Fracture toughness is an important index related to the service safety of marine risers, and weld is an essential component of the steel catenary risers. In this paper, microscopic structure characterization methods such as scanning electron microscopy (SEM) and electron back scatter diffraction (EBSD), as well as mechanical experiments like crack tip opening displacement (CTOD) and nanoindentation, were employed to conduct a detailed study on the influence of the microstructure characteristics of multi-wire submerged arc welded seams of steel catenary riser pipes on CTOD fracture toughness. The influence mechanisms of each microstructure characteristic on fracture toughness were clarified. The results show that the main structure in the weld of the steel catenary riser is acicular ferrite (AF), but there is also often side lath plate ferrite (FSP) and grain boundary ferrite (GBF). With the increase in the proportion of FSP and GBF in the weld microstructure, the CTOD fracture toughness of the weld decreases gradually. The weld AF is a braided cross arrangement structure, and most of the grain boundary orientation difference is higher than 45°. The effective grain size refinement of AF can effectively prevent crack propagation and significantly improve fracture toughness. GBF is distributed along proto-austenitic grain boundaries PAGB, and the large hardness difference between the GBF and the AF matrix weakens the grain boundary. Cracks can easy be initiated at the interface position of the two phases and can propagate along the GBF grain boundary, resulting in the deterioration of toughness. Although the hardness of FSP is between that of GBF and AF, it destroys the continuity of the overall weld microstructure and is also unfavorable to toughness. Full article

At present, researchers in the field of pipeline inspection focus on pipe wall defects while neglecting pipeline defects in special situations such as welds. This poses a threat to the safe operation of projects. In this paper, a multi-node fusion and modal projection algorithm of steel pipes based on guided wave technology is proposed. Through an ANSYS numerical simulation, research is conducted to achieve the identification, localization, and quantification of axial cracks on the surface of straight pipelines and internal cracks in circumferential welds. The propagation characteristics and vibration law of ultrasonic guided waves are theoretically solved by the semi-analytical finite element method in the pipeline. The model section is discretized in one-dimensional polar coordinates to obtain the dispersion curve of the steel pipe. The T(0,1) mode, which is modulated by the Hanning window, is selected to simulate the axial crack of the pipeline and the L(0,2) mode to simulate the crack in the weld, and the correctness of the dispersion curve is verified. The results show that the T(0,1) and L(0,2) modes are successfully excited, and they are sensitive to axial and circumferential cracks. The time–frequency diagram of wavelet transform and the time domain diagram of the crack signal of Hilbert transform are used to identify the echo signal. The first wave packet peak point and group velocity are used to locate the crack. The pure signal of the crack is extracted from the simulation data, and the variation law between the reflection coefficient and the circumferential and radial dimensions of the defect is calculated to evaluate the size of the defect. This provides a new and feasible method for steel pipe defect detection. Full article

Rock particles in excavated materials can damage and wear down slurry discharge pipelines when slurry shield tunneling occurs in a pebble layer and rock ground. This pipeline damage and wear, if not properly dealt with, can lead to a broken-down tunneling machine. Based on a slurry shield tunneling project in China, damage and wear were thoroughly examined. The observed pipeline wear and leaks, transported rock particles, mechanical properties, and flow rate of the carrier slurry were presented. The measured results showed that the wear rates of a straight pipe, a pipe along a curved tunnel, a 60° inclined pipe, and a 90° elbow pipe in pebble ground were approximately 0.71 mm/100 rings, 1 mm/100 rings, 2.14 mm/100 rings, and 4 mm/100 rings, respectively. When the machine drove into rock ground, the wear rates increased by one to two times, which could be attributed to the sharper particle shapes. Countermeasures to address these issues, such as adjusting the pipeline layout, welding reinforcement plates in advance, and preparing additional pipes, were highlighted. The wear rates of different types of pipes, the effectiveness of new pipeline fixing methods, and the probability of pipeline leaks in different strata were discussed in detail. Full article

Squared hollow steel profiles are commonly used in the construction of offshore structures or building facades. By welding two or more pipes, typical joints are created that are specific for different areas of applications. These joints are less resistant than straight pipes due to the geometrical heterogeneity and the complex stress behavior of the welding. Standards define these joints, but there are restrictions imposed regarding the material or geometry. This paper focused on full-overlapped joints with squared hollow section profiles and on-top connection, which are disregarded in current standards. The aim was to figure out the influence of the inclination angle on the resistance of the joint. In the analysis, experimental and numerical studies were performed. Four different inclination angles commonly used on construction sites were the focus. It was discovered that there is a total diminishment of 46% in the load bearing capacity between the steepest and the most obtuse angles. The structural behavior is non-linear and is influenced by the value of the angles. The second aspect is related to the influence of the steel profile, which is evaluated by a comparison between a squared profile and two circular profiles. It was discovered that the joint made with squared profiles has a higher bearing capacity than the one made with circular profiles, a statement valid for similar thicknesses of the elements. Full article

Erosion caused by solid particles in a pipeline is one of the main problems endangering the safety production of the oil and gas industry, which may lead the equipment to malfunction or even fail. However, most of the previous studies focused on the standard elbow, and the erosion law of right-angle elbow and blind tee is rarely reported in the literature. This work aims to investigate the erosion law of different pipeline structures including 90° elbow, right-angle pipe, and tee pipe based on the production characteristics and engineering parameters of the gas field. An integrated CFD-DPM method is established including a realizable k-ε turbulence model, discrete phase model, and erosion rate prediction model. The accuracy of the model is evaluated by a series of experimental data of flow conditions of our previous work. Further, the erosion rate, pressure distributions, and particle trajectories in 90° elbow, right-angle pipe, and tee pipe under different flow velocities, particle mass flow rate, pipe diameter are investigated by applying the presented model. The results show that the blind tee has the most obvious growth rate, and the most serious erosion is located in the blind end of the pipe wall. The maximum erosion rate of the 1.5D is greater than that of the 3D elbow as a whole, and the 1.5D elbow is more concentrated in the serious erosion area. Furthermore, the erosion rate of the bend weld is much greater than that of the straight pipe weld. This study can provide a basis for the selection of different structural pipe fittings, thereby reducing the pipeline erosion rate and improving the integrity of the management of gas pipelines. Full article

Aiming at the forming efficiency and roundness of the longitudinal submerged arc welded (LSAW) pipes in JCO (J-shape to C-shape to O-shape) forming process, this paper proposes a four-point air bending process. Compared with the traditional three-point air bending process, The new process can provide a more uniform bending moment, does not need to crimp the edges of steel sheet, shorten the residual straight segment length, and lengthen the forming length in single pass. The mechanical model is established to analyze the static equilibrium conditions and elastic–plastic deformation. The process is simulated by using the software package ABAQUS, to find the maximum punch spacing, and further determine the formulation principles of other process parameters. In addition, a contour detection method for the LSAW pipes in forming process is proposed based on machine vision (planar-array CCD camera produced by Gray Point Corporation, Vancouver, Canada). This method can not only quickly detect the contour of each pass, but also splice the detected contours together to obtain the overall contour with the given splicing algorithm. According to the measured contour, the bending angle, radius, and roundness can be calculated, to correct the punch reduction in the next pass and improve the forming accuracy of the pipes. Finally, an experimental system is designed to verify the proposed four-point bending JCO forming process and contour detection method. The result shows that the error between the contour detection method and CMM (coordinate measuring machine) is less than 0.5% for the overall contour, the two experimental pipes require 13 and 15 passes respectively, the roundness of pipes are less than 1.1%, which is much better than that of traditional three-point bending JCO forming process. Full article

Pipeline inspection gauges (PIGs) carry out automatic pipeline inspection with nondestructive testing (NDT) technologies like ultrasound, magnetic flux leakage, and eddy current. The ultrasonic straight beam allows technicians to determine the wall thickness of the pipeline through the time of flight diffraction (TOFD), providing the pipeline reconstruction and allowing the detection of several defects like dents or corrosion. If the pipeline is of a long distance, then the inspection process is automatic, and the fluid pressure pushes the PIG through the pipeline system. In this case, the PIG velocity and its axial alignment with the pipeline cannot be controlled. The PIG geometry, the pipeline deformations, and the girth welds cause a continuous chattering when the PIG is running, removing the transducers perpendicularity with the inspection points, which means that some echoes cannot be received. To reduce this problem, we propose a novel method to design a sensor carrier that takes into account the angularity and distance effects to acquire the straight beam echoes. The main advantage of our sensor carrier is that it can be used in concave and convex pipeline sections through geometric adjustments, which ensure that it is in contact with the inner pipe wall. Our improvement of the method is the characterization of the misalignment between the internal wall of the pipeline and the transducer. Later, we analyzed the conditions of the automatic pipeline inspection, the existing recommendations in state-of-the-art technology, and the different mechanical scenarios that may occur. For the mechanical design, we developed all the equations and rules. At the signal processing level, we set a fixed gain in the filtering step to obtain the echoes in a defined distance range without saturating the acquisition channels. For the validation, we compared through the mean squared error (MSE) our sensor carrier in a straight pipe section and a pipe elbow of steel versus other sensor carrier configurations. Finally, we present the design parameters for the development of the sensor carrier for different pipeline diameters. Full article

TA1/X65 bimetallic plate has a bright future of application by combining the excellent corrosion resistance of TA1 and the high strength of inexpensive X65 steel, while manufacturing large size TA1/X65 bimetallic plate is still a challenging task. Multi-pass hot-rolling is the most common way to achieve a large size bimetallic plate. In this work, interface characteristic of explosive-welded and multi-pass hot-rolled TA1/X65 bimetallic plate is experimentally studied. The microstructure, composition and microhardness distribution across the TA1/X65 interface are investigated by optical metallographic observation, scanning electron microscope (SEM) observation, energy dispersive spectrometer (EDS) analysis, and Vickers hardness test. Shear tests and stratified tensile tests are conducted with emphasis on impacts of the angle between loading direction and detonation wave propagation direction on interface strength. A straight TA1/X65 interface with periodic morphology of residual peninsula could be observed on the cross section parallel to detonation wave propagation direction, while in most cases there is no residual peninsula morphology on the straight TA1/X65 interface when the cross section is perpendicular to detonation wave propagation direction. TA1/X65 interface of explosive-welded and multi-pass hot-rolled bimetallic plate presents higher bearing capacity for the load perpendicular to detonation wave propagation direction than that for the load parallel to detonation wave propagation direction. The results of this paper have a certain guiding significance for the fabrication of pipes and containers made of explosive-welded and hot-rolled TA1/X65 bimetallic plate. Full article
