This paper put forward a hybrid energy harvester for collecting RF and solar energy in quad-band (GSM-900/1800, ISM-2400 and WiMAX-3500). By introducing diverse parasitic structures, good impedance matching with unidirectional radiation is achieved in the multi-band. Below the solar antenna, a low-power rectifier circuit is employed to achieve broadband rectification. Under the input power of 0 dBm, and maximum RF-DC conversion efficiency of 56.94% is realized. Accordingly, the hybrid energy harvester collects RF and solar energy individually or simultaneously, and then converts it into DC for power supply. With a light intensity of 1500 lux, the solar cell obtains 1.732 mW, and the rectenna can harvest additional 0.37–0.405 mW power. The proposed RF–Solar energy harvester has the advantages of multi-frequency operation, high gain, and high energy harvesting conversion efficiency. Full article

In this work, a novel quad-band rectifier circuit is introduced for RF energy harvesting and Internet of Things (IoT) applications. The proposed rectifier operates in the Wi-Fi frequency band and can supply low-power sensors and systems used in IoT services. The circuit operates at $2.4$, $3.5$, 5, and $5.8$ GHz. The proposed RF-to-DC rectifier is designed based on Delon theory and Greinacher topology on an RT/Duroid 5880 substrate. The results show that our proposed circuit can harvest RF energy from the environment, providing maximum power conversion efficiency (PCE) greater than 81% when the output load is $0.511$ kΩ and the input power is 12 dBm. In this work, we provide a comprehensive design framework for an affordable RF-to-DC rectifier. Our circuit performs better than similar designs in the literature. This rectifier could be integrated into an IoT node to harvest RF energy, thereby proving a green energy source. The IoT node can operate at various frequencies. Full article

For low input radio frequency (RF) power from −35 to 5 dBm, a novel quad-band RF energy harvester (RFEH) with an improved impedance matching network (IMN) is proposed to overcome the poor conversion efficiency and limited RF power range of the ambient environment. In this research, an RF spectral survey was performed in the semi-urban region of Malaysia, and using these results, a multi-frequency highly sensitive RF energy harvester was designed to harvest energy from available frequency bands within the 0.8 GHz to 2.6 GHz frequency range. Firstly, a new IMN is implemented to improve the rectifying circuit’s efficiency in ambient conditions. Secondly, a self-complementary log-periodic higher bandwidth antenna is proposed. Finally, the design and manufacture of the proposed RF harvester’s prototype are carried out and tested to realize its output in the desired frequency bands. For an accumulative −15 dBm input RF power that is uniformly universal across the four radio frequency bands, the harvester’s calculated dc rectification efficiency is about 35 percent and reaches 52 percent at −20 dBm. Measurement in an ambient RF setting shows that the proposed harvester is able to harvest dc energy at −20 dBm up to 0.678 V. Full article

RF power is broadly available in both urban and semi-urban areas and thus exhibits as a promising candidate for ambient energy scavenging sources. In this research, a high-efficiency quad-band rectenna is designed for ambient RF wireless energy scavenging over the frequency range from 0.8 to 2.5 GHz. Firstly, the detailed characteristics (i.e., available frequency bands and associated power density levels) of the ambient RF power are studied and analyzed. The data (i.e., RF survey results) are then applied to aid the design of a new quad-band RF harvester. A newly designed impedance matching network (IMN) with an additional L-network in a third-branch of dual-port rectifier circuit is familiarized to increase the performance and RF-to-DC conversion efficiency of the harvester with comparatively very low input RF power density levels. A dual-polarized multi-frequency bow-tie antenna is designed, which has a wide bandwidth (BW) and is miniature in size. The dual cross planer structure internal triangular shape and co-axial feeding are used to decrease the size and enhance the antenna performance. Consequently, the suggested RF harvester is designed to cover all available frequency bands, including part of most mobile phone and wireless local area network (WLAN) bands in Malaysia, while the optimum resistance value for maximum dc rectification efficiency (up to 48%) is from 1 to 10 kΩ. The measurement result in the ambient environment (i.e., both indoor and outdoor) depicts that the new harvester is able to harvest dc voltage of 124.3 and 191.0 mV, respectively, which can be used for low power sensors and wireless applications. Full article

In this work toward a sustainable operation of a self-powered wireless sensor, we investigated a multiband Wi-Fi/3G/4G/5G energy harvester based on a novel wideband circularly polarized antenna, a quadplexer, and rectifiers at four corresponding bands. This proposed antenna consisted of four sequentially rotated dual-dipoles, fed by a hybrid feeding network with equal amplitude and an incremental 90° phase delay. The feeding network was composed of three Wilkinson power dividers and Schiffman phase shifters. Based on the sequential rotation method, the antenna obtained a −10 dB reflection coefficient bandwidth of 71.2% from 1.4 GHz to 2.95 GHz and a 3 dB axial ratio (AR) bandwidth of 63.6%, from 1.5 GHz to 2.9 GHz. In addition, this antenna gain was higher than 6 dBi in a wide bandwidth from 1.65 GHz to 2.8 GHz, whereas the peak gain was 9.9 dBi. The quad-band rectifier yielded the maximum AC–DC conversion efficiency of 1.8 GHz and was 60% at −1 dBm input power, 2.1 GHz was 55% at 0 dBm, 2.45 GHz was 55% at −1 dBm, and 2.6 GHz was 54% at 0.5 dBm, respectively. The maximum RF–DC conversion efficiency using the wideband circularly polarized antenna was 27%, 26%, 25.5%, and 27.5% at −6 dBm of input power, respectively. Full article
