Satellites experience complex vibrational environments during their launch and operation, potentially leading to structural failures and equipment damage. This work aimed to mitigate this issue by designing a variable cross-sectional metal rubber isolator (VCMRI), which was fully constructed from metal and featured a symmetric structure. Initially, a finite element model of the VCMRI was developed, incorporating symmetric boundary conditions and employing the Bergström–Boyce model to define variable cross-sectional metal rubber (VCMR) parameters. Subsequently, sinusoidal sweep tests were performed to investigate how variations in VCMR density, spring stiffness, and exc itation deflection angle affect the peak acceleration response and natural frequency of the VCMRI. Finally, simulation analyses were conducted and insertion loss was derived from the results to assess the vibration isolation performance of the VCMRI. The results indicate that the finite element model accurately captures the dynamic behavior of the VCMRI with minimal error. In addition, the VCMRI demonstrates robust vibration isolation performance by effectively integrating the influences of VCMR density, spring stiffness, and excitation angle, achieving insertion losses of up to 19.2 dB across a wide frequency range. It provides robust theoretical support for the design and performance optimization of isolation systems, with potential positive impacts on relevant engineering applications. Full article

Oil extraction is shifting towards high-temperature and high-pressure environments, which leads to the deterioration of the rubber material used in packer rubber cylinders, ultimately resulting in sealing failure. Hence, we propose enhancing the configuration of the rubber cylinder by incorporating a composite material consisting of metal and rubber. Additionally, we suggest integrating springs at the shoulders to fabricate a spring-embedded shoulder protection packer rubber cylinder. ABAQUS 2023 software was employed to simulate the packer setting process, investigating the variations in compression distance between a conventional packer rubber cylinder and a spring-embedded shoulder protection packer rubber cylinder. The results showed that at 25 °C and 177 °C, the compression distance of the fully seated spring-embedded shoulder protection packer rubber cylinder was reduced by 3% compared to the traditional packer rubber, Mises stress was reduced by 14%, and the sealing performance evaluation coefficient K of the rubber cylinder was increased by 2% to 10%.The stress in the spring-embedded shoulder protection packer rubber cylinder is primarily concentrated between the spring and the wire mesh, effectively ensuring the performance of the rubber cylinder and mitigating any potential decrease in sealing performance caused by internal stress concentration. The spring-embedded protective rubber cylinder will not experience shoulder protrusion during the sealing process. The incorporation of a spring-embedded shoulder protection mechanism in the packer rubber cylinder enhances the contact stress between the rubber cylinder and casing tube, mitigates stress concentration within the rubber cylinder, resolves shoulder protrusion issues, and ultimately improves both sealing performance and service life. Full article

The cylindrical shell made of metal rubber has a strong ability to reduce and absorb vibration, which widens its application in the industrial field. Therefore, it is of great significance to study the vibration characteristics of metal-rubber cylindrical shells (MRCSs). However, there is relatively little research on this aspect. Based on this, the dynamic properties of MRCS are investigated in this paper based on viscoelastic theory, the Rayleigh–Ritz method, and the Gram–Schmidt orthogonal polynomials. The correctness of the proposed model was verified by comparison with the literature and experimental verification. The results show that the preloading state and boundary conditions have significant effects on the natural frequency and modal loss factor of MRCS. The effect of the Pasternak elastic foundation on the natural frequency and modal loss factor of MRCS varies with the change of the axial half wave number m. The effect of the Pasternak elastic foundation on higher-order vibrations is similar to that of the artificial spring technique. Full article

Driven by the need for impact resistance and vibration reduction for mechanical devices in extreme environments, an all-metal vibration isolator with 6-degree-of-freedom (6-DOF) motion that is horizontally symmetrical was developed. Its stiffness and damping ability are provided by oblique springs in symmetrical arrangement and a metal–rubber elasto-porous damper. The spring is symmetrically distributed in the center axis of the support load surface. It is necessary to investigate the kinematics and the singularity before conducting multi-body dynamics analysis of the vibration isolator. Based on the theory of dual quaternions, the forward kinematics equations of the isolator were successively derived for theoretical kinematics modeling. In addition, an enhanced Broyden numerical iterative algorithm was developed and applied to the numerical solution of the forward kinematics equations of the vibration isolator. Compared with the traditional rotation-matrix method and Newton–Raphson method, the computational efficiency of the enhanced Broyden numerical iterative algorithm was increased by 680% and 290%, respectively. This was due to the enhanced algorithm without the calculations of any inverse matrix and forward kinematics equations. Finally, according to the forward kinematics Jacobian matrix, the position-singularity trajectory at a given orientation and the orientation-singularity space at a given position are calculated, which provides a basis for the algorithm of the 6-DOF vibration isolator to avoid singular positions and orientations. Full article

A horizontally symmetric all-metallic vibration isolator (AM-VI) is proposed to further investigate the dynamic mechanical performance. The novel AM-VI was constructed by combining hat-shaped metal rubber and oblique springs, which were connected in parallel. The springs were arranged symmetrically relative to the support. The elliptic method and the frequency sweeping method were used to compare the dynamic stiffness and the loss factor of the AM-VI. The results demonstrated that the dynamic stiffness and the loss factor calculated by two distinct test methodologies were considerably different, indicating that the inertial force effect of the dynamic testing equipment should be taken into count when adopting the elliptic method. Furthermore, when the vibration isolation performance was evaluated by utilizing mechanical impedance and force transmissibility, the AM-VI achieved excellent vibration isolation performance within a broad frequency range. Full article

The selection of a rubber compound has a determining influence on the final characteristics of rubber-metal springs. Therefore, the correct selection of a rubber compound is a key factor for development of rubber-metal vibration isolation springs with required characteristics. The procedure for the selection of the rubber compound for vibration isolation of rubber-metal springs has been proposed, so that the rubber-metal elements have the necessary characteristics, especially in terms of deflection. The procedure is based on numerical simulation of spring deflection with Bergström-Boyce constitutive model in virtual experiment, with a goal to determine which parameters of the constitutive model will lead to spring required deflection. The procedure was verified by case study defined to select rubber compound for a rubber–metal spring used in railway engineering. Full article
