The forced-air self-aspirating flotation machine is the core equipment for achieving a horizontal configuration in a large-scale flotation circuit. During scale-up, power consumption increases significantly due to the requirement for a greater pulp suction volume, while flotation dynamics deteriorate. Therefore, it is difficult to meet the horizontal configuration requirement for a large-scale flotation process. In this study, the key factors influencing pulp suction capacity were analyzed, revealing that as impeller submergence depth increases, pulp suction capacity decreases sharply, while power consumption rises, which was determined to be the main limitation in scaling up a forced-air self-aspirating flotation machine. To address these challenges, a new design concept for large-scale forced-air self-aspirating flotation machines was developed, featuring an impeller–stator system positioned in the middle of a trough. This design eliminated the issue of the impeller moving farther from the overflow weir and prevented increasing pulp suction resistance during scale-up. Additionally, an independent design of the upper blades was introduced based on pulp suction demand, and the design method and scale-up equations for the new impeller were established. An industrial experiment system based on a 50 m³ forced-air self-aspirating flotation machine was established to verify the developed design schemes. The new impeller with a middle placement design achieved the best separation performance, exhibited low unit pulp suction power consumption, and demonstrated the most favorable overall performance. Using CFD simulations, the flow pattern and dynamic performance were calculated, including the pulp suction volume, circulation volume, and gas–liquid dispersion for large-scale forced-air self-aspirating flotation machines. The first and largest 160 m³ large-scale forced-air self-aspirating flotation cell was successfully developed and applied in a copper–sulfur mine, where the function of self-absorbing pulp was achieved and power consumption was effectively controlled. Finally, the feasibility and accuracy of the new large-scale forced-air self-aspirating flotation machine design and scale-up method were verified. In this paper, a large forced-air self-aspirating flotation machine is designed and developed which is capable of supporting horizontally configured large-scale flotation processes. This innovative approach significantly simplifies the processing layout and reduces both the equipment configuration complexity and energy consumption, offering a more efficient and cost-effective solution for large-scale mineral processing operations. Full article

The present work investigates a comparative study between mechanical and Imhoflot^TM cells on a mini-pilot scale and the applicability of one self-aspirated H-16 cell (hybrid Imhoflot^TM cell) on an industrial scale on-site. The VM-04 cell (vertical feed to the separator vessel with 400 mm diameter) was fabricated, developed, and examined. The copper flotation experiments were conducted under similar volumetric conditions for both the Imhoflot^TM and mechanical flotation cells keeping the rest of the parameters constant. Further, one H-16 cell was positioned at four different stages in the Gökirmak copper flotation circuit of the Acacia (Türkiye) copper beneficiation plant, i.e., at (i) pre-rougher flotation, (ii) rougher concentrate, (iii) cleaner-scavenger tailing, and (iv) first cleaning concentrate aiming at enhancing the flotation circuit capacity through flash flotation in the rougher stage, reducing copper grade in the final tailing, and increasing cleaning throughput, respectively. Comparative copper flotation tests showed that ultimate recoveries using the Imhoflot^TM and mechanically agitated conventional cells were 94% and 74%, respectively. The industrial scale test results indicated that locating one pneumatic H-16 cell with the duty of pre-floating (also known as flash flotation) led to the enrichment ratio and recovery of 4.84 and 89%, respectively. Positioning the H-16 cell at the cleaner-scavenger tailings could diminish the copper tailings grade from 0.43% to 0.31%. Further, a relatively greater enrichment ratio and copper recovery were obtained using only one Imhoflot^TM cell (1.76 and 64%) in comparison with employing four existing mechanical cells (50 m³, each cell) in series (1.45 and 60%) at the first cleaner stage. Full article

This article describes the impact of restricting the air intake in industrial 250 m³ WEMCO flotation cells at Los Pelambres concentrator. The influence of air restriction on the hydrodynamic and metallurgical performance of this type of machine was evaluated. The experiments were conducted in single flotation cells and entire rougher banks. In all cases, the gas holdup was measured to estimate the effectiveness of the obstruction system to decrease the air concentration. In single cells, axial profiles for solid percentage and particle size were evaluated. In addition, mass balances were conducted to assess the copper recoveries and concentrate features. In individual cells, air restriction led to a decrease in the gas holdup. However, this slight change was enough to obtain a more stable froth zone and a better solid suspension. The latter was observed as: (i) a higher P80 below the pulp–froth interface, (ii) a less diluted pulp at this level, (iii) a slightly higher Cu recovery, and (iv) a coarser concentrate product. A mineralogical analysis of the concentrate sample also showed the presence of coarser liberated Cu-sulfide particles. The results in single cells suggested an improvement in the recovery of coarse particles via more intense solid suspension. The air intake was also restricted in three rougher banks to assess the impact of air obstruction on the overall performance of the respective circuit. Eleven out of fourteen cells were operated with air restriction, which led to a significant improvement in recovery of 0.9%–1.6% (absolute), at a 95% confidence level. Size-by-size mass balances were also conducted for the rougher circuits, which proved that the recovery improvements were justified by the simultaneous increase in the recovery of coarse and fine particles. Thus, a restriction in the air intake showed that a decrease in the gas holdup (and in the bubble surface area flux) was compensated by better solid suspension and a higher collision efficiency in the draft tube. The former promoted the recovery of coarse particles in the quiescent zone, whereas the latter improved the interaction between bubbles and fine particles. Further developments are being made to implement a regulatory control strategy for the air intake in self-aspirated flotation cells and to use this approach for optimizing industrial flotation banks. Full article

In this study, a new jet-stirring coupling flotation device that incorporates the advantages of three conventional flotation machines (specifically, Jameson cell, mechanical flotation cell, flotation column) was designed based on jet suction. The suction capacity of a double cosine self-aspirated nozzle utilized by the device was analyzed under different feeding pressures, and the effects of frother concentration, feeding pressure, suction capacity, and height of sampling location on the bubble size distribution (BSD) were investigated using a high-speed video system. It was found that a large amount of air was sucked into the flotation cell by the self-aspirated nozzle arranged in a non-submerged manner, which met the requirements of flotation in terms of the suction amount of air. The suction capacity showed a positive linear correlation with negative pressure inside the nozzle. When the Methyl isobutyl carbinol (MIBC) concentration reached the critical coalescence concentration (CCC), the bubble size stabilized at approximately 0.31 mm, which was smaller than the bubble size produced by the conventional flotation machine. This indicated that bubbles suitable for flotation were generated. D₃₂ linearly decreased with increasing of feeding pressures and conversely increased with increasing suction capacities and sampling location heights, independent of the frother concentration. Full article
