This paper proposes a novel suspended seismic structure system called Base-suspended Pendulum Isolation (BSPI) structure. The BSPI structure can isolate seismic action and reduce structural seismic response by hanging the structure with hanger rods set at the base. The viscous dampers are installed in the isolation layer to dissipate earthquake energy and control the displacement. Firstly, the configuration of suspension isolation layer and mechanical model of the BSPI structure are described. Then, an equivalent scaled BSPI structure physical model was tested on the shaking table. The test results demonstrate that the BSPI structure has a good isolation effect under earthquakes, and the viscous dampers had an obvious control effect on the structure’s displacement and acceleration response. Finally, numerical simulation of the tests was carried out. The accuracy of the numerical models are confirmed by the good agreement between the simulation and test results. The numerical models for the BSPI structure and conventional reinforced concrete (RC) frame structure are built and analyzed using the commercial software ABAQUS. Research results indicate that the lateral stiffness of the BSPI structure is reduced greatly by installing the suspension layer, and the acceleration response of BSPI structure is significantly reduced under rare earthquakes, which is only 1/2 of that of the RC frame. The inter-story displacement of the BSPI structure is less than 1/100, which meets the seismic fortification goal and is reduced to 50% of that of the BSPI structure without damper under rare earthquakes. Full article

The hybrid cable-stayed and suspension (HCSS) bridge is known for its stability and cost-effectiveness, with significant application potential. This study examined the static performance of an HCSS bridge with a 1440 m main span. A finite element model (FEM) was developed to assess key parameters, such as the span-to-rise ratio, cable-to-hanger ratio, pylon stiffness, steel–concrete interface, and cable stiffness. Through FEM analysis and parameter optimization using the zero-order and first-order optimization methods in an ANSYS module, key design variables were optimized. The results show that an inappropriate span-to-rise ratio negatively impacts mid-span girder forces, while increasing the cable-stayed area enhances the overall stiffness. Main cable stiffness plays a crucial role in load-bearing and deformation control. Significant force differences were observed between stay and hanger cables, with axial force in the main girder increasing from the side span to the pylon under dead load. Bending moments in the transition region varied widely under combined loads. Optimizing parameters, such as the span-to-rise and cable-to-hanger ratios, significantly improved the mechanical performance of HCSS bridges, offering valuable insights for future designs. Full article

When the arch rib of the mid-bearing through and lower-bearing through arch bridges undergoes out-of-plane deformation, it is usually subject to the resilience force provided by the flexible hanger, which is known as the “non-conservative force effect” of the suspender. In contrast to the static condition, in the dynamic scenario, the time-varying non-conservative force exerted by the flexible suspender becomes more complex due to dynamic changes in external load. Moreover, the difference in fundamental frequency and vibration period between the bridge system and arch rib may influence the stress distribution within the arch rib during ground motion. This paper investigates the impact of time-varying non-conservative forces on the dynamic stability of arch ribs in concrete-filled steel tube (CFST) bridges under seismic loads. Specifically, it examines the influence of different seismic waveforms, frequency disparities between bridge slabs and arch ribs, and suspender stiffness on the non-conservative effect. The results reveal significant disparities in the impact of non-conservative forces exerted by the suspender during seismic events with identical intensity but varying frequency characteristics. The influence of non-conservative forces on the dynamic stability of bridges escalates as deck stiffness increases, while it remains relatively unaffected by changes in suspender stiffness. Full article

The fatigue problem of hangers is fatal for the safety of the whole bridge structure. The objective of this study is to present a strain monitoring-based method to assess the fatigue performance of stiff hangers in highway arch bridges and predict their remaining life. A vehicle–bridge interaction system was constructed to analyze the dynamic behavior in the area close to the key welding line where the hanger was connected to the deck slab. Then, the empirical mode decomposition (EMD) algorithm and rain-flow counting algorithm were used in signal preprocessing and statistical analysis of field monitoring data. Finally, the fatigue life was assessed according to the standards in the Chinese Code for the Design of Steel Structures, as well as the Eurocode 3 and AASHTO codes. Differences were found in the fatigue behavior of hangers, and the shortest hanger was shown to surfer more serious fatigue damage. The influence of vehicle volume growth and low-stress amplitude on the fatigue performance was also discussed. Full article

In tied-arch bridges with a single arch, the deck is usually suspended from the arch by means of a single set of cables, pinned at both ends and anchored to the centerline, using either vertical or Nielsen-type hanger arrangements. When properly designed, this layout can significantly reduce forces and deflections under loads that are symmetrical with respect to the plane of the arch. However, it does not contribute to the support of nonsymmetrical loads, such as eccentric loads distributions or wind loading, and does not reduce the sensibility of the arch to out-of-plane buckling. Thus, this paper studies how a cable arrangement composed of two sets of lateral hangers, attached to both edges of a deck, can be very suitable to address these problems. Firstly, it is demonstrated that the structural behavior under symmetrical loads improves with respect to the bridge with centered hangers. Secondly, it is shown how nonsymmetric loads are partially carried by structural systems (such as the transversal stiffness both of the arch and the deck) that would remain inactive for tied-arch bridges with centered hangers, leading to a general reduction in the forces and the deflections of the bridge and in the critical buckling load of the arch. Full article

In the design process of an arch bridge, the designer may decide to stiffen the hangers linking the arch and the deck, usually in order to reduce the internal forces or the deflections. In this paper, the effect of stiffened hangers on the longitudinal in-plane structural behavior of arch bridges is studied. Then, the effect of the stiffness of the hangers and the relevance of the arch–deck relative stiffness are shown. The paper also describes how stiff hangers with a hinge—either at the bottom or the top—combine very high structural efficiency and ease of execution. Once the advantages of stiff hangers are described and a possible drawback is highlighted. The problem may arise for stiffened hangers, as the bending moments near the ends of the deck might become more adverse for symmetrical load cases than for asymmetrical load distributions, as this usually occurs in arch bridges. To address this problem, this paper suggests a novel solution by designing a combination of fixed and pinned hangers, which can be as efficient as a configuration where all the hangers are fixed, while simultaneously reducing the bending moment at the end zones of the deck. Full article
