discrete curvature. Secondly, based on differential geometry, a spatial curve reconstruction algorithm based on the Frenet moving frame is derived, and the shape curve prediction interpolation model is built based on a gated recurrent unit (GRU) model, which reduces the impact of the decrease in curve reconstruction accuracy caused by damage to some grating measuring points. Finally, an experimental platform was designed and built, and sensors with curvature radii of 6 m, 7 m, and 8 m were tested. The experimental results showed that the reconstructed curve was essentially consistent with the actual shape, and the absolute error at the end was about 2 mm. The feasibility of this reconstruction algorithm in engineering has been proven, and this is of great significance in achieving shape curve perception and straightness control for scraper conveyors. Full article

In order to solve the key technical problem of accurate perception of the straightness of a scraper conveyor in intelligent mining of coal mines, a three-dimensional (3D) curvature sensor of fiber Bragg grating (FBG) is designed and developed based on the curvature sensing principle of FBG. The grating string embedded in the FBG curvature sensor is simulated under the radius of curvature of 100 m, 200 m, 300 m, 400 m and 500 m. The results show that the strain of the built-in FBG string is linearly related to the curvature at the bend of the FBG string. The simulation results are consistent with the theoretical results, which verifies the rationality of the sensor design. Based on the discrete curvature information obtained by the 3D curvature sensor of FBG, the curve reconstruction algorithm is derived by using the method of fitting recursion, and the bending shape fitting perception and curve reconstruction of the scraper conveyor is realized. A test platform for the three-dimensional bending of the scraper conveyor is set up. The measuring effect of perceived and actual shape at the straight and bending states of the scraper conveyor is verified. The test results show that the measured curve is basically the same as the perceptual curve in the three-dimensional bending configuration of the scraper conveyor, and the error of the direction of each coordinate axis is not more than ±15 mm, which can meet the requirements of the accuracy of detecting the straightness of the intelligent work. Full article

Measuring the straightness of the scraper conveyor, which is an indispensable piece of equipment in a fully mechanized coal face, can prevent accidents such as derailment of the shearer and is also important for the precise positioning of the shearer and the accurate control of the hydraulic support. The existing scraper conveyor straightness measurement methods have the disadvantages of inconsistent measurement cost, accuracy, and reliability as well as low dimension of straightness description. To this end, this paper proposes a method for monitoring the three-dimensional straightness of a scraper conveyor based on binocular vision. Trapezoidal window matching technology was used to realize the image acquisition of multiple stations and multiple sensors. The bit pose acquisition model of binocular vision 3D reconstruction was used to obtain the 3D coordinates of the feature points on the sign board in each local coordinate system and the bit pose information of each sign board. The pose relay videometric method was used to convert the straightness in each local coordinate system to the global coordinate system to realize the 3D reconstruction of the scraper conveyor. Finally, the straightness measurement test of the preset scraper conveyor was carried out, and the error analysis was carried out by comparing with the manual measurement results, which showed that the measurement errors were all within ±30 mm. At the same time, the standard deviation of errors in both directions was small, which indicates that the straightness measurement method for the scraper conveyor in this paper has high reliability. In addition, the visual measurement process is independent of each other, so there is no error accumulation in the visual straightness measurement method. The analysis shows that the method of measuring the straightness of a scraper conveyor based on binocular vision can realize continuous and real-time monitoring of the scraper conveyor. Full article

The accurate perception of straightness of a scraper conveyor is important for the construction of intelligent working faces in coal mines. In this paper, we propose a precision compensation model based on rotation error angle to improve the accuracy of the fiber Bragg grating (FBG) curvature sensor of a scraper conveyor. The correctness of the model is verified by theoretical analysis, numerical simulation, and experiments. Finally, the feasibility of the model is analyzed and discussed for field application in a coal mine. When the rotation error angle is within the range of 0~90°, according to the strain of FBG obtained by numerical simulation, the radius of the curvature is inversely calculated by the compensation model. The relative error of each discrete point is within ±0.9%, and the relative error after fitting is less than 0.2%. The experiment shows that the relative error of the curvature radius after fitting according to the theoretical formula is less than ±3%, and the relative error of the curvature radius value obtained by the inverse deduction of each discrete point is less than ±6%, which verifies the correctness and applicability of the compensation model. In addition, the compensation model with the FBG curvature sensor has broad application prospects in coal mine underground conveyors, submarine pipelines and ground pipelines. Full article
