As the global energy structure transitions towards cleaner sources, large-scale integration of wind power has become a trend for modern power systems. However, the impact of low-inertia power electronic converters and the fault propagation effects at critical nodes pose significant challenges to power system stability. To this end, a Kuramoto-like model analysis method, considering node importance, is proposed in this paper. First, virtual node technology is utilized to optimize the power grid topology model. Then an improved PageRank algorithm embedded by a critical node identification method is proposed, which simultaneously considers transmission efficiency, coupling transmission probability, and voltage influence among nodes. On this basis, the traditional uniform coupling assumption is eliminated, thereby reallocating the coupling strength between critical nodes. In addition, the Kron method is applied to simplify the power grid model, constructing a hybrid Kuramoto-like model that integrates second-order synchronous machine oscillators and first-order wind power oscillators. Based on this model, the transient stability of the wind power integrated power system is analyzed. Finally, through estimating the attraction region range of the stable equilibrium point, a transient stability criterion is proposed for fault limit removal time assessment. The simulation results of the improved IEEE 39-bus system show that coupling strength optimization based on node importance reduces the system’s average critical coupling strength by 17%, significantly improving synchronization robustness. Time-domain simulations validate the accuracy of the method, with the relative error of fault removal time estimation controlled within 10%. This research provides a new analytical tool for transient stability analysis of wind power integration. Full article

Precise and comprehensive model development is essential for predicting power network balance and maintaining power system analysis and optimization. The development of big data technologies and measurement systems has introduced new challenges in power grid modeling, simulation, and fault prediction. In-depth analysis of grid data has become vital for maintaining steady and safe operations. Traditional knowledge graphs can structure data in graph form, but identifying topological errors remains a challenge. Meanwhile, Graph Convolutional Networks (GCNs) can be trained on graph data to detect connections between entities, facilitating the identification of potential topological errors. Therefore, this paper proposes a method for power grid topological error identification that combines knowledge graphs with GCNs. The proposed method first constructs a knowledge graph to organize grid data and introduces a new GCN model for deep training, significantly improving the accuracy and robustness of topological error identification compared to traditional GCNs. This method is tested on the IEEE 30-bus system, the IEEE 118-bus system, and a provincial power grid system. The results demonstrate the method’s effectiveness in identifying topological errors, even in scenarios involving branch disconnections and data loss. Full article

Accurate line parameters are the basis for the optimal control and safety analysis of distribution networks. The lack of real-time monitoring equipment in grids has meant that data-driven identification methods have become the main tool to estimate line parameters. However, frequent network reconfigurations increase the uncertainty of distribution network topologies, creating challenges in the data-driven identification of line parameters. In this paper, a line parameter identification method compatible with an uncertain topology is proposed, which simplifies the model complexity of the joint identification of topology and line parameters by removing the unconnected branches through noise reduction. In order to improve the solving accuracy and efficiency of the identification model, a two-stage identification method is proposed. First, the initial values of the topology and line parameters are quickly obtained using a linear power flow model. Then, the identification results are modified iteratively based on the classical power flow model to achieve a more accurate estimation of the grid topology and line parameters. Finally, a simulation analysis based on IEEE 33- and 118-bus distribution systems demonstrated that the proposed method can effectively realize the estimation of topology and line parameters, and is robust with regard to both measurement errors and grid structures. Full article

This paper describes a methodology for implementing the state estimation and enhancing the accuracy in large-scale power systems that partially depend on variable renewable energy resources. To determine the actual states of electricity grids, including those of wind and solar power systems, the proposed state estimation method adopts a fast-decoupled weighted least square approach based on the architecture of application common database. Renewable energy modeling is considered on the basis of the point of data acquisition, the type of renewable energy, and the voltage level of the bus-connected renewable energy. Moreover, the proposed algorithm performs accurate bad data processing using inner and outer functions. The inner function is applied to the largest normalized residue method to process the bad data detection, identification and adjustment. While the outer function is analyzed whether the identified bad measurements exceed the condition of Kirchhoff’s current law. In addition, to decrease the topology and measurement errors associated with transformers, a connectivity model is proposed for transformers that use switching devices, and a transformer error processing technique is proposed using a simple heuristic method. To verify the performance of the proposed methodology, we performed comprehensive tests based on a modified IEEE 18-bus test system and a large-scale power system that utilizes renewable energy. Full article

The paper describes the results of a measurement campaign to characterize the non-intentional emissions (NIE) that are present in the low voltage section of the electrical grid, within the frequency range assigned to narrowband power line communications (NB-PLC), from 20 kHz to 500 kHz. These NIE may severely degrade the quality of the communications and, in some cases, even isolate the transmission devices. For this reason, the identification and characterization of these perturbations are important aspects for the proper performance of the smart grid services based on PLC. The proper characterization of NIE in this frequency range is a key aspect for the selection of efficient configurations to find the best trade-off between data throughput and robustness, or even for the definition of new improved error detection and correction methods. The huge number of types of NIE, together with the wide variety of grid topologies and loads distribution (density and location of homes and industrial facilities) are great challenges that complicate the thorough characterization of NIE. This work contributes with results from field trials in different scenarios, the identification of different types of NIE and the characterization both in time and frequency domains of all the registered disturbances. This contribution will be helpful for a better knowledge of the electrical grid as a transmission medium for PLC and, therefore, for evaluating the appropriateness of different robustness techniques to be applied in the next generation of smart grid services. Full article
