As gas wells enter later production stages, the formation pressure decreases and liquid accumulates at the bottom of the gas well. The formation pressure is insufficient to lift the accumulated liquid from the bottom of the well to the surface. At this time, a large number of gas wells need to undergo intermittent production to maintain their production capacity. This article focuses on the four stages of intermittent production in gas wells, considering the changes in slip gas holdup, pressure, and gas–liquid flow in and out of tubing and casing, and establishes a transient mathematical model for intermittent production in gas wells in stages. By using the dynamic tracking technology of moving liquid slugs to divide the wellbore grid and solve it in stages, the optimal shut-in time for intermittent production of gas wells was obtained. The transient mathematical model developed for intermittent gas well production achieved a high historical fit accuracy of over 90%. This indicates that the simulation results are in line with the actual situation of gas well intermittent production and can effectively guide intermittent production. The optimized intermittent production system of gas wells has a higher cumulative gas production compared to the original system, achieving the optimization of intermittent production system. This method is beneficial for guiding efficient production of gas wells in low-pressure formations. Full article

Under casing annulus gas venting, the annulus of the well is in a special state of zero-net liquid flow (ZNLF), leading to gas production without liquid at the wellhead, resulting in significant holdup issues. Therefore, conventional two-phase flow models cannot be used for calculation. To study the flow characteristics of ZNLF in the annulus of the well, this study established a visual experimental device with a total height of 5.4 m, an outer pipe inner diameter of 140 mm, and an inner pipe outer diameter of 72 mm. The flow characteristics of ZNLF were studied by controlling the casing pressure, initial liquid level, and bottom gas injection rate. The experimental results showed that the flow patterns of ZNLF are mainly bubbly flow and churn flow. Bubbly flow occurred at lower gas rates, while churn flow occurred at higher gas rates. In addition, the experiment found that when the gas injection rate and initial liquid column height were controlled to be the same, the liquid holdup decreased as the casing pressure increased. Analysis of the data patterns indicated that the slip velocity is related to the casing pressure. Based on the experimental results of ZNLF in the annulus, this study established standards for flow pattern transitions, holdup, and a pressure drop calculation model. The model results showed good agreement with the experimental results, with errors not exceeding ±5%. Full article

Gas injection is a frequently used method for artificial lift and flow regime rectification in offshore production and transportation flowlines. The flow behaviour in such flowlines is complex and a better understanding of flow characteristics, such as flow patterns, void fraction/hold up distributions and pressure gradient is always required for efficient and optimal design of downstream handling facilities. Injection method and location have been shown to strongly affect downstream fluid behaviour that can have important implications for pumping and downstream facility design, especially if the development length between pipeline and downstream facility is less than L/D = 50 as reported by many investigators. In this article, we provide the results of an experimental investigation into the effects of the gas injection position on the characteristics of the downstream upwards vertical gas flow using a vertical riser with an internal diameter of 52 mm and a length of 10.5 m. A horizontal 40-m-long section connected at the bottom provides options for riser base or horizontal flow line injection of gas. The flowline gas injection is performed 40 m upstream of the riser base. A 16 by 16 capacitance wire mesh sensor and a gamma densitometer were used to measure the gas-liquid phase cross-sectional distribution at the riser top. A detailed analysis of the flow characteristics is carried out based on the measurements. These include flow regimes, cross-sectional liquid holdup distributions and peaking patterns as well as analysis of the time series data. Our findings show that flow behaviours differences due to different gas injection locations were persisting after a development length of 180D in the riser. More specifically, core-peaking liquid holdup occurred at the lower gas injection rates through the flowline, while wall-peaking holdup profiles were established at the same flow conditions for riser base injection. Wall peaking was associated with dispersed bubbly flows and hence non-pulsating as against core-peaking was associated with Taylor bubbles and slug flows. Furthermore, it was found that the riser base injection generally produced lower holdups. It was noted that the circumferential injector used at the riser base promoted high void fraction and hence low liquid holdups. Due to the bubbly flow structure, the slip velocity is smaller than for larger cap bubbles and hence the void fraction is higher. The measurements and observations presented in the paper provides valuable knowledge on riser base/flowline gas introduction that can directly feed into the design of downstream facilities such as storage tanks, slug catchers and separators. Full article

In a pilot-scale internal loop airlift reactor with a height of 5.5 m and a main column diameter of 0.484 m, the influence of three gas sparger structures (ladder distributor, tri-nozzle sparger and perforated plate) on the volumetric mass transfer coefficient k_La was investigated. It was found that the perforated plate produces the highest gas holdup difference and circulating liquid velocity between the riser and the downcomer. The perforated plate provides the most efficient mass transfer due to the more uniform gas distribution and higher circulating liquid velocity, followed by the ladder distributor and tri-nozzle spargers. Compared with the tri-nozzle sparger, the perforated plate increases the value of k_La by up to 16% at a superficial velocity of 0.15 m/s. Interestingly, the analysis of the liquid-phase mass transfer coefficient k_L and specific area a with respect to gas velocity shows that the mass transfer rate is primarily controlled by a. By comparing the predictions of different mass transfer models, the slip velocity model based on penetration theory yields a satisfactory agreement with the experimental results within ±15% error. Meanwhile, empirical correlations regarding gas holdup and k_La were developed and were found to have good consistency with experimental values. Full article

This study developed a data-driven surrogate model based on a deep neural network (DNN) to evaluate gas–liquid multiphase flow occurring in horizontal pipes. It estimated the liquid holdup and pressure gradient under a slip condition and different flow patterns, i.e., slug, annular, stratified flow, etc. The inputs of the surrogate modelling were related to the fluid properties and the dynamic data, e.g., superficial velocities at the inlet, while the outputs were the liquid holdup and pressure gradient observed at the outlet. The case study determined the optimal number of hidden neurons by considering the processing time and the validation error. A total of 350 experimental data were used: 279 for supervised training, 31 for validating the training performance, and 40 unknown data, not used in training and validation, were examined to forecast the liquid holdup and pressure gradient. The liquid holdups were estimated within less than 8.08% of the mean absolute percentage error, while the error of the pressure gradient was 23.76%. The R² values confirmed the reliability of the developed model, showing 0.89 for liquid holdups and 0.98 for pressure gradients. The DNN-based surrogate model can be applicable to estimate liquid holdup and pressure gradients in a more realistic manner with a small amount of computating resources. Full article
