To enhance the performance of rigid coaxial rotors across both hovering and high-speed cruising conditions, this study develops a novel aerodynamic optimization method that differentiates between the upper and lower rotors. Utilizing the lifting line and reformulated viscous vortex particle method (rVPM), this approach models the complex wake fields of coaxial rotors and accurately assesses the aerodynamic loads on the blades. The optimization of geometric properties such as planform configuration and nonlinear twist is conducted through an innovative solver that integrates simulated annealing with the Nelder–Mead algorithm, ensuring both rapid and comprehensive optimization results. Comparative analyses demonstrate that these tailored geometric adjustments significantly enhance efficiency in both operational states, surpassing traditional methods. This research provides a strategic framework for addressing the varied aerodynamic challenges presented by different flight states in coaxial rotor design. Full article

This work details the development and validation of a methodology for high-resolution rotor models used in hybrid Blade Element Momentum Theory Unsteady Reynolds Averaged Navier–Stokes (BEMT-URANS) CFD. The methodology is shown to accurately predict single and coaxial rotor performance in a fraction of the time required by conventional CFD methods. The methodology has three key features: (1) a high-resolution BEMT rotor model enabling large reductions in grid size, (2) a discretized set of momentum sources to interface between the BEMT rotor model and the structured URANS flow solver, and (3) leveraging of the first two features to enable highly parallelized GPU-accelerated multirotor CFD simulations. The hybrid approach retains high-fidelity rotor inflow, wake propagation, and rotor–rotor interactional effects at a several orders of magnitude lower computational cost compared to conventional blade-resolved CFD while retaining high accuracy on steady rotor performance metrics. Rotor performance predictions of thrust and torque for both single and coaxial rotor configurations are compared to test the data that the authors obtained at the NASA Langley 14- by 22-ft. Subsonic Tunnel Facility. Simulations were run with both fully turbulent and free-transition airfoil performance tables to quantify the associated uncertainty. Single rotor thrust and torque were predicted on average within 4%. Coaxial thrust and power were predicted within an average of 5%. A vortex ring state (VRS) shielding phenomenon for coaxial rotor systems is also presented and discussed. The results support that this hybrid BEMT-URANS CFD methodology can be highly parallelized on GPU machines to obtain accurate rotor performance predictions across the full spectrum of possible UAM flight conditions in a fraction of the time required by conventional higher-fidelity methods. This strategy can be used to rapidly create look-up tables with hundreds to thousands of flight conditions using a three-dimensional multirotor CFD for UAM. Full article

This study develops a hybrid solver with reversed overset assembly technology (ROAT), a viscous vortex particle method (VVPM), and a CFD program based on the URNS method, in order to study the aerodynamic and acoustic characteristics of coaxial rigid rotors. The aerodynamic load of the “AH-1G” helicopter rotor is first calculated based on the hybrid method and compared with available experimental data. The prediction of the linear noise of the OLS rotor is then performed and the obtained results are compared with available experimental data. These results allow the evaluation of the accuracy of the hybrid method for emulating rotor aerodynamics and acoustics. Afterwards, the hybrid and CFD methods are applied to obtain the aerodynamic and acoustic characteristics of the given coaxial rigid rotor model, while taking into account the trim of the collective pitch. The obtained results demonstrate that the hybrid method has high proficiency in capturing blade–vortex-interaction impulsive loads and high computational efficiency in predicting associated loading noise characteristics. Furthermore, the effect of the hybrid method on the noise characteristics of coaxial rigid rotors under a different advance ratio, blade tip speed, shaft angle, and other conditions, as well as the impact of the upper and lower rotors on the noise contribution of the coaxial rotor are analyzed. Finally, the impacts of the initial phase and the vertical spacing on the sound pressure level are studied. Full article

This present study investigates the effect of blade tip configurations, such as the sweepback angle and anhedral angle, on the performance and hub vibratory loads for the lift-offset coaxial rotor of a 30,000-pound-class high-speed long-range utility helicopter. The rotorcraft comprehensive analysis code, CAMRAD II, is utilized to conduct the performance and hub vibratory load analyses for the present lift-offset coaxial rotor. The total rotor thrust, torque, and individual rotor’s hub pitch moment and hub roll moment are considered the trim targets. The general properties for the lift-offset coaxial rotor are designed from the X2TD, S-97 Raider, and SB > 1 Defiant, which are lift-offset compound helicopters. The rotor performance and hub vibratory loads are studied with the various blade tip configurations including the sweepback angle and anhedral angle. The rotor power when the rotor blade tip considers only the sweepback angle (20°) is lower than the baseline rotor model by 41.25% at 170 knots. The maximum rotor effective lift-to-drag ratio (L/D_e) for the lift-offset coaxial rotor using only the sweepback angle and the rotor with both sweepback (20°) and anhedral angles (10°) at 170 knots increase by 10.82% and 5.02%, respectively, compared with the baseline rotor model without both sweepback and anhedral angles. The vibration index (VI) for the rotor with only the sweepback angle is higher than that for the baseline rotor model without both sweepback and anhedral angles by 37.14%. Furthermore, when the rotor blade tip has the anhedral angle, the magnitude of the Blade Vortex Interaction (BVI) decreases compared with the rotor without the sweepback and anhedral angles. Full article

In the design of electric vertical takeoff and landing (eVTOL) vehicles, coaxial rotors have garnered significant attention due to their superior space usage and aerodynamic efficiency compared to standard rotors. However, it is challenging to study the flow field near the rotors due to the blade–vortex interface (BVI) and vortex–vortex contact between two rotors. Using sliding mesh technology and Reynolds-averaged Navier–Stokes (RANS) solvers, a numerical method was established to simulate the flow field of a coaxial rotor in hover, which was verified by experiments. Using this method, this paper analyzes the relationship between position and intensity of the tip vortex of the upper rotor, the axial velocity of induced flow and the load distribution on the blades at the azimuth when the BVI phenomenon occurs with a difference in rotational speed and rotor spacing. The results indicate that, when the BVI phenomenon appears, the blade-tip vortex of the top rotor rapidly dissipates, and the load distribution of the lower blade changes due to the induced flow of the vortex. When the rotational speed increases, the spanwise thrust coefficient of each rotor changes slightly. The vortex–vortex interaction becomes stronger, which leads to vortex pairing. When the distance between the rotors decreases, the BVI phenomenon occurs at an earlier azimuth and the location of the BVI moves towards the tip of the lower blade. The vortex–vortex interaction is also enhanced, which leads to vortex pairing and vortex merging. Full article
