Lattice structures offer the possibility to obtain lightweight components with additional functionalities, improving their shock absorption and thermal exchange properties. Recently, a body-centered cubic (BCC) lattice structure has been used to fabricate metal lattice sandwich panels (MLSPs) for aerospace applications. MLSPs are made of two external skins and a lattice core and can be produced thanks to laser powder bed fusion technology (LPBF), which is characterized by its superior printing accuracy with respect to other additive manufacturing processes for metals. Since few studies can be found in the literature on Ti-6Al-4V MLSPs, further work is needed to evaluate the mechanical response of these panels. Moreover, due to their design complexity and to avoid a costly experimental campaign, numerical simulation could be used to encourage the industrial application of these structures. In this paper, different cell configurations were printed and tested in compression to study the influence of the cell’s geometrical parameters, i.e., the cell size and beam radius, on the mechanical response of MLSPs. Numerical simulations of the LPBF of these geometries were also carried out to understand how the residual stresses can be varied by varying the cell configuration. A geometrical evaluation was carried out to quantitatively express the influence of the beam radius and cell size on the resulting volume fraction, which strongly influences the mechanical behavior and residual stress profiles of MLSPs. From the analysis, we found that the C2-R0.35 sample resulted in the configuration with the highest compressive strength, while C3-R0.25 showed the lowest and most uniform residual stress profile. Full article

A novel 316L stainless steel Vertex Modified BCC (VM-BCC) lattice unit cell with attractive performance characteristics is developed. Lattice structure, as well as the sandwich panel, are constructed. Numerical simulation is utilized to simulate the quasi-static compression, dynamic compression and blast behavior considering the rate-dependent properties, elastoplastic response and nonlinear contact. Finite element results are validated by comparing with the experimental results. Parametric studies are conducted to gain insight into the effects of loading velocity, equivalent TNT load and explosion distance on the dynamic behavior of the lattice pattern and sandwich panel. Testing results indicate that the proposed 316L stainless steel VM-BCC structure exhibits more superior plateau stress and specific energy absorption (SEA) than those of the BCC or Octet one. The proposed novel lattice will provide reference for improving the protective efficiency in key equipment fields and enhancing overall safety. Full article

An analytical method to predict the elastic modulus of the sandwich body-centered cubic (BCC) lattice structure is presented on the basis of the assumption of a linearly changing elastic modulus. In the constrained region, the maximum of elastic modulus used the elastic moduli of the BCC lattice element with plate constraints and is calculated with Timoshenko beam theory, the minimum used without plate constraints. In the rest of the constrained region, a linear function along the thickness direction is proposed to calculate elastic modulus. The elastic modulus of the unconstrained region is constant and it is the same as the minimum of the constrained region. The elastic modulus of the whole sandwich BCC lattice structure can be calculated theoretically with the elastic modulus of the constrained and unconstrained regions and a single-layer slice integration method. Six kinds of sandwich BCC lattice structures with different geometric parameters are designed and made by resin 3D printing technology, and the elastic moduli are measured. By comparing the predictions of the elastic modulus using the proposed analytical method and existing method with experimental results, the errors between the results of the existing method and the experimental results varied from 10.3% to 24.7%, and the errors between the results of the proposed method and the experimental results varied from 1.6% to 7.4%, proving that the proposed method is more accurate than the existing methods. Full article

In this paper, the shear modulus based equivalent homogenization methods of multi-layer BCC (body-centered cubic) lattice sandwich structures have been studied using analytical, experimental, and finite element methods. In the analytical approach, the multiple strut-deformation patterns were introduced in the derivations of the shear modulus based on Euler–Bernoulli beam theory and Timoshenko beam theory according to different boundary conditions. The analytical shear modulus of three types of rectangle shaped sandwich BCC lattice structures was derived. Finite element models of the BCC lattice structures by ANSYS were conducted to estimate the analytical solutions. Butterfly style sandwich BCC lattice structures were printed by SLM technology using 304 stainless steel (06Cr19Ni10), and corresponding shear experiments using modified Arcan Rig experimental devices were conducted to validate the analytical and numerical calculations. Good agreements were observed among the analytical, numerical, and experimental results. Full article

This paper proposes a dynamic drop weight impact simulation to predict the impact response of 3D printed polymeric sandwich structures using an explicit finite element (FE) approach. The lattice cores of sandwich structures were based on two unit cells, a body-centred cubic (BCC) and an edge-centred cubic (ECC). The deformation and the peak acceleration, referred to as the g-max score, were calculated to quantify their shock absorption characteristic. For the FE results verification, a falling mass impact test was conducted. The FE results were in good agreement with experimental measurements. The results suggested that the strut diameter, strut length, number and orientation, and the apparent material stiffness of the lattice cores had a significant effect on their deformation behavior and shock absorption capability. In addition, the BCC lattice core with a thinner strut diameter and low structural height might lead to poor shock absorption capability caused by structure collapse and border effect, which could be improved by increasing its apparent material stiffness. This dynamic drop impact simulation process could be applied across numerous industries such as footwear, sporting goods, personal protective equipment, packaging, or biomechanical implants. Full article

Lattice cell structures (LCS) are being investigated for applications in sandwich composites. To obtain an optimized design, finite element analysis (FEA) -based computational approach can be used for detailed analyses of such structures, sometime at full scale. However, developing a large-scale model for a lattice-based structure is computationally expensive. If an equivalent solid FEA model can be developed using the equivalent solid mechanical properties of a lattice structure, the computational time will be greatly reduced. The main idea of this research is to develop a material model which is equivalent to the mechanical response of a lattice structure. In this study, the mechanical behavior of a body centered cubic (BCC) configuration under compression and within elastic limit is considered. First, the FEA approach and theoretical calculations are used on a single unit cell BCC for several cases (different strut diameters and cell sizes) to predict equivalent solid properties. The results are then used to develop a neural network (NN) model so that the equivalent solid properties of a BCC lattice of any configuration can be predicted. The input data of NN are bulk material properties and output data are equivalent solid mechanical properties. Two separate FEA models are then developed for samples under compression: one with 5 × 5 × 4 cell BCC and one completely solid with equivalent solid properties obtained from NN. In addition, 5 × 5 × 4 cell BCC LCS specimens are fabricated on a Fused Deposition Modeling uPrint SEplus 3D printer using Acrylonitrile Butadiene Styrene (ABS) and tested under compression. Experimental load-displacement behavior and the results obtained from both the FEA models are in good agreement within the elastic limit. Full article
